Newport 205-TC Manuale utente

205-TC

THERMOCOUPLE

MINIATURE PANEL THERMOMETER

Operator’s Manual

NEWPORT

Electronics, Inc.

Counters

Frequency Meters

PID Controllers

Clock/Timers

Printers

Process Meters

On/Off

Controllers

Recorders

Relative

umidity

Transmitters

Thermocouples

Thermistors

Wire

Rate Meters

Timers

Totalizers

Strain Gauge

Meters

Voltmeters

Multimeters

Soldering Iron

Testers

p pens

p Controllers

p Electrodes

RTDs

Thermowells

Flow Sensors

For Immediate Assistance

In the U.S.A. and Canada: 1-800-NEWPORT

In Mexico: (95) 800-NEWPORT

Or call your local NEWPORT Office.

It is the policy of NEWPORT to comply with all worldwide safety and EMC/EMI regulations that apply. NEWPORT is constantly pursuing

certification of its products to the European New Approach Directives. NEWPORT will add the CE mark to every appropriate device upon

certification.

The information contained in this document is believed to be correct but NEWPORT Electronics, Inc. accepts no liability for any errors it

contains, and reserves the right to alter specifications without notice.

WARNING: These products are not designed for use in, and should not be used for, patient connected applications.

TRADEMARK NOTICE:

newportUS com, , ,

and the “Meter

Case Bezel Design”

are trademarks of NEWPORT Electronics, Inc.

PATENT NOTICE: This product is covered by one or more of the following patents: U.S. Pat. No. Des. 336,895; 5,274,577 / Canada 2052599;

2052600 / Italy 1249456; 1250938 / France Brevet No. 91 12756 / Spain 2039150; 2048066 / UK Patent No. GB2 249 837; GB2 248 954 /

Germany DE 41 34398 C2. Other US and International Patents Pending.

NEWPORT

Internet e-mail

[email protected]

Additional products from

NEWPORTnetSM On-Line Service

http://www.newportUS.com

This device is marked with the international caution symbol. It is important to read the Setup Guide before installing or commissioning

this device as it contains important information relating to safety and EMC.

NEWPORT

Electronics, Inc.

TABLE OF CONTENTS

SECTION PAGE

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii

Models Available . . . . . . . . . . . . . . . . . . . . . . . . . .iii

Section 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

1.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

1.2 Safety Considerations . . . . . . . . . . . . . . . . . . . . . .2

Section 2 About the Meter . . . . . . . . . . . . . . . . . . . . . . . . . . .3

2.1 Front of the Meter . . . . . . . . . . . . . . . . . . . . . . . . .3

2.2 Back of the Meter . . . . . . . . . . . . . . . . . . . . . . . . .4

2.3 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Section 3 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3.1 Main Board Power Jumpers . . . . . . . . . . . . . . . . . .5

3.2 Converting °F to °C (vice versa) . . . . . . . . . . . . . . .7

3.3 Installation and Panel Mounting . . . . . . . . . . . . . . .8

3.4 Sensor Input Connections . . . . . . . . . . . . . . . . . .10

3.5 Analog Output Connections . . . . . . . . . . . . . . . . .12

3.6 Display old Connections . . . . . . . . . . . . . . . . . .13

3.7 Main Power Connections . . . . . . . . . . . . . . . . . . .14

3.8 Disassembly/Assembly . . . . . . . . . . . . . . . . . . . .16

Section 4 Operation and Calibration . . . . . . . . . . . . . . . . . .18

4.1 Equipment Required . . . . . . . . . . . . . . . . . . . . . .18

4.2 Calibration Procedure . . . . . . . . . . . . . . . . . . . . .19

Section 5 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Section 6 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

PREFACE

Manual Objectives: This manual shows you how to set up and

use the Panel Thermometer.

This meter is an economical Miniature Temperature Panel

Thermometer featuring a large display with a linearized analog

output that is supplied as a standard feature.

Each of the models* can be converted by the user to display in

degrees Fahrenheit or Celsius. However, due to the internal

design of the meter, the input type and resolution CANNOT

be changed on any J, K, T, or unit.

The meter is available in many different styles. All of the

Thermocouple models listed in Table 1-1 come standard with

red LEDs, and can be ordered with a green LED display as an

option. The part numbers would include a “G”.

xample: 205-JF1,G,C0

Also, these thermocouple meters can be ordered with different

power configurations. Refer to Table 1-3 for available choices.

*Refer to Table 1-1 for the complete listing of models available.

iii

TABLE 1-1

TC MODELS AVAILABLE

The accuracies and ranges are listed in Section 5.

