NEC NDRV-60 Manuale utente

DVD RECORDER/

VIDEO CASSETTE

RECORDER

OWNER’S MANUAL

MODEL : NDRV-60

Before connecting, operating or adjusting this product,

please read this instruction booklet carefully and completely.

CD-R/RW

PAL

Safety Precautions

This lightning flash with arrowhead symbol within an

equilateral triangle is intended to alert the user to

the presence of uninsulated dangerous voltage

within the product’s enclosure that may be of

sufficient magnitude to constitute a risk of electric

shock to persons.

The exclamation point within an equilateral triangle

is intended to alert the user to the presence of

important operating and maintenance (servicing)

instructions in the literature accompanying the

product.

WARNING: Do not install this equipment in a confined space

such as a book case or similar unit.

CAUTION:

This DVD Recorder employs a Laser System.

To ensure proper use of this product, please read this owner’s

manual carefully and retain for future reference should the unit

require maintenance, contact an authorized service location

(see service procedure).

Use of controls, adjustments, or the performance of proce

dures other than those specified herein may result in haz

ardous radiation exposure.

To prevent direct exposure to laser beam, do not try to open

the enclosure. Visible laser radiation when open. DO NOT

STARE INTO BEAM.

CAUTION: The apparatus should not be exposed to water

(dripping or splashing) and no objects filled with liquids, such

as vases, should be placed on the apparatus.

NOTES ON COPYRIGHTS:

It is forbidden by law to copy, broadcast, show, broadcast

via cable, play in public, or rent copyrighted material without

permission.

This product features the copy protection function developed

by Macrovision. Copy protection signals are recorded on some

discs. When recording and playing the pictures of these discs

on a VCR, picture noise will appear.

This product incorporates copyright protection technology that

is protected by method claims of certain U.S. patents and other

intellectual property rights owned by Macrovision Corporation

and other rights owners. Use of this copyright protection tech

nology must be authorized by Macrovision Corporation, and is

intended for home and other limited viewing uses only unless

otherwise authorized by Macrovision Corporation. Reverse

engineering or disassembly is prohibited.

SERIAL NUMBER: The serial number is found on the back of

this unit. This number is unique to this unit and not available to

others. You should record requested information here and

retain this guide as a permanent record of your purchase.

Model No.

Serial No.

WARNING: TO REDUCE THE RISK OF FIRE OR ELEC

TRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO

RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK

OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

INTRODUCTION

Table of Contents

INTRODUCTION

Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . 2

Table of Contents . . . . . . . . . . . . . . . . . . . . . . 3-4

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10

Recordable Discs . . . . . . . . . . . . . . . . . . . . . . . 5

Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . 5

Disc-related terms . . . . . . . . . . . . . . . . . . . . . . 6

• Types of video CDs . . . . . . . . . . . . . . . . . . 6

About Symbols . . . . . . . . . . . . . . . . . . . . . . . . . 6

• About the symbol display . . . . . . . . . . . . 6

• About the disc symbols for instructions . . . . 6

About DVD-R and DVD-RW disc. . . . . . . . . . . . 7

• What are ‘recording modes’? . . . . . . . . . . . 7

• Is editing a DVD like editing a video tape? . 7

• About word ‘Original’ and ‘Playlist’ . . . . . . . 7

About DVD+R and DVD+RW disc. . . . . . . . . . . 7

About DVD recording . . . . . . . . . . . . . . . . . . . . 8

• Disc types and recording formats, modes,

and settings . . . . . . . . . . . . . . . . . . . . . . . . 8

• Notes for recording. . . . . . . . . . . . . . . . . . . 8

• Restrictions on video recording. . . . . . . . . . 9

• What is ‘CPRM’? . . . . . . . . . . . . . . . . . . . . 9

• Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Remote Control Operation Range . . . . . . . . . . . 9

