CONTENTS
1 EN
WARNING & PRECAUTION
Support USB DVR
NK 10.0 operating system
Cpu 8-Core A53 Architecture
9"/10.1" IPS Screen
1024 x 600 resolution
500 lumens LCD display
Support multicolor key backlight
2.5D G+G Capacitive screen
2G or 4G large memory
32G or 64G storage space
Support ios Phone link
Support Android Phone link
Built-in bluetooth,support A2DP
Support bluetooth music playback
Support USB playback
Support 1080P video playback
Support Picture-in-Picture playback
Support double screen differential display
Support external microphone interface
Support AHD camera reversing
Built-in GPS,Use FARKRA connector
High sensitivity radio, support FM AM RDS
HDMI ouput
2 channel audio input
1 video input,1 video output
Built-in professional DSP
Support HPF, LPF
Support time delay setting
Support filter slope setup
Support Phase adjustment
Support Q Value adjustment
Support frequency customization
Support 5.1, 2-way, 3-way network
Support gain adjustment for every channel
Support gain adjustment for every frequency
Preset 6 sound effects, support 3 groups of scenes
Support subwoofer volume control
Pre-output: 8 channel x 4V
Maximum power: 4 x 50W
2 EN
PRODUCT FEATURES
A: Power Supply
G: Camera Input
C: NA
D: NA
F: 6P USB
B: Extend
H: Radio ANT
J: HDMI
E: 4P USB
I: GPS
B
D
C
EFG
A
J
H
I
Black Groud Wire
Yellow Battery Wire
Red Lgnittion Wire
Orange Lamp Control Wire
Purple/White Reverse Wire
Brown Steering Wheel Contrl Wire1
Brown/Black Steering Wheel Contrl Wire2
Blue Automatic Antenna
Grey/Black Front Right Speaker-
Front Left Speaker-
Front Left Speaker+
Grey Front Right Speaker+
Green/Black Rear Left Speaker-
White/Black
Rear Left Speaker+
Rear Right Speaker-
Green
White
Purple/Black
Rear Right Speaker+Purple
Lobel Color Name Lobel Color Name
GND
B+
ACC
ILL
BACK
KEY1
KEY2
P.ANT
FR-
FR+
RL-
RL+
FL-
FL+
RR-
RR+
A:Power
Lobel Color Name
Brake
Yellow
G: Camera Input
Reverse Camera Input
Light Green Brake Control
Camera Input
Red DVR Camera Power
Supply +12V
Black DVR Camera Power
Supply GND
WIFI-ANT
BT-ANT
Blue WiFi Signal Antenna
Blue BT Signal Antenna
DVR Camera
Power Supply
+12V
DVR Camera
Power Supply
GND
Lobel Color Name Lobel Color Name
B:Extend
VIDEO IN
AUDIO IN-L
AUDIO IN-R
CVBS OUT
MIC
Amp.Control
Yellow
White
Red
Yellow
White
Red
White
Red
White
Red
Brown
Black
Blue/White
Video Input
Audio Input Left
Audio Input Right
Video Output
2 Frequency: Front Left High Audio Output
Microphone Interface
Power Amplifier Control Wire
5.1: FL
OUTPUT 2-Way: FL HIGH
3-Way: FL HIGH
5.1: FR
OUTPUT 2-Way: FR HIGH
3-Way: FR HIGH
5.1: RL
OUTPUT 2-Way: FL MID lOW
3-Way: FL MID
5.1: RR
OUTPUT 2-Way: FR MID LOW
3-Way: FR MID
Brown
OUTPUT
5.1: SUB_SW-L
2-Way: SUB_SW-L
3-Way: SUB_SW-L
OUTPUT
5.1: SUB_SW-R
2-Way: SUB_SW-R
3-Way: SUB_SW-R
OUTPUT 5.1: CENTER-L
3-Way: FL LOW
OUTPUT
5.1: CENTER-R
3-Way: FR LOW
3 Frequency: Front Left High Audio Output
5.1 Channel: Front Left Audio Output
2 Frequency: Front Right High Audio Output
3 Frequency: Front Right High Audio Output
5.1 Channel: Front Right Audio Output
2 Frequency: Front Left Mid Low Audio Output
3 Frequency: Front Left Middle Audio Output
5.1 Channel: Rear Left Audio Output
2 Frequency: Front Right Medium Low Audio Output
3 Frequency: Front Right Middle Audio Output
5.1 Channel: Rear Right Audio Output
2 Frequency: Left Subwoofer Audio Output
3 Frequency: Left Subwoofer Audio Output
5.1 Channel: Left Subwoofer Audio Output
2 Frequency: Right Subwoofer Audio Output
3 Frequency: Right Subwoofer Audio Output
5.1 Channel: Right Subwoofer Audio Output
3 Frequency: Front Left Low Audio Output
5.1 Channel: Center Left Audio Output
3 Frequency: front Right Low Audio Output
5.1 Channel: Center Right Audio Output
3 EN
WIRING CONNECTION
4 EN
ACCESSORY LIST
FRONT PANEL
Check and identify the contents of your package:
1. 16P ISO Cable x 1pc
3. 20P InPut / OutPut Cable x 1pc
2. GPS Antenna x 1pc
4. 4P USB Cable x 1pc
7. User Manual x 1pc
6. 10P Camera Input Cable x 1pc
5. 6P USB Cable x 1pc
Function Operations & Controls
1. MIC
7. Volume
6. Volume
5. Return
4. Home
3. Power
2. RST
Microphone: Voice receiving position
Short press to decrease volume.
