NEC AT55 Quick User Guide

Last Number Redial

The last telephone number dialled (up to 32 digits) can be redialled by pressing the

redial key. You can re-dial the same telephone number as many times as required.

However, once you dial another number, the previous number is erased.

Answer Calls

You can answer calls using the handset, speakerphone, or a headset. To answer a call

do one of the following:

• To answer with the handset, lift the handset when the phone rings.

• To answer with the speakerphone, press the speaker key when the phone rings.

Call Indicator /

Message Waiting Lamp

LCD Screen

Search Key

Programmable Keys

Dial Pad

Volume Keys

Delete Key

In Use Key

PBX Dial/Set Time Key

Flash/Pause Key

Redial Key

Mute Key

Speaker Key

Hold Key

Microphone Mute

Call Hold

The Mute Key allows you to switch o the handset and speakerphone microphone

temporarily.

To mute the call so that the called party cannot hear you, press the Mute Key and the

Mute LED will light up.

To cancel mute and resume normal conversation, press the Mute Key again and the LED

light will go out.

A call in progress may be placed on hold at the telephone by pressing the hold key.

When the hold key is pressed, the call remains on the telephone, and both parties hear

the hold melody until the call is retrieved.

There are two separate melodies for the hold function. To select the desired melody,

follow these steps:

• Ensure the phone is idle

• Dial * 5 *

• Dial 0 or 1 to select the desired melody

• Dial #. The selected melody will be plated for approximately 6 seconds.

Memory Redial

The last 30 telephone numbers dialled (up to 21 digits each) are stored in the Outgoing

Call Memory. To dial from Outgoing Call Memory:

• Press the search key until the OUT icon is shown on display, advance up or down to

the search number you wish to dial by pressing the volume keys

• When the desired number is displayed, press the PBX dial key, speaker key, or lift

the handset.
