GETTING STARTED GUIDE
PXIe-5841
6 GHz, 1 GHz Bandwidth, RF PXI Vector Signal Transceiver
Note Before you begin, install and configure your chassis and controller.
This document explains how to install, configure, and test the PXIe-5841. The PXIe-5841 is
an RF vector signal transceiver (VST) and ships with the following software options, which
you use to program the device.
• RFmx software
• NI-RFSA and NI-RFSG driver software
Notice The protection provided by this equipment may be impaired if it is used in
a manner not described in the documentation.
Contents
Verifying the System Requirements..........................................................................................2
Unpacking the Kit..................................................................................................................... 2
Preparing the Environment....................................................................................................... 2
Verifying the Kit Contents........................................................................................................ 3
Other Equipment............................................................................................................... 4
Choosing and Installing the Software....................................................................................... 5
Software Options...............................................................................................................5
Installing the Software...................................................................................................... 5
Installing the PXIe-5841........................................................................................................... 6
Direct Connections to the PXIe-5841............................................................................... 8
Hardware Front Panel Connectors and Indicators............................................................ 9
Configuring the Hardware in MAX........................................................................................ 11
Self-Calibration.......................................................................................................................12
Performing a Device Self-Calibration Using the NI-RFSA or NI-RFSG SFP............... 12
Locating the Software and Examples......................................................................................13
Software Locations......................................................................................................... 13
Programming Examples Locations................................................................................. 15
Making a First Measurement.................................................................................................. 16
Troubleshooting...................................................................................................................... 17
What Should I Do if the PXIe-5841 Doesn't Appear in MAX?......................................17
Why Is the ACCESS LED Off When the Chassis Is On?...............................................17
Where to Go Next................................................................................................................... 18
Worldwide Support and Services............................................................................................ 18
Verifying the System Requirements
To use the PXIe-5841, your system must meet certain requirements. For more information
about minimum system requirements, recommended system, and supported application
development environments (ADEs), refer to the readme, which is installed or available at
ni.com/manuals.
Unpacking the Kit
Notice To prevent electrostatic discharge (ESD) from damaging the device, ground
yourself using a grounding strap or by holding a grounded object, such as your
computer chassis.
1. Touch the antistatic package to a metal part of the computer chassis.
2. Remove the device from the package and inspect the device for loose components or any
other sign of damage.
Notice Never touch the exposed pins of connectors.
Note Do not install a device if it appears damaged in any way.
3. Unpack any other items and documentation from the kit.
Store the device in the antistatic package when the device is not in use.
Preparing the Environment
Ensure that the environment you are using the PXIe-5841 in meets the following
specifications.
Temperature
Operating ambient temperature
Chassis with slot cooling
capacity ≥58 W1
0 °C to 55 °C
All other compatible chassis20 °C to 40 °C
Operating relative humidity 10% to 90%, noncondensing
1Not all chassis with a slot cooling capacity ≥58 W can achieve this ambient temperature range.
Refer to PXI chassis specifications to determine the ambient temperature ranges your chassis can
achieve.
2For chassis with a slot cooling capacity of 38 W, the fan speed must be set to HIGH to achieve this
ambient temperature range.
2| ni.com | PXIe-5841 Getting Started Guide
Maximum altitude 2,000 m (800 mbar) (at 25 °C ambient
temperature)
Pollution Degree 2
Indoor use only.
Notice Clean the hardware with a soft, nonmetallic brush or lint free cloth. Make
sure that the hardware is completely dry and free from contaminants before returning
it to service.
Note Refer to the PXIe-5841 Specifications at ni.com/manuals for complete
specifications.
Verifying the Kit Contents
Figure 1. PXIe-5841 Kit Contents
123
PXIe-5841
VectorSignal Transceiver
9kHz – 6 GHz, 1 GHz BW
PFI0
DIO
REF
OUT
REF
IN
RFIN
+33dBm MAX
50
Ω
RFOUT
ReversePower
+33dBm MAX
ACCESS ACTIVE
LOOUT
50Ω
LOOUT
50Ω
LOIN
+15dBm MAX
50Ω
LOIN
+15dBm MAX
50Ω
50Ω
50Ω
ESD
SENSITIVE
4 5 6
1. PXIe-5841 Module
2. Screwdriver, Part Number 772006-01
3. SMA Driver Bit, Part Number 780895-01
4. PXIe-5841 Safety, Environmental, and Regulatory
Information
5. Maintain Forced-Air Cooling Note to Users
6. PXIe-5841 Getting Started Guide (This
Document)
PXIe-5841 Getting Started Guide | © National Instruments | 3
Other Equipment
There are several required items not included in your device kit that you need to operate the
PXIe-5841. Your application may require additional items not included in your kit to install or
operate your PXIe-5841.
