NETGEAR FA511 - 32-bit CardBus PC Card Mobile Manuale utente

NETGEAR’s 10/100 dual-speed CardBus Ethernet PC Card is a 32-bit,

high-performance adapter that allows any CardBus-equipped computer to

connect to an Ethernet or Fast Ethernet network.

Model FA511 supports hot-swapping, allowing you to insert and remove it as

necessary, without having to turn off or reset your PC.With a compact,

dongle-free design, Plug-and-Play simplicity, and PCI-like performance, the

Model FA511 unleashes the power of today's notebook PCs, allowing you to

keep pace with demanding applications and advanced desktop technologies.

CARDBUS SUPPORT

CardBus is a 32-bit bus-mastering architecture that operates at PCI local-bus speeds of

up to 33 MHz, yielding a peak bandwidth of 132 MB/sec. Unlike 16-bit PC Cards, which

operate at slower ISA bus speeds of 8 MHz using an ISA-like asynchronous protocol,

CardBus provides a fast 32-bit multiplexed address/data path that allows full access to

Fast Ethernet's bandwidth.

By utilizing internal bus speeds, CardBus can operate at speeds six times faster than a 16-

bit PC Card and five times faster than a 100 Mbps PC Card. In addition, CardBus PC

cards operate at 3.3 Volts, saving power and conserving your PC’s battery life.

BUS-MASTERING CAPABILITY

Model FA511 features leading-edge bus-mastering capabilities to optimize throughput

while maintaining low CPU utilization. Bus mastering allows the FA511 to assume control

of your PC’s system bus, accelerating data transfers. 16-bit PC Cards, by comparison, act

as a bus slave and pass data through the CPU before sending it to the host system.This

slows data transfers and strain your PC’s processor.

LOW VOLTAGE

The Model FA511 consumes a low 3.3 Volts of power. Low power consumption prolongs

your PC’s battery life, which allows you to run your PC longer without needing to

recharge it or use a power supply.

ROBUST

Designed specifically to harness the power of the latest networking technology with

32-bit ,10/100 performance.

SIMPLE TO USE

Plug and Play makes installation a snap.

Connect your notebook PC to

everything on your network

FA511

Help is there when you need it!

NETGEAR provides free, 24x7

telephone and e mail technical

support in English, with selected

local language support during

office hours.

www.NETGEAR.com

CardBus Mobile Adapter

10/100 Mbps

NETGEAR Inc.

4500 Great America Parkway

Santa Clara, CA 95054

USA

Phone: 1-888-NETGEAR

E-mail: [email protected]

www.NETGEAR.com

In-Country Phone Support

(24x7 phone support in English, local language support during ofﬁce hours.) NETGEAR® is a registered

trademark of NETGEAR, Inc. in

the United States and other

countries. Windows® is a

registered trademark of Microsoft

Corporation. Other brand and

product names are trademarks or

registered trademarks of their

respective holders. Information is

subject to change without notice.

www.NETGEAR.com

Maximum length = 100 meters (300 feet)

Category 5 UTP cables

Model FA411 or

Model FA511

network card

Power adapter

PC with FA311

network card

installed Notebook PC

RJ-45

connector

EN104TP Hub

Korea 00308-11-0319

Netherlands 0800-023-0981

New Zealand 00800-1233-4566

Norway 800-12041

Singapore 001-800-1233-4566

Sweden 0200-298-298

Switzerland 00800-0638-4327

(00800-0-NETGEAR)

United Kingdom 020-7216-0014

United States 1-888-NETGEAR

All Other Countries +1 801-236-8499

Australia 1800-787-638

Austria 00800-06384327

(00800-0-NETGEAR)

Denmark 808-82179

Canada 1-888-NETGEAR

Finland 0800-111-036

France 0800-77-17-53

Germany 00800-06384327

(00800-0-NETGEAR)

Hong Kong 001-800-1233-4566

Japan 0120-66-5402

TECHNICAL SPECIFICATIONS

Dimensions

W 111.3mm (4.38”)

D 54.0mm (2.13”)

H 14.2mm (0.56”)

Weight

55g (1.94 oz)

Physical Specifications

Operating temperature:

0 to 55˚C

Humidity:

10 to 90%, noncondensing

Power Consumption

0.5 W (max.)

Warranty

5 years

Standards Compliance

IEEE 802.3u 100BASE-TX Fast Ethernet

IEEE 802.3i 10BASE-T Ethernet

Support auto-negotiation

IRQ

Automatically assigned by Plug and Play system

Media Interface

RJ-45

Network Data Transfer Rate

10 Mbps Ethernet

100 Mbps Fast Ethernet

Network Media

10BASE-T – UTP Category 3,4,5

100BASE-TX – UTP Category 5,

EIA/TIA 568 100ohm

shielded twisted pair

PACKAGE CONTENTS

CardBus Fast Ethernet Mobile Adapter

Installation manual

Installation CD-ROM

Support Information Card

DRIVERS PROVIDED

Microsoft Windows

Windows for Workgroups 3.11

Windows NT v4.0/2000

Windows 95/98/Me

Novell NetWare

Client for DOS/Windows (16 bit)

Others

Linux (Red Hat) 6.0, 6.1, 6.2, 7.0

NDIS 2.0 for DOS

•

ISO-9000

REGISTERED

QUALITY

D-FA511-001
