NETGEAR GS524T - ProSafe Switch Manuale utente

NETGEAR’s GS524T 10/100/1000 Mbps Gigabit Switch gives your

office network a megaboost of speed and capacity. Its 24 ports can blast

2000 Mbps per port of data throughput in full-duplex mode. Ideal for

combining 10, 100, and 1000 Mbps devices, this unmanaged, rack-mountable

switch features 10/100/1000 automatic speed and full/half-duplex sensing

plus Auto UplinkTM on every port. Users can take advantage of the GS524T’s

ability to deliver large amounts of multimedia, image, and video information

in no time at all. Use it as a robust and reliable network backbone for your

50- to 250-employee company.

HIGH-CAPACITY

Plenty of bandwidth for all users, with 24 switched 10/100/1000 ports for PCs, servers,

or switches.

ALERT

Each port is equipped with automatic speed and duplex sensing, plus Auto UplinkTM to

adjust for straight-through or crossover cables and make the right link.

HIGH-PERFORMANCE

Shoots data across your network at speeds of up to 2000 Mbps per port.

UNCOMPLICATED

Easy to set up and easy to use, this unmanaged switch features integrated LEDs on every

port for effortless network monitoring.

24 ports =

gigabit power to spare

GS524T

Gigabit Switch

Help is there when you need it!

NETGEAR provides free, 24x7

telephone and e mail technical

support in English, with selected

local language support during

office hours.

www.NETGEAR.com

10/100/1000 Mbps

24Port

NETGEAR Inc.

4500 Great America Parkway

Santa Clara, CA 95054

USA

Phone: 1-888-NETGEAR

E-mail: [email protected]

www.NETGEAR.com

In-Country Phone Support

(24x7 phone support in English, local language support during ofﬁce hours.) NETGEAR®is a trademark of

NETGEAR, Inc.Windows®is

a registered trademark of

Microsoft Corporation. Other

brand and product names are

trademarks or registered

trademarks of their respective

holders. Information is subject

to change without notice.

www.NETGEAR.com

TECHNICAL SPECIFICATIONS

Network Ports

10/100/1000 Mbps twisted-pair RJ-45 ports

Performance (64 byte packets)

Switching fabric: 20 gigabit per sec

Forward rate (1000 Mbps port):

1,480,000 packet per sec

Forward rate (100 Mbps port):

148,000 packet per sec

Forward rate (10 Mbps port):

14,800 packet per sec

Latency (1000 to 1000 Mbps): 30 µs max

MAC addresses: 32,000

Power Consumption

70 W maximum

Localized power cord for North America,

Japan, UK, Europe,Australia

Standards Compliance

IEEE 802.3i 10BASE-T Ethernet

IEEE 802.3u 100BASE-TX Fast Ethernet

IEEE 802.3ab 1000BASE-T Gigabit Ethernet

IEEE 802.3x Flow Control

Status LEDs

Unit: power

Per network port: link, activity, full

duplex/collision, speed

Dimensions

W 330 mm (13”)

D 207 mm (8.2”)

H 43 mm (1.7”)

Weight

2.4 kg (5.3 lb)

Environmental Specifications

Operating temperature: 0 to 40°C

Operating humidity: 90% maximum relative

humidity, noncondensing

Electromagnetic Compliance

CE mark, commercial

FCC Part 15 Class A

VCCI Class A

EN 55022 (CISPR 22), Class A, EN 50082-1,

EN 55024

C-Tick

Safety Agency Approvals

UL listed (UL 1950)/cUL

IEC950/EN60950

TUV EN 60950

Warranty

Switch: 5 years

Power supply: 2 year

PACKAGE CONTENTS

Switch

Power cord

Rack-mount kit

User guide

Warranty card

Support information card

Korea 00308-11-0319

Netherlands 0800-023-0981

New Zealand 00800-1233-4566

Norway 800-12041

Singapore 001-800-1233-4566

Sweden 0200-298-298

Switzerland 00800-0638-4327

(00800-0-NETGEAR)

United Kingdom 020-7216-0014

United States 1-888-NETGEAR

All Other Countries +1 801-236-8499

Australia 1800-787-638

Austria 00800-06384327

(00800-0-NETGEAR)

Denmark 808-82179

Canada 1-888-NETGEAR

Finland 0800-111-036

France 0800-77-17-53

Germany 00800-06384327

(00800-0-NETGEAR)

Hong Kong 001-800-1233-4566

Japan 0120-66-5402

D-GS524T-001
