Multitech RouteFinder RF560VPN Manuale utente

SOHO Internet Security Appliance

RF560VPN

User Guide

RouteFinder SOHO Internet Security Appliance

RF560VPN

PN S000302A Revision A

This publication may not be reproduced, in whole or in part, without prior expressed written permission

Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents hereof

and specifically disclaims any implied warranties of merchantability or fitness for any particular

purpose. Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to

make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to

notify any person or organization of such revisions or changes.

Revision Date Description

A08/18/03 Initial release.

Trademarks

The Multi-Tech logo is a trademark of Multi-Tech System, Inc. Windows is a trademark of

Microsoft. All other trademarks are owned by their respective companies.

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112

(763) 785-3500 or (800) 328-9717

Fax (763) 785-9874

Internet Address: http://www.multitech.com

Contents

Chapter 1 – Introduction and Description .............................................................................. 5

Key Features ...................................................................................................................... 5

RouteFinder Documentation ............................................................................................... 7

RF560VPN Front Panel ...................................................................................................... 8

RF560VPN Back Panel....................................................................................................... 9

Chapter 2 – Installation...........................................................................................................10

Safety Warnings ................................................................................................................10

System Requirements .......................................................................................................10

Unpacking Your RouteFinder.............................................................................................10

Cabling Your RouteFinder .................................................................................................11

Chapter 3 – Configuring the PC .............................................................................................12

Chapter 4 – Navigating the Screens ......................................................................................19

Chapter 5 – Configuring the RouteFinder Using a Web Browser ........................................20

About the Browser Interface...............................................................................................20

Setup Wizard .....................................................................................................................22

Chapter 6 – Managing the RouteFinder Using a Web Browser............................................39

Device Information.............................................................................................................39

Device Status ....................................................................................................................40

Advanced Settings.............................................................................................................42

System Tools.....................................................................................................................52

Chapter 7 – Troubleshooting .................................................................................................60

Chapter 8 – Frequently Asked Questions .............................................................................63

Appendix A – Specifications ..................................................................................................66

Appendix B – Installing TCP/IP ..............................................................................................67

Appendix C – Tools for Your RF560VPN...............................................................................69

PING..................................................................................................................................69

WINIPCFG and IPCONFIG................................................................................................69

TRACERT..........................................................................................................................69

Appendix D – Warranty and Repairs .....................................................................................70

Appendix E – Regulatory Compliance Information ..............................................................72

FCC Part 15 Regulation.....................................................................................................72

EMC, Safety, and R&TTE Directive Compliance................................................................73

Other Approvals.................................................................................................................73

Appendix F – Technical Support............................................................................................74

Glossary ..................................................................................................................................76

Index ........................................................................................................................................81

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF560VPN User Guide 5

Chapter 1 – Introduction and

Description

Welcome to the world of Internet security. Your Multi-Tech SOHO RouteFinder VPN Internet security

appliance, Model RF560VPN, is ideal for the small branch office or telecommuter who needs secure

access to the corporate LAN.

In addition to providing a WAN Ethernet port for DSL or cable broadband Internet access, it also offers

both client-to-LAN and LAN-to-LAN connectivity based on the IPSec protocol. The SOHO RouteFinder

supports up to 10 IPSec tunnels and provides 3DES encryption with 1.5 Mbps throughput.

The RF560VPN is a cost-effective, easy-to-manage solution that is ideal for small- to medium-sized

businesses through the use of Network Address Translation (NAT). Since NAT provides for the

sharing of a single connection, you save the cost of multiple Internet accounts. See the Glossary for

more about NAT.

Key Features

·One WAN Ethernet port connects to a DSL or cable modem for shared Internet access.

·Supports up to 10 IPSec VPN tunnels for secure LAN-to-LAN and Client-to-LAN access over the

Internet.

·3DES encryption throughput of 1.5 Mbps.

·Built-in 4-port 10/100M bps switch.

·Built-in firewall and DHCP services with Network Address Translation (NAT).

·Protects your LAN against Denial of Service (DoS) attacks.

·Internet access controls provide client and site filtering.

·Asynchronous port for automatic dial-backup.

·Network monitoring allows the network administrator to view all incoming and outgoing packets,

status of connections, and specific connection events via a Syslog server.

·Configuration and management using any Web browser.

·Works with H.323 Voice over IP products including Multi-Tech MultiVOIP gateways or Microsoft

NetMeeting.

·PPPoE support.

·Supports Windows Plug and Play

·Flash memory allows easy firmware upgrades.

·IP address mapping/port forwarding.

·Two-year warranty.

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF560VPN User Guide 6

·Secure VPN Connections. The SOHO RouteFinder VPN uses the IPSec industry standard

protocol, data encryption, and the Internet to provide high-performance, secure VPN connections.

·For LAN-to-LAN connectivity, the RouteFinder utilizes the IPSec protocol to provide up to 10

tunnels with strong 168-bit 3DES encryption using IKE and PSK key management. In addition, it

provides very high performance with 1.5 Mbps with 3 DES encryption throughput.

