NetComm NP2005HS Manuale utente

10/100Mbps AUTO-NEGOTIATION ETHERNET SWITCH

• 5 x 10/100Mbps Ethernet ports

• Simple Plug & Play

• Automatically detects and sets optimum data rate

• Store & Forward technology

• Windows®95/98/2000/Me/ P, Linux, MacOS 8/9/

NetComm Limited, ABN 85 002 490 486 • PO Box 1200, Lane Cove NSW 2066 Australia.

PHONE (02) 9424 2070 • FAX (02) 9424 2010 • EMAIL [email protected] • ..nneettccoommmm..ccoomm..aauu

Trademarks and registered trademarks are the property

of NetComm Limited or their respective o ners.

Specifications are subject to change ithout notice.

Product Code: NP2005HS

Build or extend a local Ethernet network with this Plug & Play network switch

for Windows®95/98/ P/ME/2000; Linux and MacOS 8/9/ .

Automatically detects and sets the optimum data rate.

Store & Forward technology ensures high-performance and error-free transfers.

Key Features

• 5 x 10/100Mbps Auto-Negotiation Ethernet ports

• Supports Auto-MDI/MDI-

• Full/half duplex transfer mode for each port

• Wire speed reception and transmission

• Integrated address Look-Up Engine, supports

2K absolute MAC addresses

• Store & Forward switching method

• Supports 128KBytes RAM for data buffering

• Comprehensive front-panel diagnostic LEDs

• Broadcast storm protection

• IEEE 802.3x flow control for full-duplex

• Back pressure flow control for half-duplex

Specifications

Standard

IEEE 802.3 10BASE-T

IEEE 802.3 100BASE-TX

Network Media

Ethernet: UTP Cat. 3,4,5

Fast Ethernet: UTP Cat. 5

Protocol CSMA/CD

Topolog Star

Number of Ports

5 x 10/100Mbps Auto-MDIX ith

RJ-45 connector

Network Data Transfer Rate

ETHERNET:10Mbps (HALF-DUPLEX)

20Mbps (FULL-DUPLEX)

FAST ETHERNET:100Mbps (HALF-DUPLEX)

200Mbps (FULL-DUPLEX)

Diagnostic LEDs

PER UNIT: Po er(1Green LED)

PER PORT: Link/Activity

SPEED (100Mbps)

Data RAM Buffers

128KBytes per device

Filtering Address Table

2K entries per device

Power Adaptor

7.5VDC/1A

Power Consumption

4atts. (max.)

Dimensions

125 (w) x70 (d) x 30 (h)

Temperature

OPERATING: 0~ 40C

STORAGE: -10 ~ 70C

Humidit

OPERATING: 10% ~ 90% RH

STORAGE: 5% ~ 90% RH

Emission

FCC Class B, CE mark Class B,

VCCI-B. C-Tick (N367)

Package Contents

NetComm NP2005HS 5-Port SmartSwitch

Power Pack

1YEAR

WARR ANT Y

CONDITIONS APPLY

NetComm is Australia’s own data

communications and networking

solutions provider. For more information

on this and other NetComm products,

please visit www.netcomm.com.au