Remote Control Battery Installation . . . . . . . . . . 9

Reset the Recorder . . . . . . . . . . . . . . . . . . . . . 9

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 10

• Handling the unit . . . . . . . . . . . . . . . . . . . 10

• Cleaning the unit . . . . . . . . . . . . . . . . . . . 10

Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . 10

• Handling discs . . . . . . . . . . . . . . . . . . . . . 10

• Storing discs . . . . . . . . . . . . . . . . . . . . . . 10

• Cleaning discs . . . . . . . . . . . . . . . . . . . . . 10

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Function Display Window . . . . . . . . . . . . . . . . 12

Remote Control Overview . . . . . . . . . . . . . . . . 13

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

HOOKUP

Connections . . . . . . . . . . . . . . . . . . . . . . . . 15-17

Connecting to the Aerial . . . . . . . . . . . . . . . . . 15

Connections to Your TV . . . . . . . . . . . . . . . . . 15

Connecting to an Amplifier . . . . . . . . . . . . . . . 16

Accessory Audio/Video (A/V) Connections

to Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting a Digital Camcorder . . . . . . . . . . . 17

Before Operation. . . . . . . . . . . . . . . . . . . . . 18-30

Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . 18

General Operation . . . . . . . . . . . . . . . . . . . . . 18

GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . 18-22

• Auto Programming . . . . . . . . . . . . . . . . . . 18

• Program Edit . . . . . . . . . . . . . . . . . . . . 19-20

• Clock Set . . . . . . . . . . . . . . . . . . . . . . . . . 21

• TV Aspect . . . . . . . . . . . . . . . . . . . . . . . . 21

• VCR Play System. . . . . . . . . . . . . . . . . . . 21

• Progressive Scan . . . . . . . . . . . . . . . . . . . 21

• Factory Setting. . . . . . . . . . . . . . . . . . . . . 22

LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . 22

• Display Language . . . . . . . . . . . . . . . . . . 22

• Disc Language . . . . . . . . . . . . . . . . . . . . . 22

AUDIO. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-23

• Dolby Digital. . . . . . . . . . . . . . . . . . . . . . . 22

• DTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

• MPEG . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

• Sampling Frequency . . . . . . . . . . . . . . . . 23

• DRC (Dynamic Range Control). . . . . . . . . 23

• Vocal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

LOCK (Parental Control) . . . . . . . . . . . . . . 23-24

• Set Password. . . . . . . . . . . . . . . . . . . . . . 23

• Movie Rating . . . . . . . . . . . . . . . . . . . . . . 24

• Country Code. . . . . . . . . . . . . . . . . . . . . . 24

RECORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

• Disc Record Mode . . . . . . . . . . . . . . . . . . 25

• VCR Record Mode . . . . . . . . . . . . . . . . . . 25

• VCR Record System . . . . . . . . . . . . . . . . 25

• DV Record Audio . . . . . . . . . . . . . . . . . . . 25

• Auto Chapter . . . . . . . . . . . . . . . . . . . . . . 25

DISC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27

• Disc Initialize . . . . . . . . . . . . . . . . . . . . . . 26

• Disc Finalize . . . . . . . . . . . . . . . . . . . . . . 26