·For Client-to-LAN connectivity, Multi-Tech provides optional IPSec client software allowing

traveling employees and telecommuters secure access to the company’s internal network.

·Network Security Protection. Protects a network from invalid access.

·Prevention of DoS (Denial of Service) – Prevents the consequences of the Denial of Service,

such as network traffic congestion or ping of death.

·Hacker Attack Logging – Supports general hacker attack pattern monitoring and logging.

·Filtering – Prevents unauthorized packets from entering or leaving the local network.

·Connects up to 253 Users to the Internet with Broadband Speed. With the SOHO

RouteFinder VPN, up to 253 users are connected to the Internet with only one IP account.

·LAN Segmentation. For added LAN security, the RouteFinder can be used to segment the LAN

by connecting the corporate servers to one RouteFinder Ethernet port and the Internet Servers to

the other Ethernet port. This configuration puts the corporate servers behind a firewall and the

Internet servers outside the firewall. To continue to provide Internet access, connect a modem or

ISDN terminal adapter to the RouteFinder’s asynchronous port.

·Can Be Configured as a DHCP Server. The SOHO RouteFinder VPN can be configured as a

DHCP server to handle request for Internet services and route to and from the ISP. Server and

Client features include:

DHCP Server – Automatically assigns IP information to the network users.

DHCP Client – Automatically gets IP information from the ISP DHCP server.

PPPoE Client – Supports PPPoE client function to connect to the remote PPPoE server.

Idle Time – Lets you set a specified idle-time before automatically disconnecting.

Dial-on-Demand – Eliminates the need for dial-up; automatically logs to your ISP.

The RouteFinder RF560VPN

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF560VPN User Guide 7

RouteFinder Documentation

The Quick Start Guide

The Quick Start Guide is a shorter version of this User Guide. It is included in printed form with your

RF560VPN. Both guides are intended to be used by systems administrators and network managers.

They provide the necessary information for a qualified person to unpack, cable, and configure the

device for proper operation.

This User Guide

The User Guide can be installed from the CD by clicking Install Manuals on the Installation screen or

downloading the file from our Web site at: http://www.multitech.com

Save or Print the User Guide

Once the User Guide is displayed on screen using Adobe Acrobat Reader, you can save the .pdf file

to your system or print a copy.

Setup Examples and Other Helpful Documents

There are five reference documents to help you setup and use your RF560VPN.

These reference guides are located on the CD that accompanies your RouteFinder and also on

the Multi-Tech Web site.

Description of the Setup Examples

1. Setup Examples for the RF560VPN.

The four examples show:

·A LAN-to-LAN VPN configuration between two RF560VPNs. One at Site A and one at Site

B. Both RouteFinders use static IP address at their WAN port gateways.

·A LAN-to-LAN VPN configuration between an RF560VPNs at Site A that uses a static IP

through its WAN port and an RF560VPN at Site B that uses a dynamic IP address through

its WAN port.

·A LAN-to-LAN VPN configuration between an RF560VPN at Site A that uses a static IP

address at the WAN port and an RF560VPN at Site B that uses dynamic IP addressing

through a modem connected to the serial port.

·A Client-to-LAN configuration between an RF560VPN at Site A and an SSH IPSec Client.

Each example includes a diagram, a summary chart of input values, an address table you can use

to keep track of your values, and explanations of the Web interface screens.

2. RF560VPN Using a NAT Box with an IPSec Pass-Through.

The two example show:

·SSH Sentinel IPSec client behind a NAT box doing IPSec Pass-Through to an RF560VPN.

·An RF560VPN behind a NAT box doing IPSec Pass-Through to another RF560VPN.

3. RF560VPN File Sharing across VPN.

4. Configuring IPSec Tunneling in Windows XP or 2000 and Connecting to an RF560VPN.

5. Advanced Settings - five examples.

6. FQDN and DDNS Examples.

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF560VPN User Guide 8

RF560VPN Front Panel

RF560VPN Light Panel

LEDs Description

Link ACT Lights when the LAN client is correctly connected to the Ethernet port. Blinks

when there is activity on the Ethernet port.

100/10 Lights when the LAN client is connected at 100MB.

Off when the LAN client is connected at 10MB.

FDX COL

Lights when the LAN client is connected as full duplex.

Off when the LAN client is connected as half duplex. Blinks when there are

collisions on the network.

Serial Data Blinks when the Serial async port is receiving or transmitting data.

Serial DCD Lights when the Serial async port is properly connected to a remote site.

WAN 100 Lights when a successful connection to the 100BaseT WAN is established.

Off when connected to the 10BaseT.

WAN Link /

ACT

Lights when the LAN port has a valid Ethernet connection. Blinks when it is

receiving or transmitting data.

Status Blinks when it is starting, saving the configuration, or performing a firmware

update. Normally, it should be off.

Power Lights when power is being supplied to the router.

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF560VPN User Guide 9

RF560VPN Back Panel

12VDC Power The power port connects the AC power adapter.

