NETGEAR GS700TR Series Manuale

202-10304-01

December 2007

v1.0

NETGEAR, Inc.

4500 Great America Parkway

Santa Clara, CA 95054 USA

GS700TR Series

Hardware Installation

Guide

v1.0, December 2007

Trademarks

NETGEAR, the NETGEAR logo, and Auto Uplink are trademarks or registered trademarks of NETGEAR, Inc.

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Other brand and product

names are registered trademarks or trademarks of their respective holders. Portions of this document are copyright

Intoto, Inc.

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to

make changes to the products described in this document without notice.

NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit

layout(s) described herein.

Certificate of the Manufacturer/Importer

It is hereby certified that the GS700TR Series Smart Switch has been suppressed in accordance with the conditions set

out in the BMPT-AmtsblVfg 243/1991 and Vfg 46/1992. The operation of some equipment (for example, test

transmitters) in accordance with the regulations may, however, be subject to certain restrictions. Please refer to the notes

in the operating instructions.

The Federal Office for Telecommunications Approvals has been notified of the placing of this equipment on the market

and has been granted the right to test the series for compliance with the regulations.

Product and Publication Details

Model Number: GS700TR

Publication Date: December 2007

Product Family: Smart Switch

Product Name: GS700TR Series Smart Switch

Home or Business Product: Business

Language: English

Publication Part Number: 202-10304-01

Publication Version Number: 1.0

Contents iii

v1.0, December 2007

Contents

GS700TR Series Hardware Installation Guide

About This Manual

Conventions, Formats and Scope .....................................................................................v

How to Use This Manual .................................................................................................. vi

How to Print this Manual ................................................................................................... vi

Revision History ................................................................................................................vii

Chapter 1

Introduction

Overview .........................................................................................................................1-1

Features .........................................................................................................................1-2

Package Contents ..........................................................................................................1-3

Chapter 2

Physical Description

GS724TR Front and Back Panel Configuration ..............................................................2-5

GS748TR Front and Back Panel Configuration ..............................................................2-6

LED Designations ...........................................................................................................2-7

Port LEDs .................................................................................................................2-7

System LEDs ...........................................................................................................2-8

Device Hardware Interfaces ...........................................................................................2-8

RJ-45 Ports ..............................................................................................................2-8

SFP GBIC Module ....................................................................................................2-9

Factory Defaults Button ............................................................................................2-9

Chapter 3

Applications

Desktop Switching ........................................................................................................3-11

Chapter 4

Installation

Step 1: Preparing the Site .............................................................................................4-13

iv Contents

v1.0, December 2007

Step 2: Installing the Switch ..........................................................................................4-14

Installing the Switch on a Flat Surface ...................................................................4-14

Installing the Switch in a Rack ...............................................................................4-14

Step 3: Checking the Installation ..................................................................................4-15

Step 4: Connecting Devices to the Switch ....................................................................4-16

Step 5: Installing an SFP GBIC Module ........................................................................4-16

Step 6: Applying AC Power ..........................................................................................4-17

Step 7: Managing the Switch using a Web Browser or the PC Utility ...........................4-18

Appendix A

Troubleshooting

Troubleshooting Chart ................................................................................................. A-19

Additional Troubleshooting Suggestions ..................................................................... A-20

Network Adapter Cards ......................................................................................... A-20

Configuration ......................................................................................................... A-20

Switch Integrity ...................................................................................................... A-20

Auto-Negotiation ................................................................................................... A-21

Appendix B

Technical Specifications

Index

v1.0, December 2007

About This Manual

The NETGEAR®GS700TR Series Hardware Installation Guide describes how to install,

configure and troubleshoot the GS700TR Series Smart Switch. The information in this manual is

intended for readers with intermediate computer and Internet skills.

Conventions, Formats and Scope

The conventions, formats, and scope of this manual are described in the following paragraphs:

•Typographical Conventions. This manual uses the following typographical conventions:

•Formats. This manual uses the following formats to highlight special messages:

Italic Emphasis, books, CDs, file and server names, extensions

Bold User input, IP addresses, GUI screen text

Fixed Command prompt, CLI text, code

italic URL links

Note: This format is used to highlight information of importance or special interest.

Tip: This format is used to highlight a procedure that will save time or resources.

Warning: Ignoring this type of note may result in a malfunction or damage to the

equipment.

GS700TR Series Hardware Installation Guide

vi About This Manual

v1.0, December 2007

•Scope. This manual is written for the GS700TR Series Smart Switch according to these

specifications:

How to Use This Manual

The HTML version of this manual includes the following:

• Buttons, and , for browsing forwards or backwards through the manual one page

at a time

•A button that displays the table of contents and an button. Double-click on a

link in the table of contents or index to navigate directly to where the topic is described in the

manual.

•A button to access the full NETGEAR, Inc. online knowledge base for the product

model.

• Links to PDF versions of the full manual and individual chapters.

How to Print this Manual

To print this manual you can choose one of the following several options, according to your needs.

