Nobles Speedshine 1700DS Manuale utente

Nobles •12875 Ransom Street •Holland, MI 49424 •USA •(800) 522-7839 •Fax (616) 786-2345

Specifications Subject to Change Without Notice. 9.10.08

Feature Specifications

Product Name

Model Number:

Speedshine 1700HD

US # 9001766/ Canadian # 9001766 Speedshine 2000HD

US # 9001768/ Canadian # 9001768

Pad Drive System

Brush rpm 175 rpm

Motor Volts 120 V

Motor HP 1.5 hp (1.12 kW)

Motor Amps 12 A

Motor Type AC, 66 frame, heavy duty, circuit breaker protected; triple planetary;

precision gear box, 10:1 gear ratio

Motor Watts 1100 watts

Construction

Handle Twist grip operation with safety lock

Base/ Handle Corrosion-proof rotationally-molded polyethylene

Dimensions

Product Height 48 in/ 121.92 cm

Product Length 22.75 in / 57.79 cm 23.50 in/ 59.70 cm

Product Weight 97 lb/ 44 kg 100 lb/ 45.36 kg

Product Width 17 in/ 403 mm 20 in/ 510 mm

Productivity

Max. Coverage (per hour) 2000 ft2/ 185.8 m23000 ft2/ 278.7 m2

Decibel Rating

Rating at operator’s position 60 dBa

Power Cord

Length 50 ft/ 15.24 m

Power Cord Type 14 gauge, 3–wire, SJT

Warranty 3 YEARS/ 3 YEARS PARTS AND LABOR

10 YEARS ROTATIONALLY-MOLDED POLYETHYLENE BODY

PLEASE CONTACT TENNANT COMPANY FOR MORE INFORMATION

Speedshine Floor Machines - Single Speed

Specifications subject to change without notice. REV 8.14.06

Models 1700DS 2000DS

Brush RPM 185 to 300 rpm

Motor volts 120 volts

Motor hp 1.5 hp / 1.12 kW

Motor amps 12 A

Motor type Permanent magnet DC, 66 frame, dual speed, circuit breaker protected;

triple planetary; precision gear box, 10:1 gear ratio

Motor watts 1100 watts

Solution Delivery System (optional)

Tank volume 3 gal / 11.36 L

Nominal solution flow rate 0.1 gpm / 0.38 L / min

Coverage rate per tank 1000 sq ft / 92.9 sq m per tank 1500 sq ft / 135.35 sq m per tank

Productivity

Max. coverage per hour 2000 ft2/ 185.8 m23000 ft2/ 278.7 m2

Power System

Power cord length 50 ft / 15.24 m

Power cord description 14 gauge, 3-wire, SJT

Dimensions / Weight / Sound level

Height 48 in / 1219 mm 48 in / 1219 mm

Length 22.75 in / 578 mm 23.5 in / 597 mm

Weight 94 lb / 42.64 kg 97 lb / 44 kg

Width 17 in / 403 mm 20 in / 510 mm

Sound level (operator’s ear) 70 dBa 70 dBa

Warranty 3 years/2500 hrs on parts and labor.

10 years on rotationally-molded polyethylene parts.

Speedshine®

specifications