• Disc Label . . . . . . . . . . . . . . . . . . . . . . . . 27

• Disc Protect . . . . . . . . . . . . . . . . . . . . . . . 27

• PBC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

• Auto Play . . . . . . . . . . . . . . . . . . . . . . . . . 27

General Explanation of On-Screen Display. 28-30

• Displaying Information on-screen. . . . . 28-30

• Displaying Information While Watching TV . . 28

• Changing TV Channels . . . . . . . . . . . . . . 28

• Changing TV Audio Channel. . . . . . . . . . . 28

Table of Contents

PLAYBACK

Operation with DVD and Video CD. . . . . . . 31-34

Playing a DVD or Video CD . . . . . . . . . . . . . . 31

General Feature . . . . . . . . . . . . . . . . . . . . . . . 31

• Moving to another TITLE . . . . . . . . . . . . . 31

• Moving to another CHAPTER/TRACK . . . 31

• Search . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

•

Still Picture and Frame-by-Frame Playback

. 31

• Slow Motion . . . . . . . . . . . . . . . . . . . . . . . 32

• Random . . . . . . . . . . . . . . . . . . . . . . . . . . 32

• Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . 32

• Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . 32

• Time Search. . . . . . . . . . . . . . . . . . . . . . . 32

• Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

• Marker Search . . . . . . . . . . . . . . . . . . . . 33

• Checking the contents of

DVD Video discs: Menus . . . . . . . . . . . . . 33

• Title Menu . . . . . . . . . . . . . . . . . . . . . . . . 33

• Disc Menu . . . . . . . . . . . . . . . . . . . . . . . . 33

• Camera Angle . . . . . . . . . . . . . . . . . . . . . 33

• Changing the Audio Soundtrack . . . . . . . . 33

• Changing the Audio Channel . . . . . . . . . . 34

• 3D Surround . . . . . . . . . . . . . . . . . . . . . . 34

• Subtitles. . . . . . . . . . . . . . . . . . . . . . . . . . 34

• Finding Locations on a Disc . . . . . . . . . . . 34

• Last Condition Memory. . . . . . . . . . . . . . . 34

Audio CD and MP3/WMA Operation . . . . . . 35-36

Playing an Audio CD or MP3/WMA Disc . . . . . 35

Music menu options . . . . . . . . . . . . . . . . . . . . 35

• Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

• Moving to Another Track. . . . . . . . . . . . . . 36

• Repeat Track/All(Folder)/Off . . . . . . . . . . . 36

• Random . . . . . . . . . . . . . . . . . . . . . . . . . . 36

• Changing the Audio Channel . . . . . . . . . . 36

• Search . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

• Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . 36

Notes on MP3/WMA Recordings . . . . . . . . . 36

Programmed Playback with Audio CD and MP3/WMA

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

JPEG File Operation . . . . . . . . . . . . . . . . . . . . 38

Viewing a JPEG File . . . . . . . . . . . . . . . . . . . . 38

• Skip Image. . . . . . . . . . . . . . . . . . . . . . . . 38

• Rotate Images . . . . . . . . . . . . . . . . . . . . . 38

• View Slide Shows. . . . . . . . . . . . . . . . . . . 38

• Notes on JPEG Recordings . . . . . . . . . . . 38

VCR Mode Tape Playback . . . . . . . . . . . . . . . . 39

Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Normal Playback . . . . . . . . . . . . . . . . . . . . . . 39

