Noax C12 Manuale utente

Operating instructions Industrial PC

BDA−N6−ALL−US−1.0www.noax.comPage 2 of 28

We reserve the right to make technical changes.

ted into another language, by any means whatsoever, with the exception of personal use, without the written permission

of noax Technologies AG. All product names are registered trademarks or subject to the copyright of their respective compa-

nies.

Table of Contents

BDA−N6−ALL−US−1.0 www.noax.com Page 3 of 28

Table of Contents

1 Safety 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Pictograms and symbols 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Intended Use 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Safety instructions 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3.1 Upgrades and maintenance work to the Industrial PC 7. . . . . . . . . . . . . . . . . .

1.3.2 Touch display 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Power units 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 External table power unit 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 External power unit IP65 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Installation and setup 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Installation site 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Mounting C12 and C15 compact enclosures 11. . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Mounting the stainless steel S12 and S15 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Installation of the Panel Mount P12 and P15 14. . . . . . . . . . . . . . . . . . . . . . . . . . .

4 Operation 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1 Operating and display elements 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1.1 General instructions concerning the keys 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1.2 Display area 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1.3 Key area 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2 Operation 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.1 CFL background illumination 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.3 Connections in the jack area 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 Servicing and cleaning of the Industrial PC 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6 Troubleshooting 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.1 N6 error codes 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.2 Handling repairs 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.3 FAQ − frequently asked questions 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7 Technical data 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.1 Weights 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.2 Materials 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.3 Ambient conditions 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.4 External power units 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.5 Mainboard 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.6 Technical data IPC 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.7 Additional cards in the ISA/PCI slot 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.8 Fuses 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8 Declaration of conformity 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9 Your notes 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Operating instructions Industrial PC

BDA−N6−ALL−US−1.0www.noax.comPage 4 of 28

This manual describes all variants of the Industrial PC with the mainboard N6A / −B und −C.

íOld device designations are in parentheses.

Enclosure types

Mainboard variants

íPlease find more information on our web page at www.noax.com.

Compact enclosure 12 inch C12 (K12)

Compact enclosure 15 inch C15

Stainless steel enclosure 12 inch S12

Stainless steel enclosure 15 inch S15

(E15)

Panel mount enclosure 12 und 15 inch

P12, P15 (FE12, FE15)

The specifications of your N6 (P6) mainboard

are listed on the type plate (A, B or C: For

differences see the technical data in chapter

Safety

BDA−N6−ALL−US−1.0 www.noax.com Page 5 of 28

1 Safety

To avoid injuries or damage, it is imperative that you read and follow the user and safety in-

structions.

The manufacturer/supplier will not be liable for any damage caused by not observing these

instructions.

1.1 Pictograms and symbols

The following pictograms and symbols are used in this operating manual.

Potential life−threatening danger sources are indicated by a warning sign with an exclama-

tion point. This sign also applies to any possible damage to the device.

Potential life−threatening danger sources from electricity are indicated by a warning sign

with a lightning symbol. This sign also applies to any possible damage to the device.

Potential life−threatening danger sources from heat are indicated by a warning sign with a

heat symbol.

Potential life−threatening danger sources from explosion are indicated by a warning sign

with an explosion symbol. This sign also applies to any possible damage to the device.

íMandatory instructions are indicated by í.

íParticularly important instructions are also in bold.

FNumerical lists and conditions are indicated by a black dot.

"Operating instructions which have to be performed by the operator are indicated with a black arrow.

1.2 Intended Use

Your Industrial PC has been built to the latest technology and safety regulations.

íPlease use the Industrial PC only when it is in a good, undamaged condition! Any problems

and/or malfunctions which could reduce safety must be corrected immediately (for example,

defective power cord or enclosure)! Our professional service will take care of any repair.

Safety

BDA−N6−ALL−US−1.0www.noax.comPage 6 of 28

1.3 Safety instructions

It is imperative that you read this manual before operating the Industrial PC.

This manual belongs with the Industrial PC and must remain with it.

Follow accident prevention and safety rules!

Do not allow liquids or harmful vapors (e.g. from cleaning agents) to get into the non−NEMA

protected electronics area.

Only allow authorized professionals to repair the ProTouch. Unprofessional work on electric

and electronic devices may cause electrical shocks.

These PC’s contain electronic devices with highly integrated components. These electronic

components highly sensitive to surges and therefore also to the discharge of static electricity.

To avoid damage, static electricity must be removed from the body before touching electronic

components. For this purpose, touch a metal part on the ProTouch which is not insulated such

as the connector panel or the metal enclosure.

Do not open the power supply at any time! There are no maintainable components inside.

Mount the power supply only with the mounting bracket provided or the mounting holes (on

no account on the cord). Do not cover the power supply or mount it in a too small enclosure,

otherwise there is danger of overheating. For safety reasons, the power unit must be mounted

in a way that it can be disconnected from the outlet at all times.

The power unit may only be connected to an outlet with a ground wire. Use the power cord

provided, as it complies with all latest safety regulations.

Operate the Industrial PC only with the power supply provided or use an optional connection

cord with an integrated fuse (can be provided as an option).

Ensure that the electrical specifications on the attached label correspond to the power supply

or outlet!

External devices (e.g. maintenance floppies, scanners...) may only be connected or discon-

nected to/from the Industrial PC is shut off, otherwise the Industrial PC electronics or the ex-

ternal device could become damaged! Wait at least five seconds after shutting off the Indu-

strial PC before connecting an external device (with the exception of connecting Hot Plug de-

vices to USB and Firewire interfaces).

