Newcon Optik NVS 10MG Manuale utente
Operation Manual
NVS 10MG
DAY/NIGHT VISION SCOPE
East European Mount Picatinny Mount
105 Sparks Ave., Toronto, ON, M2H 2S5, Canada
IMPORTANT INFORMATION
READ PRIOR TO ACTIVATION
You have just purchased a complicated electronic
device. To operate it properly, please read this manual
carefully. Here are some common Precautions that must
be noted.
NEVER expose the opened objective lens of an
active unit in daylight (if operating in night mode).
At daytime objective lens must be covered by caps.
There is a tiny hole in the cap to provide enough light
for day time operation.
NEVER aim active unit at intense light sources (i.e.
lights, headlamps, campfires, the Moon, etc.)
NEVER reverse the polarity of a battery
NEVER disassemble the unit
NEVER connect the unit to external power sources
ALWAYS remove batteries when not in use for a
long period
ALWAYS keep the objective lenses covered when
not in use
ALWAYS store in a warm dry place when not in use
TABLE OF CONTENTS
1. DESCRIPTION................................................ 1
2. DELIVERY SET ............................................. 2
3. SPECIFICATIONS.......................................... 3
4. DESIGN........................................................... 4
5. TOOLS AND ACCESSORIES........................ 9
6. GENERAL INFORMATION ........................ 10
6.1 Precautions............................................... 10
6.2 General Instructions ................................. 11
6.3 Mounting on weapon (Side Mount) ......... 14
6.4 Mounting on weapon (Weaver Mount).... 14
7. MAINTENANCE .......................................... 15
8. TROUBLESHOOTING................................. 16
9. STORAGE ..................................................... 17
10. WARRANTY ................................................ 19
11. CUSTOMER SUPPORT ............................... 20
12. ACCEPTANCE CERTIFICATE ................... 21
1
1. DESCRIPTION
1.1 The integrated day/night riflescope NVS 10MG is a
day/night sight (hereinafter referred to as the sight) with the
set of accessories. The sight is intended for aimed firing
during daylight and at night, using large variety of weapons
with side mounting or weaver mounting rail.
1.2 The sight provides detection, recognition, observation of
a target and aiming firing in daylight and at night.
1.3 The operation temperature range of the sight is from -55
to +55°C and relative humidity up to 98% at temperature
+25°C.
Thank you for purchasing NVS 10 MG
Please read all the instructions carefully prior to use.
Failure to follow the instructions may void the warranty.
2
2. DELIVERY SET
Quantity
NVS 10MG 1
Weaver or side fail mount 1
Wrench / Screwdriver 1
Battery 2
Allen key 1
Battery control module 1
Soft cloth 1
Bag 1
Rubber eye guard 1
Case 1
Operational manual 1
Disguise cover 1
3
3. SPECIFICATIONS
Magnification
Field of view
Objective lens focal length/F
Objective lens diameter, mm
Focus range, m
Eyepiece focal length, mm
Eyepiece relief distance, mm
Dioptric adj. relative to reticle
Windage/Elevation adjustment
Windage/Elevation step
Man viewing distance, m
Vehicle viewing distance, m
Image Intensifier Tube
Tube sensitivity, A/lm
Tube resolution lp/mm
Power supply
Battery life, up to
Operations temperature
Storage temperature
Waterproof construction
Dimensions (w/o mount), mm
Weight (w/o batteries), kg
4x 0.2
9°
108mm/F1.5
72
50 –
27.4
40
Fixed -0.5 to -1 D
±34 MoA*
0.7 MoA *
>500
>1500
18 mm, Gen 2+ or 3
>500
>45
3V (2 x AA)
60 hours
-55°C to +55°C
-55°C to +70°C
Yes
255x88x80
1.600
*Minute of Angle
The unit works under voltage from 2 to 3 Volts. To test the
battery voltage, use the supplied battery control module.
4
4. DESIGN
Figure 1
1 – Flight Filter 2 – Objective lens
3 – Collective lens 4a – Switching mechanism in
the position “DAY”
4b – Switching mechanism
in the position “NIGHT”
5 – Handle
6 – Internal lenses 7 – Reticle
8 – Windage adjustment
screw
9 – Elevation adjustment wheel
10 – Elevation scale 11 – Eyepiece
12 – Direction adjustment
screw
13 – Image intensifier screen
14 – Photocathode of image
intensifier
A2 – Image intensifier
G1, G2 – Batteries R1 – Resistor
SA1 – Switch SA – Micro switch
VD1 – Light diode
5
Figure 2
1 – Light filter 2 – Objective
3 – Hand wheel for of reticle
brightness
4 – Switching mechanism
5 – Battery pack 6 – Battery
7 – Battery compartment
cover
8 – Latch
9 – Handle DAY/ NIGHT 10 – Switch ON / OFF
11 – Elevation scale 12 – Elevation adjustment
hand wheel
13 – Windage adjustment
screw
14 – Eyepiece
15 – Clutch 16 – Eyepiece Rubber
17 – Side mount 18 – Mount
19 – Washer 20 – Clutching screw
21 – Latch 22 – Lever
23 – Handle
6
WARNING!
Never operate your night vision device at daylight
without the lens cover on! Never direct the
lens to bright light!
The functional device scheme is given on the figure 1 (see
the Exhibit A).
In daylight, the handle (5) is set into the position DAY,
setting the switching mechanism into position (4a). Light
filter (1) must be removed from the objective (2). Visible
image that is formed by the objective (2) is projected onto
the reticle (7) through the collective lens (3) and lens system
(6). It can be viewed through the eyepiece (11) together with
the aiming marks.
If the aiming marks on the reticle (7) are not seen well, turn
the switch SA1 into ON position. The light diode VD1
illuminates the reticle (7). You can adjust the brightness of
the aiming marks by the resistor R1.