•Printing a Page in the HTML View. Each page in the HTML version of the manual is

dedicated to a major topic. Use the Print button on the browser toolbar to print the page

contents.

•Printing a Chapter. Use the PDF of This Chapter link at the top left of any page.

Danger: This is a safety warning. Failure to take heed of this notice may result in

personal injury or death.

Product Version GS700TR Series Smart Switch

Manual Publication Date December 2007

Note: Product updates are available on the NETGEAR, Inc. website at

http://kbserver.netgear.com/main.asp.

GS700TR Series Hardware Installation Guide

About This Manual vii

v1.0, December 2007

– Click the PDF of This Chapter link at the top right of any page in the chapter you want to

print. The PDF version of the chapter you were viewing opens in a browser window.

– Your computer must have the free Adobe Acrobat reader installed in order to view and

print PDF files. The Acrobat reader is available on the Adobe Web site at

http://www.adobe.com.

– Click the print icon in the upper left of the window.

•Printing the Full Manual. Use the Complete PDF Manual link at the top left of any page.

– Click the Complete PDF Manual link at the top left of any page in the manual. The PDF

version of the complete manual opens in a browser window.

– Click the print icon in the upper left of the window.

Revision History

Tip: If your printer supports printing two pages on a single sheet of paper, you can

save paper and printer ink by selecting this feature.

Tip: If your printer supports printing two pages on a single sheet of paper, you can

save paper and printer ink by selecting this feature.

Part Number Version

Number Date Description

202-10304-01 1.0 December 2007 Initial release

GS700TR Series Hardware Installation Guide

viii About This Manual

v1.0, December 2007

1-1

v1.0, December 2007

Chapter 1

Introduction

Congratulations on the purchase of the NETGEAR Smart Switch. The NETGEAR Smart Switch is

a state-of-the-art, high-performance, IEEE-compliant network solution designed for users who

require a large number of ports and want the power of Gigabit connectivity to eliminate

bottlenecks, boost performance, and increase productivity. To simplify installation, the switch is

shipped ready for use out of the box.

This chapter serves as an introduction to the GS700TR Series Smart Switch and provides the

following information:

•Overview

•Features

•Package Contents

Overview

This Installation Guide is for the following NETGEAR Smart Switches:

• GS724TR – This product offers support for 24 ports of 10/100/1000 and two Form-factor slots

which support 1000 (1000Base-SX/LX)/100M SFP.

• GS748TR – This product offers support for 48 ports of 10/100/1000 and four Form-factor

slots which support 1000 (1000Base-SX/LX)/100M SFP.

Using Gigabit ports, high-speed connections can be made to a server or network backbone. For

example:

• Linking to high-speed servers

• Providing 10/100/1000 copper and fiber connectivity

The GS700TR Series Smart Switch also provides the benefit of administrative management with a

complete package of features for the observation, configuration, and control of the network. With a

Web-based Graphical User Interface (GUI), the switch’s many capabilities can be viewed and used

in a simple and intuitive manner. The switch’s management features include configuration for port

and switch information, VLAN for traffic control, port trunking for increased bandwidth, and

GS700TR Series Hardware Installation Guide

1-2 Introduction

v1.0, December 2007

Class of Service (CoS) for traffic prioritization. These features provide better understanding and

control of the network. Initial discovery of the switch on the network requires the Smart Wizard

Discovery program, a utility that runs on a PC.

The GS700TR Series Smart Switch can be free-standing, or rack mounted in a wiring closet or

equipment room. It is IEEE-compliant and offers low latency for high-speed networking. All ports

can automatically negotiate to the highest speed. This capability makes the switch ideal for

environments that have a mix of Ethernet, Fast Ethernet, or Gigabit Ethernet devices. In addition,

all RJ-45 ports operate in half- or full-duplex mode. The maximum segment length is 328 feet (100

meters) over Category 5 Unshielded Twisted-Pair (UTP) cable, but much longer for fiber

connections using SFP GBIC modules.

Features

The following list identifies the key features of the NETGEAR Smart Switch.

• 24/48 RJ-45 10/100/1000M auto sensing Giga switching ports.

• 2/4 Small Form-factor Pluggable (SFP) GBIC slots which function as combo ports. Combo

ports are single ports with two physical connections, SFP fiber and RJ-45 copper. The RJ-45

copper ports corresponding to the Combo ports are the last four 10/100/1000M auto sensing

Giga switching ports on each device. If both devices are plugged in, the fiber connection is

active, with fiber port taking priority if both are connected. The following SFP types are

supported:

• 1000Base-SX

• 1000Base-LX

• 100Base-FX

• The devices support full Netgear Smart Switch functionality.

• The devices provide full compatibility with IEEE standards:

• IEEE 802.3i, (10BASE-T)

• IEEE 802.3u (100BASE-TX, 100BASE-FX)

• IEEE 802.3x (Full-duplex flow control)

• IEEE 802.3ab (1000BASE-T)

• IEEE 802.3z (1000BASE-X)

• Auto-sensing and auto-negotiating capabilities for all ports.