• Tracking Control. . . . . . . . . . . . . . . . . . . . 39

Special Effect Playback. . . . . . . . . . . . . . . . . . 39

• Search . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

• Still Picture and Frame-by-Frame Playback . . 39

• Slow Motion . . . . . . . . . . . . . . . . . . . . . . . 39

• Counter Memory Function . . . . . . . . . . . . 39

RECORDING

Basic Recording . . . . . . . . . . . . . . . . . . . . . 40-41

Basic Recording from a TV . . . . . . . . . . . . . . . 40

Instant Timer Recording . . . . . . . . . . . . . . . . . 40

Copying from DVD to VCR . . . . . . . . . . . . . . . 41

Copying from VCR to DVD . . . . . . . . . . . . . . . 41

Timer Recording . . . . . . . . . . . . . . . . . . . . . 42-43

Checking Timer Recording Details . . . . . . . . . 43

Canceling a Timer Recording . . . . . . . . . . . . . 43

Stopping a Timer Recording in Progress . . . . . 43

Timer Recording Troubleshooting . . . . . . . . . . 43

Recording from External Input . . . . . . . . . . 44-45

Recording from External Components. . . . . . . 44

Recording from a Digital Camcorder . . . . . . . . 44

What is DV? . . . . . . . . . . . . . . . . . . . . . . . . . . 45

• DV-Related Messages . . . . . . . . . . . . . . . 45

• Troubleshooting . . . . . . . . . . . . . . . . . . . . 45

EDITING

Title List and Chapter List Menu . . . . . . . . 46-50

Using the Title List-Original menu . . . . . . 46

Using the Chapter List-Original menu . . . 46

Using the Title List-Playlist menu . . . . . . 47

Using the Chapter List-Playlist menu . . . 47

Using the Title List menu . . . . . . . . . . . . 48

• Deleting a Title . . . . . . . . . . . . . . . . . . . . . 48

• If the disc has already been finalized . . . . 48

Using the Title List menu . . . . . . . . . . . . 49

Using the Chapter List menu . . . . . . . . . 49

Using the Title List menu . . . . . . . . . . . . 50

Using the Chapter List menu . . . . . . . . . 50

Title and Chapter Editing . . . . . . . . . . . . . . 51-56

Titles, Chapters and Parts. . . . . . . . . . . . . . . . 51

Adding Chapter Markers . . . . . . . . . . . . . . . . . 51

Changing Title Thumbnails . . . . . . . . . . . . . . . 51

Making a New Playlist. . . . . . . . . . . . . . . . . . . 52

Adding Additional Title/Chapters to the Playlist 52

Deleting a Title/Chapter . . . . . . . . . . . . . . . . . 53

Deleting a Part . . . . . . . . . . . . . . . . . . . . . . . . 53

Naming a Title . . . . . . . . . . . . . . . . . . . . . . . . 54

Combining Two Chapters Into One . . . . . . . . . 54

Moving a Playlist Chapter . . . . . . . . . . . . . . . . 55

Protect a Title . . . . . . . . . . . . . . . . . . . . . . . . . 55

Hide a Title/Chapter . . . . . . . . . . . . . . . . . . . . 56

Divide One Title Into Two . . . . . . . . . . . . . . . . 56

Additional Information . . . . . . . . . . . . . . . . . . . 57

Clean-up Recording . . . . . . . . . . . . . . . . . . . . 57

Overwrite Recording . . . . . . . . . . . . . . . . . . . . 57

Viewing Title List menu displayed on other

DVD recorders or players . . . . . . . . . . . . . . . . 57

Playing Your Recordings on other

DVD Players (Finalizing a Disc) . . . . . . . . . . . 57

REFERENCE

Language Code List. . . . . . . . . . . . . . . . . . . . . 58

Country Code List . . . . . . . . . . . . . . . . . . . . . . 59

Troubleshooting . . . . . . . . . . . . . . . . . . . . . 60-61

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 62

About the symbols for instructions

Indicates hazards likely to cause harm to the unit

itself or other material damage.

Indicates special operating features of this unit.

Indicates tips and hints for making the task easier.

+RW

Video

INTRODUCTION

Overview

Recordable Discs

DVD-RW (Digital Video Disc - ReWritable):

These Discs can be recorded on repeatedly.

Recordings can be erased, then you can

record again on the same Disc.

DVD-R (Digital Video Disc - Recordable):

These Discs can be recorded only once.

After you finalize a DVD-R, you cannot

record on it or edit it any more.

DVD+RW (Digital Video Disc + ReWritable):

These Discs can be recorded on repeatedly.

Recordings can be erased, then you can

record again on the same Disc.

DVD+R (Digital Video Disc + Recordable):

These Discs can be recorded only once.

After you finalize a DVD+R, you cannot

record on it or edit it any more.

otes

– This recorder cannot record CD-R or CD-RW discs.

– DVD-R/RW, DVD+R/RW and CD-R/RW discs record-

ed using a personal computer or a DVD or CD

recorder may not play if the disc is damaged or dirty,

or if there is dirt of condensation on the recorder’s

lens.

– If you record a disc using a personal computer, even

if it is recorded in a compatible format, there are

cases in which it may not play because of the settings

of the application software used to create the disc.