Required Items
• A PXI Express chassis and chassis documentation
• A PXI Express embedded controller or PC with MXI controller system that meets the
system requirements specified in this guide and chassis documentation
Optional Items
• PXI Chassis Slot Blocker kit (NI part number 199198-01)
• SMA (m)-to-SMA (m) cables
• SMA (m)-to-MMPX (m) cables
• MMPX (m)-to-MMPX (m) cables
• OCuLink x4, 1 m cable (NI part number 143340-01)3
Visit ni.com for more information about these additional items.
3NI does not recommend using an OCuLink x4 cable supplied by another manufacturer.
4| ni.com | PXIe-5841 Getting Started Guide
Choosing and Installing the Software
Software Options
NI provides three software options for programming the PXIe-5841—RFmx, NI-RFSA and
NI-RFSG instrument driver software.
Table 1. PXIe-5841 Software Options
Software
Option
Description Use Case
RFmx Provides a single-handle instrument
driver with built-in measurements.
You can use instrument driver
FPGA extensions to customize the
device FPGA using precompiled
bitfiles.
Use RFmx SpecAn to perform spectral
measurements.
Use RFmx Demod to perform
modulation quality measurements, such
as EVM.
Use RFmx personalities to perform
physical layer analysis on supported
communications and connectivity
signals.
NI-RFSA and
NI-RFSG
instrument
driver
The NI-RFSA and NI-RFSG APIs
each provide a fixed API for
interacting with your hardware.
NI-RFSA and NI-RFSG provide
standard IVI-based functionality
needed for most vector signal
analyzer and vector signal
generator applications.
You can use NI-RFSA and
NI-RFSG instrument driver FPGA
extensions to customize the device
FPGA using precompiled bitfiles.
Use NI-RFSA to create custom
measurements or applications that
require I/Q data.
Use NI-RFSG to generate continuous
wave (CW) or modulated waveforms.
Use NI-RFSA and NI-RFSG with the
NI Modulation Toolkit to develop
software-defined radio transmitters and
receivers.
Use NI-RFSG with the NI Modulation
Toolkit to create and generate
modulated signals to test receivers.
Related Information
Refer to the RFmx SpecAn Help, the NI-RFmx Demod Help, the NI RF Vector Signal Analyzers
Help, or the NI RF Signal Generators Help for more information about using the NI-RFmx,
NI-RFSA, and NI-RFSG instrument driver FPGA extensions.
Installing the Software
You must be an Administrator to install NI software on your computer.
1. Install an ADE, such as LabVIEW or LabWindows™/CVI™.
PXIe-5841 Getting Started Guide | © National Instruments | 5
2. Install the driver software using NI Package Manager or by inserting your driver software
media into your computer.
If you do not already have NI Package Manager installed, visit ni.com/r/NIPMDownload
to download NI Package Manager. Refer to the NI Package Manager Manual for more
information about installing, removing, and upgrading NI software using NI Package
Manager.
3. Follow the instructions in the installation prompts.
Note Windows users may see access and security messages during
installation. Accept the prompts to complete the installation.
4. When the installer completes, select Restart in the dialog box that prompts you to restart,
shut down, or restart later.
Installing the PXIe-5841
Notice To prevent damage to the PXIe-5841 caused by ESD or contamination,
handle the module using the edges or the metal bracket.
You must install the software before installing the hardware.
Before you install the hardware, refer to the guidelines in the Maintain Forced-Air Cooling
Note to Users included with the module to ensure that the device can cool itself effectively.
This document is also available at ni.com/manuals.
The PXIe-5841 is a two-slot module with two backplane connectors. The module must be
installed into two adjacent chassis slots.
1. Ensure the AC power source is connected to the chassis before installing the module.
The AC power cord grounds the chassis and protects it from electrical damage while you
install the module.
2. Power off the chassis.
3. Inspect the slot pins on the chassis backplane for any bends or damage prior to
installation. Do not install a module if the backplane is damaged.
4. If the chassis has a slot cooling capacity of 38 W, set the fan speed to HIGH.
Note Inadequate air circulation could cause the temperature inside the chassis
to rise above the optimal operating temperature for the device, potentially
causing thermal shutdown, shorter lifespans, or improper performance.
5. Position the chassis so that inlet and outlet vents are not obstructed.
6. Remove the black plastic covers from all the captive screws on the module front panel.
7. Identify two adjacent PXI Express-compatible slots in the chassis. The following figure
shows the symbols that indicate the slot types.
6| ni.com | PXIe-5841 Getting Started Guide
Figure 2. Chassis Compatibility Symbols
NI PXIe-1062Q
12 3 45
1. PXI Express System Controller Slot
2. PXI Peripheral Slot
3. PXI Express Hybrid Peripheral Slot
4. PXI Express System Timing Slot
5. PXI Express Peripheral Slot
The PXIe-5841 can be placed in PXI Express peripheral slots, PXI Express Hybrid
peripheral slots, or PXI Express system timing slots.
8. Touch any metal part of the chassis to discharge static electricity.
9. Ensure that the ejector handle is in the unlatched (downward) position.
10. Hold the module by the edges and slide it into the empty compatible slots. Ensure the
base engages with the guides in the chassis.
