Multimo 115-NITRO Manuale utente
Assembly Instructions
+-
VIDEO
link
70 min.
180 min.
Technical Service
End User
115- NITRO
Page 1 Page 2
Piece T hickness Length Width Piece T hick H eight M ost
A21,18 81,89 17,32 230 2080 440
B11,18 79,06 16,50 130 2008 419
C10,71 79,06 17,28 1 18 2008 439
D10,71 79,06 15,75 1 18 2008 400
E10,71 26,85 15,75 1 18 682 400
F10,71 41,38 15,75 1 18 1051 400
G10,71 78,43 19,69 1 18 1992 500
H10,71 78,43 2,36 1 18 1992 60
J10,71 51,97 4,72 1 18 1320 120
K10,71 37,72 76,38 1 18 958 1940
L10,71 36,97 15,75 1 18 939 400
M20,71 27,56 18,50 2 18 700 470
N10,71 41,57 15,75 1 18 1056 400
P10,71 74,80 6,30 1 18 1900 160
R40,31 81,06 19,88 4 8 2059 505
S10,71 76,85 7,09 1 18 1952 180
Track Title (inch) (mm)
Accessories List
MNG - 01
20 / piece
VD - 03 ( 3,5x18 ) mm
34 / piece
CT - 03 ( 6x50 ) mm
8 / piece
PM - 01
4 / piece
AMR - 01 ( 120N )
2 / piece
20 / piece
MNX 02
VD - 02 (3,5x25) mm
24 / piece
TTC 01
4 / piece
H 01
3 / piece
KVL 01
24 / piece
TAP - 01
20 / piece
DD - 01 ( R10 )
2 / piece
DSE - 01 (40x90x32) mm
2 / piece
VTB - 01 (4,8x16) mm
24 / piece
PL - 02 (8x22x1) mm
2 / piece
KP - 01 ( 224 ) mm
1 / piece
KP - 03
3 / piece
AVT - 01
10 / piece
VKP - 01 (22) mm
5 / piece
IM - 02 (6x20) mm
4 / piece
IM - 03 (6x40) mm
4 / piece
VDA - 01 ( 6,5x50 ) mm
12 / piece
TFC - 01(8x70) mm
2 / piece
TS - 03
4 / piece
TS - 02
2 / piece
TSY - 02
1 / piece
TSY - 03
1 / piece
Page 1 Page 2
Piece T hickness Length Width Piece T hick H eight M ost
A21,18 81,89 17,32 230 2080 440
B11,18 79,06 16,50 130 2008 419
C10,71 79,06 17,28 1 18 2008 439
D10,71 79,06 15,75 1 18 2008 400
E10,71 26,85 15,75 1 18 682 400
F10,71 41,38 15,75 1 18 1051 400
G10,71 78,43 19,69 1 18 1992 500
H10,71 78,43 2,36 1 18 1992 60
J10,71 51,97 4,72 1 18 1320 120
K10,71 37,72 76,38 1 18 958 1940
L10,71 36,97 15,75 1 18 939 400
M20,71 27,56 18,50 2 18 700 470
N10,71 41,57 15,75 1 18 1056 400
P10,71 74,80 6,30 1 18 1900 160
R40,31 81,06 19,88 4 8 2059 505
S10,71 76,85 7,09 1 18 1952 180
Track Title (inch) (mm)
Accessories List
MNG - 01
20 / piece
VD - 03 ( 3,5x18 ) mm
34 / piece
CT - 03 ( 6x50 ) mm
8 / piece
PM - 01
4 / piece
AMR - 01 ( 120N )
2 / piece
20 / piece
MNX 02
VD - 02 (3,5x25) mm
24 / piece
TTC 01
4 / piece
H 01
3 / piece
KVL 01
24 / piece
TAP - 01
20 / piece
DD - 01 ( R10 )
2 / piece
DSE - 01 (40x90x32) mm
2 / piece
VTB - 01 (4,8x16) mm
24 / piece
PL - 02 (8x22x1) mm
2 / piece
KP - 01 ( 224 ) mm
1 / piece
KP - 03
3 / piece
AVT - 01
10 / piece
VKP - 01 (22) mm
5 / piece
IM - 02 (6x20) mm
4 / piece
IM - 03 (6x40) mm
4 / piece
VDA - 01 ( 6,5x50 ) mm
12 / piece
TFC - 01(8x70) mm
2 / piece
TS - 03
4 / piece
TS - 02
2 / piece
TSY - 02
1 / piece
TSY - 03
1 / piece
Page 3 Page 4
STEP 1
VIDEO
link
A-R
A-L
B
C
D
E
F
L
J
M
M
N
R
R
R
R
M-L+MKZ
M-R+MKZ
MNX - 02
KVL 01
B
MNX-02 x 2
KVL-01 x 4
D
MNX-02 x 2
KVL-01 x 4
A-R
MNX-02 x 8
A-L
MNX-02 x 6
G
H
K
S
P
Page 3 Page 4
STEP 1
VIDEO
link
A-R
A-L
B
C
D
E
F
L
J
M
M
N
R
R
R
R
M-L+MKZ
M-R+MKZ
MNX - 02
KVL 01
B
MNX-02 x 2
KVL-01 x 4
D
MNX-02 x 2
KVL-01 x 4
A-R
MNX-02 x 8
A-L
MNX-02 x 6
G
H
K
S
P
Page 5 Page 6
STEP 2 STEP 4
VIDEO
link
VIDEO
link
MNX - 02
KVL 01
C
KVL-01 x 4
F
KVL-01 x 4
KVL-01 x 4
J
MNG - 01
J
C
A-R
D
210°
MNG-01 x 2
STEP 5
MNG - 01
210°
MNG-01 x 2
E
KVL-01 x 4
MNX-02 x 2
STEP 3
VDA - 01 X 6
G
H
Page 5 Page 6
STEP 2 STEP 4
VIDEO
link
VIDEO
link
MNX - 02
KVL 01
C
KVL-01 x 4
F
KVL-01 x 4
KVL-01 x 4
J
MNG - 01
J
C
A-R
D
210°
MNG-01 x 2
STEP 5
MNG - 01
210°
MNG-01 x 2
E
KVL-01 x 4
MNX-02 x 2
STEP 3
VDA - 01 X 6
G
H
Page 7 Page 8
STEP 6 STEP 8
VIDEO
link
VIDEO
link
E
B
R
R
R
R
210°
MNG-01 x 6
MNG - 01MNG - 01
STEP 7
H-01 x 3
210°
MNG-01 x 10
F
A-L
STEP 9
VD - 02 x 14
VD - 02 x 10
AVT - 01x 10
Page 7 Page 8
STEP 6 STEP 8
VIDEO
link
VIDEO
link
E
B
R
R
R
R
210°
MNG-01 x 6
MNG - 01MNG - 01
STEP 7
H-01 x 3
210°
MNG-01 x 10
F
A-L
STEP 9
VD - 02 x 14
VD - 02 x 10
AVT - 01x 10
Page 9 Page 10
STEP 10 STEP 11
VIDEO
link
VIDEO
link
Ø 10 mm / 0,254 inch
DD - 01
TFC - 01
DSE - 01
VTB - 01
PL - 02
PM - 01 X 4
M-L+MKZ
M-R+MKZ
M-L+MKZ
M-R+MKZ
TAP - 01
IM - 02
AL - 02
IM - 02
IM - 03 x 2
AL - 02
IM - 03 x 2
AL - 02