Please take care, that the connecting cables to the Industrial PC, are not too short or stretched.

Power units

External

devices

Safety

BDA−N6−ALL−US−1.0 www.noax.com Page 7 of 28

1.3.1 Upgrades and maintenance work to the Industrial PC

Before opening the device to upgrade or service it, the Industrial PC must be completely di-

sconnected from the power supply! For this purpose, unplug the cord for the power supply

from the "Power" connector of the Industrial PC. Simply turning off is not sufficient!

The Industrial PC may only be opened by authorized professionals with fundamental PC

knowledge and not by a layperson. Should upgrades or maintenance work be improperly car-

ried out, the warranty is no longer valid. Our service is recommended.

Faulty and damaged electrical equipment and parts must always be replaced by expert electri-

cians only!

Please note after opening the Industrial PC that some components can become very hot du-

ring operation (e.g. memory or hard drive). Allow these components to cool off before tou-

ching them.

Please use only batteries of the same type or those of a similar type recommended by the ma-

nufacturer. Please dispose of the batteries according to the manufacturer’s directions.

There is danger of explosion if the CMOS battery is not properly inserted. Insert the battery

with the "+" side facing upwards (the "+" sign must be legible after having been inserted).

1.3.2 Touch display

To avoid damage and malfunction, do not use pointed, sharp or harsh objects to touch the

screen! Optional protective film is available.

Do not beat or use extreme pressure to touch the display, as this could damage or destroy

it (resulting in broken glass, for example).

Do not place the Industrial PC face down on a hard surface. If necessary, place a soft cloth

or a piece of foam underneath the unit and make sure that no objects (e.g. screws) can damage

the display.

Only use soft cloths to clean the touch screen. Avoid scratches.

Please also observe the instructions in the chapter 5 "Servicing and cleaning the Industrial

PC".

Batteries

Power supplies

BDA−N6−ALL−US−1.0www.noax.comPage 8 of 28

2 Power supplies

2.1 External power supply

Fig. 15 External power supply unit

Fig. 16 Mounting bracket

The external table power unit consists of the

following components:

FPower cord

FPower unit with connecting cord to the

device

FInstallation frame for attaching the device

The mounting bracket serves the purpose of

holding the external power supply unit. The

external power supply unit can be mounted

directly on the wall, for example, using the

mounting holes in the bracket.

Power supplies

BDA−N6−ALL−US−1.0 www.noax.com Page 9 of 28

2.2 External power supply NEMA4 (IP65)

Fig. 17 External power supply NEMA4

Fig. 18 Mounting holes

198

174

145

130

14.5

4.5

atleast220

144

The external power supply with a degree of

protection NEMA4 can be mounted directly

on the wall, for example, using the mounting

holes.

To mount the external power pack, transfer

the distances between the drill holes shown in

the drawing to the surface provided for at-

tachment.

Installation and setup

BDA−N6−ALL−US−1.0www.noax.comPage 10 of 28

3 Installation and setup

3.1 Installation site

The Industrial PC is designed for challenging (harsh) environments.

However, please following the installation regulations:

FAvoid exposing the display to sun.

FDo not install the Industrial PC to be directly influenced by heat sources. Please see that there

is sufficient circulation of the rear panel, or rather, of the cool fins at the rear panel.

FLeave a minimum of 0.6 inch (15 mm) space to ensure sufficient air circulation.

íThe device will switch off on its own if the temperature is out of the operating range.

FDo not mount the Industrial PC on heavily vibrating surfaces. If this cannot be avoided, attach

the device to shock and vibration absorbers.

FWhen the ProTouch is used on fork lifts or similar vehicles, it is imperative that you take addi-

tional measures to absorb shocks and reduce vibrations (available as an option: "Modifica-

tion for mobile use").

Special mounting brackets are available for mobile applications.

íYou can find more information about installation and mounting brackets on our web

page www.noax.com.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali noax PC industriale

noax

noax N10 Manuale utente

noax

noax N11 Manuale utente

Manuali PC industriale popolari di altre marche

Chipsee

Chipsee PPC-A72-101 Manuale utente

Advantech

Advantech UNO-2184G Manuale utente

MSI

MSI MS-9A76 Manuale utente

Stackrack

Stackrack THOR200 Manuale utente

Moxa Technologies

Moxa Technologies DA-682C Series Manuale utente

Nodka

Nodka eBOX-3000-ETC Manuale utente

Siemens

Siemens SIMATIC IPC627E Manuale utente

MSI

MSI MS-9A89 Manuale utente

Artila

Artila Matrix-516 Manuale utente

Siemens

Siemens SIMATIC Rack PC 840 V2 Manuale utente

Advantech

Advantech IPPC-6152A Manuale utente

Beckhoff

Beckhoff CX9020 Manuale utente

Dell

Dell Embedded Box PC 5000 Manuale utente

IBASE Technology

IBASE Technology ASB200-918 Series Manuale utente

Lenovo

Lenovo ThinkCentre M90q Manuale del proprietario

IXXAT

IXXAT Econ 100 Manuale utente

Kontron

Kontron KBox A-151-TGL Manuale utente

AXIOMTEK

AXIOMTEK ICO500-518 Series Manuale utente

noax C12 Manuale utente

Manuali PC industriale popolari di altre marche