10/100 BT WAN

(10/100BaseT)

The WAN port connects the xDSL modem or cable modem.

Serial The Serial port connects a standard modem (optional).

Reset

The Reset button resets the router to factory defaults. Press and hold the Reset

button until the Status LED of the RF560VPN blinks, and then release it. Do not

press this button unless you want to restore all settings to the factory defaults.

Ports 1 - 4 There are 4 LAN ports. You can connect network devices such as PCs, FTP

servers, printers, or other devices you want to put on your network.

Chapter 2 – Installation

Multi-Tech Systems, Inc. RF560VPN User Guide 10

Chapter 2 – Installation

Safety Warnings

1. Never install telephone wiring during a lightning storm.

2. Never install telephone jacks in a wet location unless the jack is specifically designed for wet

locations.

3. This product is to be used with UL and cUL listed computers.

4. Never touch uninsulated telephone wires or terminals unless the telephone line has been

disconnected at the network interface.

5. Avoid using a telephone during an electrical storm. There may be a remote risk of electrical

shock from lightening.

6. Do not use the telephone to report a gas leak in the vicinity of the leak.

7. To reduce the risk of fire, use only No. 26 AWG or larger Telecommunications line cord.

System Requirements

·Microsoft I.E 5.5 or later version or Netscape Navigator 7.0 or later version

·One computer with an installed 10Mbps, 100Mbps or 10/100Mbps Ethernet card

·One Modem or ISDN TA (if a dialup backup connection is needed)

·One RJ-45 xDSL/Cable Internet connection

·TCP/IP protocol installed

·UTP network Cable with a RJ-45 connection

Unpacking Your RouteFinder

The RF560VPN shipping box contains the following items:

·The RouteFinder RF560VPN

·One RF560VPN System CD

·Power Supply

·A Quick Start Guide

If any of the items is missing or damaged, please contact Multi-Tech Systems.

Altri manuali per RouteFinder RF560VPN

Indice

Altri manuali Multitech Router di rete

Multitech

Multitech MultiConnect rCell 100 Series Manuale utente

Multitech

Multitech RouteFinder RF560VPN Manuale utente

Multitech

Multitech MultiConnect rCell 100 Series Manuale utente

Multitech

Multitech rCell 500 Series Manuale utente

Multitech

Multitech MultiConnect rCell MTR-H6 Manuale utente

Multitech

Multitech MultiFRAD FR220 Manuale utente

Multitech

Multitech MultiConnect rCell100 Cat M1/NB-IoT Series Istruzioni per l'installazione

Multitech

Multitech MultiConnect rCell 100 Series Manuale utente

Multitech

Multitech RouteFinder MTASR2-201 Manuale utente

Multitech

Multitech MultiConnect rCell MTR-H6 Manuale utente

Multitech

Multitech RoteFinder RF500S Manuale utente

Multitech

Multitech RouteFinder MTASR2-203 Manuale utente

Multitech

Multitech MultiVOIP 100 (MVP110 Manuale utente

Multitech

Multitech MultiConnect rCell 100 Series Manuale utente

Multitech

Multitech MultiConnect rCell 100 Series Manuale utente

Multitech

Multitech MultiFrad FR3100 Manuale utente

Multitech

Multitech MultiConnect rCell 100 Series Manuale utente

Multitech

Multitech MultiConnect rCell MTR-LAT1-B07 Manuale utente

Multitech

Multitech MultiConnect rCell 100 Series Manuale utente

Multitech

Multitech MultiConnect rCell MTR-H5 Manuale di istruzioni

Multitech

Multitech MULTIFRAD FR3060 Manuale utente

Multitech

Multitech MultiFRAD FR221 Manuale utente

Multitech

Multitech MultiConnect rCell 100 Series Manuale utente

Multitech

Multitech MultiConnect rCell 100 Series Istruzioni per l'installazione

Manuali Router di rete popolari di altre marche

Allnet

Allnet ALL0333AU Manuale utente

HomeSeer

HomeSeer HT-SEL Manuale utente

Sercomm

Sercomm Genesis OC3505D Manuale utente

Billion

Billion BIPAC 5102 Series Manuale utente

TP-Link

TP-Link TD-8817 Manuale utente

Motorola

Motorola MR1900 Manuale utente

Digi

Digi IX14 Manuale utente

Cisco

Cisco NCS 540 Manuale

XAVi

XAVi X8821e Manuale utente

BEC

BEC 6200WZL Manuale utente

MikroTik

MikroTik hAP ac3 Series Manuale utente

Korenix

Korenix JetNet 5428G Series Manuale utente

NETGEAR

NETGEAR FS526T - Switch Manuale utente

Korenix

Korenix JetNet 5710G Series Manuale utente

Automated Logic

Automated Logic ZN551 Manuale del proprietario

Cisco

Cisco ASR 1000 Series Manuale dell'operatore

EnGenius

EnGenius ESR-9710 Manuale utente

Cisco

Cisco 805 Series Istruzioni operative e di sicurezza
