NEC Display Solutions of America, Inc.

Whitepaper

Projector Placement Comparison Ver. 2.4

www.necdisplay.com PJ Placement Page 1 of 2

Ceiling Mounted Installation

This is a reference to compare placement between the different models.

The ability to hang a projector higher is usually desired;

this drawing allows you to see the height each model needs to be mounted at for a 100" screen.

All the projectors are placed at the proper height (using 100" screen) and are within the zoom range for that lens.

Note: All projectors shown at the middle point of their respective zoom range.

WT610E

Ceiling

100" Diagonal Screen

Top

Center

Bottom

Orange = LT280/LT380

Green = VT49

w/Standard Lens

Lens shift Lens shift

w/NP03ZL Lens

Color Chart

NP40

NP50

NP60

Red = VT490/VT590/VT595/VT695/VT700

NP08ZL

Lens shift

Blue = NP1000/NP2000/NP3150

Brown = NP4000/NP4001

NEC Display Solutions of America, Inc.

Whitepaper

Projector Placement Comparison Ver. 2.4

www.necdisplay.com PJ Placement Page 1 of 2

Orange = LT280/LT380

Green = VT49

Color Chart

Red = VT490/VT590/VT595/VT695/VT700

Desktop

This is a reference to compare placement between the different models.

The ability to place a projector low on a cart or table is usually desired;

this drawing allows you to see the height each model needs to be placed at.

All the projectors are placed at the proper height (using 100" screen) and are within the zoom range for that lens.

Note: All projectors shown at the middle point of their respective zoom range.

WT610E

Ceiling

100" Diagonal Screen

Top

Center

Bottom

w/Standard Lens NP40

NP50

NP60

Blue = NP1000/NP2000/NP3150

Brown = NP4000/NP4001

NP08ZL