(Check with the software publisher for more detailed

information.)

– The company does not hold any responsibility to

compensate the contents which should have been

recorded, and any losses or damages (e.g. losses of

business profit, or business intermission) that may

arise from malfunction of this recorder (not record-

ing/editing as intended).

Problems arising in the following situations are included.

• When a DVD disc recorded on this recorder is used

in a DVD recorder of another manufacturer, or used

(insertion, playback, recording or editing) in a

personal computer DVD drive.

• When a DVD that has been used as above is used

again in this recorder.

• When a DVD disc recorded in a DVD recorder of

another manufacturer, or in a personal computer

DVD drive is used.

Playable Discs

DVD

(8 cm/12 cm disc)

Video CD (VCD)

(8 cm / 12 cm disc)

Audio CD

(8 cm/12 cm disc)

In addition, this unit can play DVD-R/DVD-RW discs;

DVD+R/DVD+RW discs; CD-R/CD-RW discs that

contain audio titles, MP3 files, WMA files, or JPEG files;

SVCD; and kodak picture CDs.

otes

– Depending on the conditions of the recording equip-

ment or the CD-R/RW (or DVD±R/±RW) disc itself,

some CD-R/RW (or DVD±R/±RW) discs cannot be

played on the unit.

– Do not attach any seal or label to either side (the

labeled side or the recorded side) of a disc.

–

Do not use irregularly shaped CDs (e.g., heart-shaped

or octagonal). Doing so may result in malfunctions.

Regional code of the DVD Recorder and DVDs

This DVD Recorder is designed and manufac-

tured for playback of Region 4 encoded DVD

software. The region code on the labels of some DVD

discs indicates which type of DVD Recorder can play

those discs. This unit can play only DVD discs labeled 4

or ALL. If you try to play any other discs, the message

“Incorrect region code. Can’t play back” will appear on

the TV screen. Some DVD discs may not have a region

code label even though their playback is prohibited by

area limits.

otes on DVDs and Video CDs

Some playback operations of DVDs and Video CDs

may be intentionally fixed by software manufacturers.

As this unit plays DVDs and Video CDs according to

disc content designed by the software manufacturer,

some playback features of the unit may not be available

or other functions may be added.

Refer also to the instructions supplied with the DVDs

and Video CDs. Some DVDs made for business pur-

poses may not be played on the unit.

Overview (Continued)

Disc-related terms

Title (DVD only)

The main film content or accompanying feature content

or music album.

Each title is assigned a title reference number enabling

you to locate it easily.

Chapter (DVD only)

Sections of a picture or a musical piece that are smaller

than titles. A title is composed of one or several chap-

ters. Each chapter is assigned a chapter number to

enable you to locate the chapter you want. Depending

on the disc, chapters may not be labeled.

Track (Video CD and audio CD only)

Sections of a picture or a musical piece on a video CD

or an audio CD. Each track is assigned a track number,

enabling you to locate the track you want.

Scene

On a video CD with PBC (Playback control) functions,

moving pictures and still pictures are divided into sec-

tions called “Scenes”. Each scene available is displayed

on the Scene menu and assigned a scene number,

enabling you to locate the scene you want.

A scene may be composed of one or several tracks.

Types of video CDs

There are two types of video CDs:

Video CDs equipped with PBC (Version 2.0)

PBC (Playback control) functions allow you to interact

with the system via menus, search functions, or other

typical computer-like operations. Moreover, high resolu-

tion still pictures can be played if they are included on

the disc.

Video CDs not equipped with PBC (Version 1.1)

Operated in the same way as audio CDs, these discs

allow playback of video pictures as well as sound, but

they are not equipped with PBC.

About Symbols

About the symbol display

“ ” may appear on the TV screen during operation.

This icon means the function explained in this owner’s

manual is not available on that specific disc.

About the disc symbols for instructions

A section whose title has one of the following symbols

are applicable only to those discs represented by the

symbol.