Press to back to previous.
Press to enter main menu.
Press and hold for more than 1 seconds to turn off the screen.
Press to Mute
In the power-on state:
Short press to increase volume.
Reset button: use a tool (such as a toothpick) to trigger the hidden buttons through
the small hole, and the navigation can be restored to factory settings.
8. Install Screw x 5 pc
5 EN
Click this icon button to enter the home interface.
Click this icon to enter the background program
interface, you can view the recently opened and
running programs in the background.
Click this icon to return to the previous page.
Show day or night mode.
WIFI on/off display.
Bluetooth on/off display.
Time display.
Memory card inserted display.
Click this the icon pops up a hidden APP window
with options to run Chrome, Maps, YouTube,
Google,Music, Bluetooth Music, and more.
Click this icon to enter the application interface;
The factory app interface is divided into three
pages, you can swipe left to browse all the apps.
Click this icon to enter the radio interface.
Click this icon to enter the music interface.
Click this icon to enter the navigation interface.
Click this icon to enter the Bluetooth interface.
HOME PAGE OPERATION
Home Interface
Application Interface
Application Interface
Application Interface
Press [ ] on the panel to enter the homepage.
Click the [ ] icon to enter the APP application interface.
6 EN
Short press to switch to a previous station,
long press to search for a previous station.
Click the icon to enter FM band.
Click the icon to enter AM band.
List of favorite radio stations.
Short press to switch to the next station,
long press to search for the next station.
Short press to search for radio stations
automatically, then browse radio stations
, long press to browse radio stations
automatically.
Touch the icon to join or cancel your
favorite radio station.
Click the icon to pop up the radio setting
window, you can set the far and short
range, ST, AF, TA switch.
Click the icon to enter the DSP audio
interface.
Click the icon to enter the list of radio
stations.
Pause/play button.
Click the icon to pop up the keyboard
interface, manual input to switch radio.
Manual Input Keyboard InterfaceRadio Setting Interface
RADIO
FM Interface AM Interface
RDS will allow you to display information such as traffic status, radio station name and more. The unit can
automatically switch to the strongest station based on the similar program.
RDS Function
Function ICONS are as follows：
7 EN
Connected Interface
Search Equipment Interface
Phone Book
History Call Record
Setting Interface
The first time pair mobile phone with AV receiver,
please follow below steps:
3. Click to [ Bluetooth Auto Connect ] select
enable [ ON ].
2. Turn on the phone's Bluetooth to search:
Bluetooth device: NAM5420.
1. Click [ ] to enter the Bluetooth setting interface.
The machine is connected to the mobile phone:
4. The phone will pop up a request box for Bluetooth
pairing，Enter the password 0000 or 1234 and then
click to confirm the connection.
1. Click this icon in the connection interface to
enter the search list.
2. Click this icon to search for connected devices.
5. If the device is connected, the connected
device will be displayed in the list of connected
devices.
3. Click this icon to match the device to be
connected.
6. Click the icon to disconnect the device.
4. In the Bluetooth Settings, you can change the name,
password, automatic connection switch and
automatic call switch.
7. If you need to delete the connected device,
click the icon .
BLUETOOTH
Dialing Interface
Dial key.
Backspace.
Phone book.
History call record.
Dial keyboard interface.
Bluetooth connection.
Bluetooth Settings.
Hang up.
Function ICONS are as follows：
