NETGEAR EX2700 Manuale utente

Installation

N300 WiFi Range Extender

Model EX2700

Getting Started

The NETGEAR WiFi Range Extender increases the distance of a WiFi

network by boosting the existing WiFi signal and enhancing the overall

signal quality over long distances. An extender repeats the signals from an

existing WiFi router or access point.

Existing WiFi

Sometimes your router

does not provide the WiFi

coverage you need.

WiFi Range

Extender

Boosts the range of your

existing WiFi and creates

a stronger signal in

hard-to-reach areas.

Meet Your Extender

Before you install your extender, familiarize yourself with its LEDs,

buttons, and port.

Router

Link

LED

Device

Link

LED

Power LED

WPS LED

Power On/O

button

WPS button

Factory Reset

button

Ethernet port

LED Descriptions

Router Link LED This LED indicates the connection between the extender and

the router or access point.

Solid green. Best connection.

Solid amber. Good connection.

Solid red. Poor connection.

O. No connection.

Device Link LED This LED indicates the connection between the extender and

a computer or mobile device.

Solid green. Best connection.

Solid amber. Good connection.

Solid red. Poor connection.

O. No connection.

Power LED Solid amber. The extender is booting.

Solid green. The extender is powered on.

O. The extender is powered o.

WPS LED Solid green. WiFi security is enabled (WPA or WPA2).

Blinking green. A WPS connection is being established.

O. WiFi security is not enabled.

Note: If the Router Link LED or Device Link LED is amber or red, see Find

the Best Location on page 10.

Install the WiFi Extender

Place the extender, apply power, and connect it to your WiFi network.

Place the Extender and Apply Power

1. Place your extender in the same room as your WiFi router.

Proximity to the WiFi router is required only during the initial setup

process.

2. Plug the extender into an electrical outlet.

The Power LED lights green. If the Power LED does not light, press the

Power button.

Connect to an Existing WiFi Network

To extend the range of your WiFi network, you must connect the extender

to your existing WiFi network. You can do this in one of two ways:

• Connect with WPS. For more information, see Connect with WPS on

page 6.

• Connect with web browser setup. For more information, see

Connect with Web Browser Setup on page 7.

Connect with WPS

Wi-Fi Protected Setup (WPS) lets you join a secure WiFi network without

typing the network name and password.

Note: WPS does not support WEP network security. If you are using WEP

security, follow the instructions in Connect with Web Browser Setup on

page 7.

1. Press the WPS button on the side panel of the extender.

The WPS LED blinks.

2. Within two minutes, press the WPS button on your router or access

point.

The WPS LED on the extender lights solid green, the Router Link LED

lights, and the extender connects to your existing WiFi network.

If the Router Link LED does not light, try again. If it still does not light,

see Connect with Web Browser Setup on page 7.

3. Find the new extender network name.

The extender’s wireless network name (SSID) changes to your existing

WiFi network name, with _EXT at the end of the name, for example:

• Existing WiFi network name. MyNetworkName

• New extended network name. MyNetworkName_EXT

4. Connect your WiFi devices to the new extender network.

Use the same WiFi password that you use for your WiFi router.

5. Unplug the extender and move it to a new location closer to the area

with a poor WiFi signal.

The location that you choose must be within the range of your

existing WiFi router network.

6. Plug the extender into an electrical outlet.

The Power LED lights green. If the Power LED does not light, press the

Power button.

7. Use the Router Link LED on the front panel to help you choose a spot

where the extender-to-router connection is optimal.

Connect with Web Browser Setup

1. Use a WiFi network manager on a computer or mobile device to ﬁnd

and connect to the NETGEAR_EXT (SSID) WiFi network.

Aer the connection with the computer or mobile device is

established, the Device Link LED lights.

2. Open a web browser window from the same computer or mobile

device.

The browser takes you directly to the NETGEAR genie Smart Setup.

If you are not automatically directed to NETGEAR genie, launch a web

browser and type www.mywiﬁext.net in the address ﬁeld. Enter

admin for the user name and password for the password.

3. Select a WiFi network to extend and click the Continue button.

4. Type the network password (also called passphrase or security key) in

the Password ﬁeld, and click the Continue button.

5. In the Name ﬁeld, type the name (SSID) for your new extender WiFi

network and click the Continue button.

You can use the same security settings as your existing network by

selecting the check box.

The settings are applied and the following screen displays.

On iPads, iPhones, and MacBook computers, this screen automatically

closes.

6. Use a WiFi network manager on the computer or mobile device to

connect to the extender’s newly created WiFi network.

Repeat this step for all of your computers and mobile devices.

7. If the screen is still displayed on your computer or device, select the

check box at the bottom of the screen and click the Continue button.

8. Unplug the extender and move it to a new location closer to the area

with a poor WiFi signal.

The location that you choose must be within the range of your

existing WiFi router network.

9. Plug the extender into an electrical outlet.

The Power LED lights green. If the Power LED does not light, press the

Power button.

Use the Router Link LED to help you choose a spot where the

extender-to-router connection is optimal.

Find the Best Location

If the WiFi signal is weak, the ﬁrst time you join the extender network, the

Router Link LED or Device Link LED is amber or red. If this happens, adjust

the position of the extender.

• If the Router Link LED is amber or red, move the extender closer to

the router.

• If the Device Link LED is amber or red, move the computer or mobile

device closer to the extender.
