NETGEAR EX6200 Manuale utente

Do More

Learn more about your EX6200

Contents

Experience Next-Generation WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Optimize Your WiFi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Share Files Across Your Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Boost Your Video Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connect Ethernet-Enabled Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connect a Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Change Your Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

FAQ. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Experience Next-Generation WiFi

Your new WiFi extender supports the 802.11ac networking

standard. This new standard offers better speed, improved

reliability, and more range than older WiFi networking standards.

Your extender is backward compatible with prior WiFi standards.

However, to get the benefits of 802.11ac, your router must

support the 802.11ac WiFi networking standard.

To learn more about the 802.11ac WiFi networking standard, visit

http://www.netgear.com/landing/80211ac/.

Optimize Your WiFi

The NETGEAR WiFi Analytics app provides detailed information to

help you optimize your WiFi home network. To install the app, visit

the Google Play store or scan the QR code.

The WiFi Analytics app provides the following:

•Network status. Get an overview of all available WiFi

networks, including signal strength, channel, security protocol,

MAC address, and more.

•Channel interference. Identify crowded and clear WiFi

channels and get channel connection recommendations.

•Signal strength. Determine the data rate available in various

locations in your home.

Share Files Across Your Network

You can share data that is stored on most common USB storage

devices across your network with ReadySHARE® USB Storage

Access.

USB 3.0 port

To access data from a Windows device:

1. Connect a supported USB storage device to the USB port on

your extender.

2. Select Start > Run, enter \\readyshare in the pop-up window,

and click the OK button.

To access data from a Mac OS X device:

1. Connect a supported USB storage device to the USB port on

your extender.

2. In Finder, select Go > Connect to Server, enter smb:// in the

pop-up window’s Server Address field, and click the Connect

button.

To change the ReadySHARE folder name on the extender:

If you have a NETGEAR router that supports ReadySHARE, the

router’s default ReadySHARE folder name is \\readyshare. The

extender’s default ReadySHARE folder name is also

\\readyshare. You can change the extender’s default

ReadySHARE folder name so that you can tell the folders apart.

1. Open a browser on your laptop, tablet, or smartphone and visit

www.mywifiext.net.

2. Log in using the following credentials:

•User name. admin

•Password. password

3. Select USB Storage > Advanced Settings.

The USB Storage (Advanced Settings) screen displays.

4. In the Network/Device Name field, type a new name.

Note: After you change the network/device name, the folder name

also changes.

5. Click on the Apply button.

Your changes are saved.

Boost Your Video Streaming

Get the most out of your HD entertainment with FastLane™

Technology. FastLane Technology connects to your router using one

band and connects to your devices using another band. Because a

band is dedicated to each function, performance is enhanced.

To activate FastLane mode:

1. Connect to the extender’s WiFi network.

2. Open a browser on your laptop, tablet, or smartphone and visit

www.mywifiext.net.

3. Log in using the following credentials:

•User name. admin

•Password. password

If you changed the default password, enter the password you

created.

4. Select Advanced > Operating Mode.

The Operating Mode screen displays.

5. Select the FastLane Technology radio button.

6. Review the two FastLane Technology options and choose the

band–either 2.4 GHz or 5 GHz–that is compatible with most of

your devices.

If you are not sure which band your devices use, check your user

manuals or search the Internet.

7. Click the Apply button.

Your changes are saved.

Connect Ethernet-Enabled Devices

You can use your extender to wirelessly connect as many as five

Ethernet-enabled devices, such as smart TVs, game consoles, and

Blu-ray players, to your WiFi router or access point at gigabit

speeds.

After your set up your extender, plug the Ethernet cable from a

device directly into the extender’s gigabit Ethernet port.

Ethernet ports
