NETGEAR FS108 - ProSafe 10/100 Desktop Switch Manuale operativo

NETGEAR’s FS100 series Fast Ethernet Switches provide your LAN

with high-speed, 10/100 Mbps auto-sensing connectivity for as many as 5, 8,

or 16 users. Just plug in your Ethernet cables, connect a power cord, and

you’re ready to go—there’s no software to configure. Engineered without the

need for internal fans, they operate silently.And each of these very compact

switches is housed in a sturdy metal case for years of dependable use.

When you want greater bandwidth and increased network access for your growing

business, plus the added benefit of quiet operation, NETGEAR’s FS105, FS108, and

FS116 are your best choices for quality, convenience, and smooth-running usability—

all at very affordable prices.

AT YOUR SERVICE

Five, eight, or sixteen ports provide LAN access for many users.

COMPACT

Solidly built in small sizes that are easy to position when space is at a premium.

SIMPLE TO USE

Once you connect the hardware, your switch is operating!

QUIET

No fan means no noise, which helps maintain a peaceful atmosphere in your busy office.

GREAT VALUE

Competitively priced—compare them to others and see the difference.

Multiple High-speed Ports

for Servers,PCs and Power Workgroups

FS105 FS108 FS116

Fast Ethernet Switches

10/100 Mbps

Help is there when you need it.

NETGEAR provides free, 24x7

telephone and e mail technical

support in English, with selected

local language support during

office hours.

www.NETGEAR.com

TECHNICAL SPECIFICATIONS

FS105

Network Ports

5 auto speed-sensing

UTP ports

Dimensions

W 158 mm (6.2”)

D 103 mm (4.1”)

H 27 mm (1.1”)

Weight

0.6 kg (1.25 lb)

AC Power

7.5 W

Standards Compliance

IEEE 802.3i 10BASE-T

IEEE 802.3u 100BASE-TX

IEEE 802.3x Flow Control

Status LEDs

Power

Collision/Rx/Tx and speed indicators for each port on the FS105 and FS108

Link, speed, and activity indicators built into each RJ-45 port

Electromagnetic Emissions

CE mark, commercial

FCC Part 15 Class A

EN55 022 (CISPR 22), Class A

VCCI Class A

C-Tick

Warranty

5 years for unit

1 year for power adapter

FS108

Network Ports

8 auto speed-sensing

UTP ports

Dimensions

W 235 mm (9.3”)

D 103 mm (4.1”)

H 27 mm (1.1”)

Weight

0.74 kg (1.7 lb)

AC Power

12.5 W

FS116

Network Ports

16 auto speed-sensing

UTP ports

Dimensions

W 285 mm (11.3”)

D 103 mm (4.1”)

H 27 mm (1.1”)

Weight

0.9 kg (2.0 lb)

AC Power

16.5 W

PACKAGE CONTENTS

Fast Ethernet Switch

Wall-mount kit

AC adapter

Quick Installation Guide

Warranty and registration card

SYSTEM REQUIREMENTS

Network cables

Network card for each PC or server

Network software

(e.g.,Windows, Linux, MacOS)

•

ISO-9001

REGISTERED

QUALITY

www.NETGEAR.com

10 11 12956781234 13 14 15 16

Power

100M 10M

Model DS108 Hub

Auto10/100 Mbps DUAL SPEED

Model FS105, FS108, or FS116 Switch

Model RT338

ISDN Router

Internet Servers Power

User PCs MAC

100 Mbps

10 Mbps

Key

NETGEAR Inc.

4401 Great America Parkway

Santa Clara, CA 95054

USA

Phone: 1-888-NETGEAR

e-mail: [email protected]

www.NETGEAR.com

In Country Phone Support

(24x7 phone support in English, local language support during ofﬁce hours.) NETGEAR™is a trademark of

NETGEAR, Inc.Windows®is

a registered trademark of

Microsoft Corporation. Other

brand and product names are

trademarks or registered

trademarks of their respective

holders. Information is subject

to change without notice.

Korea 00308-11-0319

Netherlands 0800-023-0981

New Zealand +800-1233-4566

Norway 800-12041

Singapore +800-1233-4566

Sweden 0200-298-298

Switzerland 00800-638-4327

(00800-NETGEAR)

United Kingdom 020-7216-0014

United States 1-888-NETGEAR

All Other Countries +1 801-236-8499

Australia 1800 787-638

Austria 00800-6384327

(00800-NETGEAR)

Denmark 808-82179

Canada 1-888-NETGEAR

Finland 0800-111-036

France 0800 77-17-53

Germany 00800-6384327

(00800-NETGEAR)

Hong Kong +800-1233-4566

Japan 0120-66-5402
