Nobles SPEED SCRUB Manuale utente

Specifications subject to change without notice. REV 1.9.2008

Scrubbing System

Cleaning path 15 in / 380 mm

Solution tank capacity 3 gal / 11.4 L

Productivity (per hour)

Theoretical max

Estimated actual*

15,920 ft2/ 1,480 m2

8,690 ft2/ 810 m2

Solution flow rate 0.10 gpm / 0.38 lpm

Scrub motor 0.4 hp / 0.3 kW

Scrub motor speed 2400 rpm

Brush down pressure 33 lb / 15 kg

Brush size 3.5 in / 89 mm

Recovery System

Recovery tank capacity 4.5 gallon / 17.0 liter

(Includes demisting chamber)

Vacuum fan

Motor

Stages

Water lift

Airflow

1.2 hp / .88 kW

2-stage

86 in / 2180 mm

99 cfm / 2.8 m³/min

Construction & Power System

Chassis Construction Cast aluminum frame, rotational molded tanks and injection molded plastic

cover

Power Supply 120V

Frequency 50 / 60 Hz

Cable Length 50 ft / 15 m

Electrical Safety Approvals ETL Tested for UL & CSA Standards

Dimensions / Weight / Sound level

Length

Handle in working position

Handle in folded position

45.4 in / 1150 mm

27.3 in / 690 mm

19.7 in / 500 mm

Width

Base

Squeegee 17.5 in / 440 mm

Height

Base (folded handle)

With Handle Up

23.8 in / 600 mm

34 in / 860 mm

Net weight

Working weight (with water)

97 lb / 44 kg

121 lb / 55 kg

Sound level** (operator’s ear) 72 dBA

Warranty

3 years/2500 hrs on parts and labor.

10 years on rotationally-molded polyethylene tanks.

Please contact your Nobles representative for additional warranty details.

* Estimated coverage rates use the practical speed and empty/fill time standards from the 2004 ISSA Cleaning Times handbook.

** Sound levels per ISO 11201 as recommended by the American Association of Cleaning Equipment Manufacturers & OSHA

Speed Scrub®

Cord-electric, 15” cylindrical

scrubber specifications