Figure 3. PXIe-5841 Module Installation
1
2
3
ESD
SENSITIVE
NIPXIe-5646R
VectorSignal Transceiver
65MHz - 6.0 GHz, 200 MHz BW
1. PXI Express Chassis
2. PXIe-5841 Module
3. Ejector Handle in Unlatched (Downward) Position
11. Latch the module in place by pulling up on the ejector handle.
12. Secure the module front panel to the chassis using the front-panel mounting screws.
Note Tightening the top and bottom mounting screws increases mechanical
stability and also electrically connects the front panel to the chassis, which can
improve the signal quality and electromagnetic performance.
PXIe-5841 Getting Started Guide | © National Instruments | 7
13. Use slot blockers and cover all empty slots with filler panels to maximize cooling air
flow.
Note Proper airflow is critical to device operation.
14. Power on the chassis.
Direct Connections to the PXIe-5841
The PXIe-5841 is a precision RF instrument that is sensitive to ESD and transients. Ensure
you take the following precautions when making direct connections to the PXIe-5841 to avoid
damaging the device.
Notice Apply external signals only while the PXIe-5841 is powered on. Applying
external signals while the device is powered off may cause damage.
• Ensure you are properly grounded when manipulating cables or antennas connected to the
PXIe-5841 RF IN connector.
• If you are using nonisolated devices, such as a nonisolated RF antenna, ensure the devices
are maintained in a static-free environment.
• If you are using an active device, such as a preamplifier or switch routed to the
PXIe-5841 RF IN connector, ensure that the device cannot generate signal transients
greater than the RF and DC specifications of the PXIe-5841 RF IN connector.
8| ni.com | PXIe-5841 Getting Started Guide
Hardware Front Panel Connectors and Indicators
Figure 4. PXIe-5841 Front Panel
PXIe-5841
Vector Signal Transceiver
9 kHz – 6 GHz, 1 GHz BW
PFI 0
DIO
REF
OUT
REF
IN
ESD
SENSITIVE
RF IN
+33 dBm MAX
50 Ω
RF OUT
Reverse Power
+33 dBm MAX
50 Ω
LO OUT
50 Ω
LO OUT
50 Ω
LO IN
+15 dBm MAX
50 Ω
LO IN
+15 dBm MAX
50 Ω
50 Ω
50 Ω
Notice Apply external signals only while the PXIe-5841 is powered on. Applying
external signals while the device is powered off may cause damage.
PXIe-5841 Getting Started Guide | © National Instruments | 9
Table 2. Device Front Panel Icon Definitions
Refer to the user documentation for required maintenance measures to ensure user
safety and/or preserve the specified EMC performance.
The signal pins of this product's input/output ports can be damaged if subjected to
ESD. To prevent damage, employ industry-standard ESD prevention measures during
installation, maintenance, and operation.
Table 3. General Connector Descriptions
Connector Use Connector Type
REF IN Input terminal that allows for the use of an external 10 MHz
Reference Clock.
MMPX (f)
REF OUT Output terminal that can export a 10 MHz Reference Clock. MMPX (f)
PFI 0 Programmable-function digital I/O (DIO) connector for use
with triggers or events.
MMPX (f)
DIO Multi-signal DIO connector that provides access to FPGA
multi-gigabit transceivers (MGTs) and general purpose
LVCMOS signals.
Nano-Pitch
Notice The DIO connector is not an OCuLink interface. Do not connect the DIO
connector on the PXIe-5841 to the OCuLink interface of another device. NI is not
liable for any damage resulting from such signal connections.
Table 4. RF Connector Descriptions
Connector Use Connector Type
RF OUT RF OUT Output terminal for RF signals. SMA (f)
LO IN Input terminal that allows for the use of an external
local oscillator (LO) for RF OUT.
MMPX (f)
LO OUT Output terminal for exporting the RF OUT LO
source.
MMPX (f)
RF IN LO IN Input terminal that allows the use of an external LO
for RF IN.
MMPX (f)
LO OUT Output terminal for exporting the RF IN LO source. MMPX (f)
RF OUT Input terminal for RF signals. SMA (f)
10 | ni.com | PXIe-5841 Getting Started Guide
Indice
Altri manuali National Instruments Ricetrasmettitore
National Instruments
National Instruments USRP-2920 Manuale utente
National Instruments
National Instruments USRP-2950 Manuale utente
National Instruments
National Instruments PXIe-5646R Manuale utente
National Instruments
National Instruments PXIe-5842 Manuale utente
National Instruments
National Instruments NI PXIe-5644R Manuale utente
National Instruments
National Instruments PXIe-5830 Manuale utente
National Instruments
National Instruments USRP-2900 Manuale utente
National Instruments
National Instruments PXIe-3610 Manuale utente
National Instruments
National Instruments USRP-2950 Manuale utente
National Instruments
National Instruments NI PXIe-5645R Manuale utente