The following 3-1/2 digit mini thermocouple panel

thermometers are discussed in this operator’s manual

MODEL TYPE °C or °F RESOLUTION

205-JF1 J F 1.0°F

205-JF2 J F 0.1°F

205-JC1 J C 1.0°C

205-JC2 J C 0.1°C

205-KF1 K F 1.0°F

205-KF2 K F 0.1°F

205-KC1 K C 1.0°C

205-KC2 K C 0.1°C

205-TF1 T F 1.0°F

205-TF2 T F 0.1°F

205-TC1 T C 1.0°C

205-TC2 T C 0.1°C

205-EF1 E F 1.0°F

205-EF2 E F 0.1°F

205-EC1 E C 1.0°C

205-EC2 E C 0.1°C

Table 1-2

Other Models Available

Table 1-3

Power Optio s Available

MODEL POWER

205-TC type, C0 115 Vac ±15%, 50/60 z

205-TC type, C1 230 Vac ±15%, 50/60 z

205-TC type, C2A 9-26 Vdc @ 110mA max,

non-isolated.

Use ungrounded Thermocouples

to avoid ground loops.

205-TC type, C5 100 Vac ±15%, 50/60 z

205-TC type, C8 24 Vac ±15%, 50/60 z

The following 3-1/2 digit mini RTD panel meters are available

and discussed in a separate RTD Operator’s Manual

MODEL TYPE °C or °F RESOLUTION

205-MF1 RTD F 1.0°F

205-MF2 RTD F 0.1°F

205-MC1 RTD C 1.0°C

205-MC2 RTD C 0.1°C

NOTES, WARNINGS a d CAUTIONS

Information that is especially important to note is identified by

these labels:

NOTE: provides you with information that is important to

successfully setup and use the Programmable Digital

Meter.

CAUTION or WARNING: tells you about the risk of

electric shock.

CAUTION, WARNING or IMPORTANT: tells you of

circumstances or practices that can effect the meter's

functionality and must refer to accompanying

documents.

SECTION 1 INTRODUCTION

1.1 UNPACKING

Remove the Packing List and verify that all equipment has been

received. If there are any questions about the shipment, use the

phone numbers listed on the back cover to contact the

Customer Service Department nearest you.

Upon receipt of shipment, inspect the container and equipment

for any signs of damage. Take particular note of any evidence

of rough handling in transit. Immediately report any damage to

the shipping agent.

The carrier will not honor any claims unless all shipping

material is saved for their examination. After examining

and removing contents, save packing material and

carton in the event reshipment is necessary.

Verify that you received the following items in the shipping box:

QTY DESCRIPTION

1 Panel Thermometer with 3 small connectors plugged

into the rear of the meter.

1 Operator’s Manual

1.2 SAFETY CONSIDERATIONS

This device is marked with the international Caution symbol. It is important to read this

manual before installing or commissioning this device as it contains important

information relating to Safety and EMC (Electromagnetic Compatibility .

Unpacking & Inspection

Unpack the instrument and inspect for obvious shipping damage. Do not attempt to

operate the unit if damage is found.

This instrument is a panel mount device protected in accordance with Class I of EN 61010

(115/230 AC power connections . Installation of this instrument should be done by

Qualified personnel. In order to ensure safe operation, the following instructions should

be followed.

This instrument has no power-on switch. An external switch or circuit-breaker shall be included in

the building installation as a disconnecting device. It shall be marked to indicate this function, and

it shall be in close proximity to the equipment within easy reach of the operator. The switch or

circuit-breaker shall not interrupt the Protective Conductor (Earth wire , and it shall meet the

relevant requirements of IEC 947–1 and IEC 947-3 (International Electrotechnical Commission .

The switch shall not be incorporated in the mains supply cord.

Furthermore, to provide protection against excessive energy being drawn from the mains supply

in case of a fault in the equipment, an overcurrent protection device shall be installed.

• The Protective Conductor must be connected for safety reasons. Check that the power

cable has the proper Earth wire, and it is properly connected. It is not safe to operate

this unit without the Protective Conductor Terminal connected.

• Do not exceed voltage rating on the label located on the top of the instrument

housing.

• Always disconnect power before changing signal and power connections.

• Do not use this instrument on a work bench without its case for safety reasons.

• Do not operate this instrument in flammable or explosive atmospheres.

• Do not expose this instrument to rain or moisture.

• Unit mounting should allow for adequate ventilation to ensure instrument does not

exceed operating temperature rating.

• Use electrical wires with adequate size to handle mechanical strain and power

requirements. Install without exposing bare wire outside the connector to minimize

electrical shock hazards.

EMC Considerations

• Whenever EMC is an issue, always use shielded cables.

• Never run signal and power wires in the same conduit.

• Use signal wire connections with twisted-pair cables.

• Install Ferrite Bead(s on signal wires close to the instrument if EMC problems

persist.
