Nobles EZ Rider HP Manuale utente

Specifications subject to change without notice. REV 8.14.06

Scrubbing System

Cleaning path 28 in / 710 mm 32 in / 810 mm

Solution tank capacity 30 gal / 113 L

Maximum solution flow rate - variable 0-1.0 gpm /3.7 L

Brush quantity & size (2) 6 in / 150 mm

Brush/Pad pressure Up to 140 lbs. / 64 kg

Scrub motors 0.75 hp / 0.56 kW

Scrub motor speed 750 rpm

Motor amps 20A

Motor voltage 36V

Recovery System

Recovery tank capacity 45 gal / 170 L

Airflow 75 cfm / 2124 L / min

Water lift 70 in / 1780 mm

Vacuum motor type 3 stage

Vacuum motor hp 0.8 hp / 0.6 kW

Vacuum motor amps 17A

Vacuum motor watts 600

Propelling & Power System

Transport drive system description Front wheel direct drive

Transport speed forward 0 - 4 mph / 6.4 km / h

Scrubbing speed forward 0 – 3.5 mph / 5.6 km / h

Speed control system reverse 0 - 2 mph / 3.2 km / h

Transport - empty for trailering 11 deg / 19.4 %

Working - scrubbing 4 deg / 7%

Battery amp hour rating 244 A / 36v

Battery description (6) 6 volt

Battery run time per charge Up to 3 hours

Dimensions / Weight / Sound level

Length 66.5 in / 1690 mm

Body width 32.25 in / 810 mm

Squeegee width 33 in / 840 mm 38.25 in / 970 mm

Height 54 in / 1,370 mm

With batteries 1285 lb / 580 kg

Cleaning Width 28 in / 710 mm 32 in / 810 mm

Sound level 72 dBa

Warranty 2 years/1000 hrs on parts and labor/travel (6 months) (excluding batteries).

10 years on rotationally-molded polyethylene tanks.

EZ Rider® HP

cylindrical specifications

Specifications subject to change without notice. REV 8.14.06

Scrubbing System

Cleaning path 28 in / 710 mm 32 in / 810 mm

Solution tank capacity 30 gal / 113 L

Maximum solution flow rate - variable 0-1.0 gpm /3.7 L

Brush quantity & size (2) 14 in / 360 mm 16 in / 400 mm

Brush/Pad pressure Up to 200 lbs. / 90 kg

Scrub motors 0.5 hp / 0.37 kW 0.75 hp / 0.56 kW

Scrub motor speed 320 rpm

Motor amps 20A

Motor voltage 36V

Recovery System

Recovery tank capacity 45 gal / 170 L

Airflow 75 cfm / 2124 L / min

Water lift 70 in / 1780 mm

Vacuum motor type 3 stage

Vacuum motor hp 0.8 hp / 0.6 kW

Vacuum motor amps 17A

Vacuum motor watts 600

Propelling & Power System

Transport drive system description Front wheel direct drive

Transport speed forward 0 - 4 mph / 6.4 km / h

Scrubbing speed forward 0 – 3.5 mph / 5.6 km / h

Speed control system reverse 0 - 2 mph / 3.2 km / h

Transport - empty for trailering 11 deg / 19.4 %

Working - scrubbing 4 deg / 7%

Battery amp hour rating 244 A / 36v

Battery description (6) 6 volt

Battery run time per charge Up to 3 hours

Dimensions / Weight / Sound level

Length 66.5 in / 1690 mm

Body width 32.25 in / 810 mm

Squeegee width 33 in / 840 mm 38.25 in / 970 mm

Height 54 in / 1,370 mm

With batteries 1285 lb / 580 kg

Cleaning Width 28 in / 710 mm 32 in / 810 mm

Sound level 72 dBa

Warranty 3years/2000 hrs on parts (excluding batteries), 2 years labor, 6 months travel.

10 years on rotationally-molded polyethylene tanks.

EZ Rider® HP

disk specifications
