Nighthawk

AC1900 WiFi Access Point

Model EX7000

Quick Start Guide

¾To set up the access point:

1. Use an Ethernet cable to connect your modem router or router to an Ethernet port on the access point.

Note: Do not connect your access point directly to your DSL or cable modem. The access point does not function as a router.

If your network includes a DHCP server, you can connect the access point to a switch or hub that is connected to the DHCP

server.

2. Open the WiFi network manager on your WiFi-enabled computer or mobile device and ﬁnd and connect to the access point WiFi

network called NETGEAR_EXT.

When you are connected to the access point, the Device to Extender LED lights solid green.

Note: If you connect your computer to the access point using an Ethernet connection, you cannot set up the access point. You

can connect your computer and other devices to the access point using an Ethernet connection aer the setup.

3. Launch a web browser.

4. Enter www.mywiﬁext.net in the address ﬁeld of the browser.

A login page displays.

5. Click the NEW EXTENDER SETUP button.

The Extender Setup page displays.

6. Complete the Extender Setup page and click the NEXT button.

7. Click the ACCESS POINT button.

The access point checks for an Internet connection.

8. Set the network name (SSID), security option, and password for each band, and click the NEXT button.

Your settings are applied.

9. Use a WiFi network manager on your WiFi-enabled computer or mobile device to connect to the new access point WiFi

network.

10. Click the CONTINUE button.

A message displays that you successfully created an access point.

Modem router

or router

Ethernet

cable

Access point

Set Up the Access Point

Support

Thank you for purchasing this NETGEAR product. You can visit www.netgear.com/support to register your product, get help, access the latest downloads and

user manuals, and join our community. We recommend that you use only ocial NETGEAR support resources.

For the current EU Declaration of Conformity, visit http://support.netgear.com/app/answers/detail/a_id/11621/.

For regulatory compliance information, visit http://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

NETGEAR, Inc., 350 East Plumeria Drive, San Jose, CA 95134 USA March 2017

NETGEAR, Inc.

First Floor Building 3 University Technology Centre

Curraheen Road Cork Ireland

Corporate Oce Phone 353 21 2333 200.

This LED indicates the 2.4 GHz WiFi connection

between the access point and the router.

Solid green. Best connection

Solid amber. Good connection

Solid red. Poor connection

Off. No connection

This LED indicates the 5 GHz WiFi connection

between the access point and the router.

Solid green. Best connection

Solid amber. Good connection

Solid red. Poor connection

Off. No connection

Solid green. The access point and device are

connected.

Solid green. The Ethernet port detected an

Ethernet link with the access point.

Solid green. A USB device is connected to the

access point.

2.4 GHz Link Rate LED

5 GHz Link Rate LED

Device to Extender LED

Ethernet ports

1–5 LEDs

USB 3.0 port

Ethernet ports 1–5

Reset button

WPS button

Power button

Power connector

2.4 GHz Link

Rate LED

5 GHz Link Rate

LED

Device to

Extender LED

Ethernet ports

1–5 LEDs

USB LEDs

USB LED

Front Panel and Side Panel Rear Panel

Indicator LEDs

Nighthawk

AC1900 WiFi Access Point

Model EX7000

Quick Start Guide

Hardware