Many functions of this recorder are dependent on the

recording mode. One or more of the symbols

( , , , ) appear by each

function explained in this manual so that you can see at

a glance whether it’s relevant for the disc loaded.

DVD-R/RW with Video recording mode

DVD-RW with VR recording mode

DVD+R disc

DVD+RW disc

DVD-Video disc

Video CDs

Audio CDs

MP3 CDs

JPEG CDs

VHS Tape.

The finalized DVD disc is as DVD-Video disc

VHS

JPEG

MP3

VCD

DVD

+RW

Video

+RW+RVR

Video

INTRODUCTION

Overview (Continued)

About DVD-R and DVD-RW disc

How are DVD-R and DVD-RW discs different?

The essential difference between DVD-R and DVD-RW

is that DVD-R is a record-once medium, while DVD-RW

is a re-recordable/erasable medium. You can re-record/

erase a DVD-RW disc approximately 1,000 times.

Can I play my recordable discs in a regular DVD

player?

Generally, DVD-R discs and DVD-RW discs recorded in

Video mode are playable in a regular DVD player, but

they must be ‘finalized’ first. This process fixes the con-

tents of the disc to make them readable to other DVD

players as DVD-Video discs.

DVD-RW discs recorded in VR (Video Recording) mode

are playable in some players.

This indicates a product feature that is capa-

ble of playing DVD-RW discs recorded with

Video Recording format.

What are ‘recording modes’?

There are two recording modes available using this

recorder: VR mode and Video mode. When recording to

a DVD-R disc, recordings are always in Video mode.

DVD-RW discs can be formatted for VR mode recording

or Video mode recording.

VR mode recording

• 4 different picture quality/recording time settings avail-

able (XP, SP, LP, EP)

• Not playable on regular DVD players

• Recordings can be extensively edited

Video mode recording

• 4 different picture quality/recording time settings avail-

able (XP, SP, LP, EP)

• Playable on regular DVD players (after finalizing)

• Limited editing features

ote

DVD-Video Format (Video mode) is a new format for

recording on DVD-R/RW and DVD+R/RW discs that

was approved by the DVD Forum in 2000. You may

therefore experience problems playing recordable DVD

discs in some players. Symptoms include video arti-

facts, audio and/or video dropouts and playback sud-

denly stopping.

Our company cannot take responsibility for problems

playing discs recorded on this recorder in other players.

Is editing a DVD like editing a video tape?

No. When you edit a video tape you need one video

deck to play the original tape and another to record the

edits. With DVD, you edit by making a ‘Playlist’ of what

to play and when to play it. On playback, the recorder

plays the disc according to the Playlist.

About word ‘Original’ and ‘Playlist’

Throughout this manual, you will often see the words

Original and Playlist to refer to the actual content and

the edited version.

•Original: content refers to what’s actually recorded

on the disc.

•Playlist: content refers to the edited version of the

disc — how the Original content is to be played.

About DVD+R and DVD+RW disc

How are DVD+R and DVD+RW discs different?

The essential difference between DVD+R and DVD+RW

is that DVD+R is a record-once medium, while

DVD+RW is a re-recordable/erasable medium. You can

re-record/ erase a DVD+RW disc approximately 1,000

times.

DVD+RW mode recording

• 4 different picture quality/recording time settings avail-

able (XP, SP, LP, EP)

• Playable on regular DVD players

• The edited contents is playable on regular DVD play-

ers only after finalizing

• Recordings can be edited the title/chapter

DVD+R mode recording

• 4 different picture quality/recording time settings avail-

able (XP, SP, LP, EP)

• Playable on regular DVD players (after finalizing)

• Any edited contents are not be compatible on regular

DVD players. (Hide, chapter combine, added chapter

mark, etc.)

• Limited title/chapter editing features

Overview (Continued)

About DVD recording

otes

• This recorder cannot make recordings on CD-R or

CD-RW discs.

