Newland NLS-FM210 Series Manuale utente

NLS-FM210 Series

Embedded 2D Barcode Scanner

Quick Start

V1.0

nlscan.com Page 1

Quick Start

Disclaimer

Newland Auto-ID Tech Inc.(“Newland Auto-ID”) reserves the right to make

changes in specifications and other information contained in this document

without prior notice, and the reader should in all cases consult Newland Auto-ID

to determine whether any such changes have been made. The information in this

publication does not represent a commitment on the part of Newland Auto-ID.

This document contains proprietary information that is protected by copyright. All

rights are reserved. No part of this document may be photocopied, reproduced,

or translated into another language without the prior written consent of Newland

Auto-ID.

Trademark

, , are trademarks or registered trademarks of Newland Auto-ID

Tech Inc.

Other product names mentioned in this manual may be trademarks or registered

trademarks of their respective companies and are hereby acknowledged.

nlscan.com Page 2

Quick Start

Box contents

NLS-FM210 Embedded 2D Barcode Scanner

RS232 Cable

NOTE: It will be supplied upon order.

USB Cable

NOTE: It will be supplied upon order.

AC Adapter

NOTE: It will be supplied upon order.

Protection Rubble

NOTE: It will be supplied upon order.

nlscan.com Page 3

Quick Start

Hardware Overview

The Protection Rubber can be disassembled, but attention should be paid to»

that the demolition of protection rubber may change the actual reading distance

and proceed to effect of readers’effect.

Encryption Module is an optional accessory. FM210 encrypts the reading»

results through the IC Card Key.

Reading Window

Encryption Module

Protection Rubber

Cable Slot

nlscan.com Page 4

Quick Start

How to read 2D barcode with FM210 on the screen of mobile phone

The factory default mode is“Sensor Mode”.

You can read barcode immediately and use

QuickSet (A programming software exclusively

used by Newland Auto-ID products) or other

communication softwares to display decoded

data and captured images.

Mobile phone screen should be facing the scan

window for the optimum reading stance.

1. Unpack FM210 and accessories.

2. Insert RS232 cable (RS232 male head) into cable slot (FM210);

3. Insert RS232 cable (RS232 male head) into RS232 slot (Host female slot);

4. Switch ON and perform;

NOTE: You can use a RS232 or a USB connection. When using a USB connec-

tion, you may need to install driver into the Host to perform. The default protocol

is USB DataPipe, you can download it from Newland Auto-ID website. www.

nlscan.com

nlscan.com Page 5

Quick Start

Supports & Service

If you have a problem with your equipment, contact the Newland Support Center

for your region. Before calling, have the model number, serial number, and several

of your barcodes at hand.

Call the support Center from a phone near the scanning equipment so that the

service person can try to talk you through your problem. If the equipment is found

to be working properly and the problem is barcode readability, the Support Center

will request samples of your bar codes for analysis at our plant.

If your problem cannot be solved over the phone, you may need to return your

equipment for servicing. If that is necessary, you will be given specific directions.

Note: Newland Auto-ID Tech. is not responsible for any damages incurred during

shipment.

For service information, warranty information or technical assistance contact or

call the Support Center listed below. For the latest service information go to http://

www.nlscan.com

If you purchased your Newland product from a Newland Business Partner, contact

that Business Partner for Service.

People's Republic of China

Newland Auto-ID Tech. Inc.

Newland Science & Technology Park,

No. 1 Rujiang West Rd., Mawei, Fuzhou, China

Tel:+86 591 83972000 FAX: +86 591 83979208

Technical support: [email protected]

North America

Newland North America Inc.

46559 Fremont Blvd., Fremont, CA 94538, USA

Tel:+1 510 490 3888 FAX: +1 510 490 3887

Commercial Email: [email protected]

Technical support: [email protected]

Taiwan

Newland Auto-ID Taiwan Inc.

7F-6, No.268, Liancheng Rd., Jhonghe City,

Taipei County 235, Taiwan

Tel: + 886-2-7731-5388 FAX: +886-2-7731-5389

Commercial Email: [email protected]

Technical support: [email protected]

Europe (Incl. Russia, Turkey and Middle East)

Newland Auto-ID Europe BV

Nijverheidsweg 1d-e 6661 KS Druten, The Netherlands

Tel: +31(0)487 588 899 FAX: +31(0)487 518 273

Commercial Email: [email protected]

Technical support: [email protected]

nlscan.com Page 6

Quick Start

Revisions

Version Data Source Description Date Approved

V1.0 20090826
