NETGEAR EX6410 Manuale utente

Quick Start

AC1900 WiFi Mesh Extender

Essentials Edition

Model EX6410

Getting started

Your extender boosts your router’s WiFi signal and enhances the

signal quality over long distances.

Extender

Boosts the WiFi range and

sends a stronger signal in

hard-to-reach areas

WiFi router

Sometimes your router

doesn’t provide the

WiFi coverage that you

need

Meet your extender

Before you install your extender, learn about its LEDs, buttons, and

port.

Client Arrow LED

Access Point/

Extender switch

Power On/Off

button

Factory Reset

button

WPS button

Router Link LED

Router Arrow LED

Client Link LED

Power LED

WPS LED

Ethernet port

(on bottom panel)

LED Description

Router Link

LED

WiFi connection from the router to the extender:

• Solid green. Best connection.

• Solid amber. Good connection.

• Solid red. Poor connection.

• Off. No connection.

Client Link

LED

WiFi connection from your computer or mobile device to

the extender:

• Solid green. Best connection.

• Solid amber. Good connection.

• Solid red. Poor connection.

• Off. No connection.

Power LED • Solid amber. The extender is booting.

• Solid green. The extender is powered on.

• Off. The extender is powered off.

WPS LED • Solid green. WiFi security is enabled (WPA or WPA2).

• Blinking green. A WPS connection is being established.

• Off. WiFi security isn’t enabled.

No arrow LEDs are lit. The extender is in a good location.

Client Arrow LED blinks. Move the WiFi-enabled computer or

mobile device closer to the extender.

Router Arrow LED blinks. Move the extender closer to the

router.

You can use your extender in extender mode or in access point

mode.

In extender mode, your extender repeats the signals from your

WiFi router. After initial setup, the best location for the extender is

about halfway between your router and the area with a poor WiFi

signal. The extender must be within the range of your WiFi router

network.

In access point mode, your extender creates a new WiFi hotspot by

using a wired Ethernet connection.

Install the extender in extender mode

1. Set the Access Point/Extender switch to Extender .

2. For initial setup, place your extender in the same room as your

WiFi router.

3. Plug the extender into an electrical outlet.

Wait for the Power LED to light green. This might take up

to 2 minutes. If the Power LED doesn’t light, press the Power

On/Off button on the extender.

Continue with installation, using one of these methods:

• To connect your extender using WPS, see the following

section.

Note: WPS doesn’t support WEP network security. If you use

WEP security, you must use the NETGEAR installation assistant.

• To connect your extender using the NETGEAR installation

assistant, see Connect the extender to your WiFi network using

the NETGEAR installation assistant on page 9.

Connect the extender to your WiFi network

using WPS

Wi-Fi Protected Setup (WPS) lets you join a secure WiFi network

without selecting the network name and entering the password.

1. Press the WPS button on the extender until the WPS LED

blinks green.

2. Within two minutes, press the WPS button on your router.

The WPS LED on the extender lights solid green, the Router

Link LED lights, and the extender connects to your WiFi

network.

If the Router Link LED doesn’t light, try again. If it still doesn’t

light, see Connect the extender to your WiFi network using the

NETGEAR installation assistant on page 9.

Note: If your router supports the 5 GHz band and your

extender didn’t connect to that band, repeat the WPS process.

3. Unplug the extender and move it to a new location that is

about halfway between your router and the area with a poor

router WiFi signal.

The extender must be within the range of your WiFi router

network.

4. Plug the extender into an electrical outlet and wait for the

Power LED to light green.

5. Use the Router Link LED to nd a spot where the

extender-to-router connection is optimal.

6. If the Router Link LED doesn’t light amber or green, plug the

extender into an outlet closer to the router and try again.

Keep moving the extender to outlets closer to the router until

the Router Link LED lights amber or green.

7. Connect your WiFi-enabled computer or mobile device to the

WiFi network.

Your extender uses the same WiFi name as your router, based on

the WiFi band that it connects to rst.

Dual-band router

WiFi names

Extender connects to

this network rst

Extender WiFi name for

2.4 GHz and 5 GHz

MyWiFiExample

MyWiFiExample-5G

MyWiFiExample MyWiFiExample

MyWiFiExample

MyWiFiExample-5G

MyWiFiExample-5G MyWiFiExample-5G

Connect the extender to your WiFi network

using the NETGEAR installation assistant

The installation assistant guides you through the steps to connect

your extender to your WiFi network.

1. Connect your WiFi-enabled computer or mobile device to the

extender using a WiFi or wired Ethernet or connection:

• WiFi. On your WiFi-enabled computer or mobile device,

join the the extender WiFi network NETGEAR_EXT.

Note: NETGEAR_EXT is the extender’s default WiFi

network.

• Ethernet. Use an Ethernet cable to connect the Ethernet

port on the extender to an Ethernet port on your WiFi-

enabled computer.

When your WiFi-enabled computer or mobile device connects,

the Client Link LED lights.

2. Launch a web browser and visit www.mywiext.net.

The NETGEAR installation assistant displays.

3. Follow the prompts to connect your extender to your WiFi

network.

The Router Link LED lights when the extender connects to

the router WiFi network.

4. Unplug the extender and move it to a new location about

halfway between your router and the area with a poor WiFi

signal.

The extender must be within the range of your WiFi router

network.

5. Plug the extender into an electrical outlet and wait for the

Power LED to light green.

6. Use the Router Link LED to nd a spot where the

extender-to-router connection is optimal.

7. If the Router Link LED doesn’t light amber or green, plug the

extender into an outlet closer to the router and try again.

Keep moving the extender to outlets closer to the router until

the Router Link LED lights amber or green.