• Our company takes no responsibility for recording fail-

ure due to power cuts, defective discs, or damage to

the recorder.

• Fingerprints and small scratches on a disc can affect

playback and/or recording performance. Please take

proper care of your discs.

Disc types and recording formats, modes,

and settings

This recorder can play five different kinds of DVD disc:

pre-recorded DVD-Video discs, DVD-RW, DVD-R,

DVD+RW and DVD+R discs. The disc format for DVD-R

discs is always “Video format”—the same as pre-record-

ed DVD-Video discs. This means that once finalized,

you can play a DVD-R in a regular DVD player.

By default, the DVD-RW disc format is Video Recording

format, though you can change this to Video format, if

required. (Reinitializing the disc will erase the contents

of the disc.)

The recording mode is closely related to the disc for-

mat. If the disc format is Video Recording format, then

the recording mode is VR mode; if the disc format is

Video mode, then the recording mode is Video mode

(except for DVD-Video, which is not recordable, and so

does not have a recording mode).

Within the recording modes (which are fixed for the

whole disc) are the record settings. These can be

changed as required for each recording and determine

the picture quality and how much space the recording

will take up on the disc.

Notes for recording

• The recording times shown are not exact because the

recorder uses variable bit-rate video compression.

This means that the exact recording time will depend

on the material being recorded.

• When recording a TV broadcast, if the reception is

poor or the picture contains interference, the record-

ing times may be shorter.

• If you record still pictures or audio only, the recording

time may be longer.

• The displayed times for recording and time remaining

may not always add up to exactly the length of the

disc.

• The recording time available may decrease if you

heavily edit a disc.

• If using a DVD-RW disc, make sure you change the

recording format (Video mode or VR mode) before

you record anything on the disc. See page 26 (Disc

Initialize) for how to do this.

• When using a DVD-R disc, you can keep recording

until the disc is full, or until you finalize the disc.

Before you start a recording session, check the

amount of recording time left on the disc.

• When using a DVD-RW disc in Video mode, recording

time available will only increase if you erase the last

title recorded on the disc.

• The Erase Title option in the Title List-Original menu

only hides the title, it does not actually erase the title

from the disc and increase the recording time avail-

able (except for the last recorded title on a DVD-RW

disc in Video mode).

• The overwrite recording is available with DVD+RW

disc.

Disc type Disc format Recording mode Functions

DVD-Video Video format n/a Playback only

DVD-RW Video Recording VR mode Playback, recording, Original/Playlist editing

format (default)

Video format Video mode Playback, limited recording, limited editing

DVD-R Video format Video mode Playback, limited recording, limited editing

DVD+RW +RW Video format DVD+RW Playback, limited recording, Title/Chapter editing

DVD+R +R Video format DVD+R Playback, limited recording, limited Title/Chapter editing

INTRODUCTION

Overview (Continued)

Restrictions on video recording

• You cannot record copy-protected video using this

recorder. Copy-protected video includes DVD-Video

discs and some satellite broadcasts. If copy-protected

material is encountered during a recording, recording

will pause or stop automatically and an error message

will be displayed on-screen.

• Video that is ‘copy-once only’ can only be recorded

using a DVD-RW disc in VR mode with CPRM (see

below).

• NTSC format signals from the analog or the DV

inputs is not recorded correctly with this recorder.

• Video signals in SECAM format (from the built-in TV

tuner or from the analog inputs) are recorded in PAL

format.

What is ‘CPRM’?

CPRM is a copy protection system (with scramble sys-

tem) only allowing the recording of ‘copy once’ broad-

cast programs. CPRM stands for Content Protection for

Recordable Media.

This recorder is CPRM compatible, which means that

you can record copy-once broadcast programs, but you

cannot then make a copy of those recordings. CPRM

recordings can only be made on DVD-RW discs format-

ted in VR mode, and CPRM recordings can only be

played on players that are specifically compatible with

CPRM.

• Recording equipment should be used only for lawful

copying and you are advised to check carefully what

is lawful copying in the country in which you are mak-

ing a copy. Copying of copyright material such as

films or music is unlawful unless permitted by a legal

exception or consented to by the rights owner.

• This product incorporates copyright protection tech-

nology that is protected by method claims of certain

U.S. patents and other intellectual property rights

owned by Macrovision Corporation and other rights

owners. Use of this copyright protection technology

must be authorized by Macrovision Corporation, and

is intended for home and other limited viewing uses

only unless otherwise authorized by Macrovision cor-

poration. Reverse engineering or disassembly is pro-

hibited.

• CONSUMERS SHOULD NOTE THAT NOT ALL HIGH

DEFINITION TELEVISION SETS ARE FULLY COM-

PATIBLE WITH THIS PRODUCT AND MAY CAUSE

ARTIFACTS TO BE DISPLAYED IN THE PICTURE.

IN CASE OF 625 PROGRESSIVE SCAN PICTURE

PROBLEMS, IT IS RECOMMENDED THAT THE

USER SWITCH THE CONNECTION TO THE

‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE

QUESTIONS REGARDING OUR TV SET COMPATI-

BILITY WITH THIS MODEL 625p RECORDER,

PLEASE CONTACT OUR CUSTOMER SERVICE

CENTER.

Remote Control Operation Range

Point the remote control at the remote sensor and press

the buttons.

Remote Control Battery Installation

Detach the battery cover on the rear of

the remote control, and insert two R03

(size AAA) batteries with and

aligned correctly.

Caution

Do not mix old and new batteries. Never mix different

types of batteries (standard, alkaline, etc.).

Reset the Recorder

If you observe any of the following symptoms...

The front panel display is not working.

The Recorder is not operating normally.

...you can reset the Recorder as follows:

Press and hold the OPERATE button for at least five

seconds. This will force the unit to power off.

Press the OPERATE button again to turn the unit

back on.

Unplug the power cord, wait at least five seconds,

and then plug it in again.

Overview (Continued)

Precautions

Handling the unit

When shipping the unit

The original shipping carton and packing materials

come in handy. For maximum protection, re-pack the

unit as it was originally packaged at the factory.

When setting up the unit

The picture and sound of a nearby TV, VCR, or radio

may be distorted during playback. In this case, position

the unit away from the TV, VCR, or radio, or turn off the

unit after removing the disc.

To keep the surface clean

Do not use volatile liquids, such as insecticide spray,

near the unit. Do not leave rubber or plastic products in

contact with the unit for a long period of time. They will

leave marks on the surface.

Cleaning the unit

To clean the cabinet

Use a soft, dry cloth. If the surfaces are extremely dirty,

use a soft cloth lightly moistened with a mild detergent

solution. Do not use strong solvents such as alcohol,

benzine, or thinner, as these might damage the surface

of the unit.

To obtain a clear picture

The Recorder is a high-tech, precision device. If the

optical pick-up lens and disc drive parts are dirty or

worn, the picture quality will be poor.

Regular inspection and maintenance are recommended

after every 1,000 hours of use. (This depends on the

operating environment.)

For details, please contact your nearest dealer.

Notes on Discs

Handling discs

Do not touch the playback side of the disc. Hold the

disc by the edges so that fingerprints will not get on the

surface. Do not stick paper or tape on the disc.

Storing discs

After playing, store the disc in its case.

Do not expose the disc to direct sunlight or sources of

heat, or leave it in a parked car exposed to direct sun-

light, as there may be a considerable temperature

increase inside the car.

Cleaning discs

Fingerprints and dust on the disc can cause poor pic-

ture quality and sound distortion. Before playing, clean

the disc with a clean cloth. Wipe the disc from the cen-

ter outward.

Do not use strong solvents such as alcohol, benzine,

thinner, commercially available cleaners, or anti-static

spray intended for older vinyl records.

NoYes
