1 Introduction

Freescale's Qorivva MPC57xx devices are the latest

generation of Automotive microcontrollers (MCU) based on

the Power Architecture™ core. This generation is

manufactured in a 55 nm wafer processing flow (c55).

Previous generations of devices were manufactured in larger

geometry technologies.

In addition to being manufactured in a smaller technology, the

e200zxcores used in the c55 devices have been updated for

higher speeds, lower power, and better die size utilization

(equating to lower cost for the core itself). Many features of

the cores are selectable by the definition requirements of the

individual devices that use these cores. This document outlines

major differences in the e200zx cores based on the options

selected for devices in the MPC57xx family. While it lists the

differences and gives a basic summary of the feature, this

document does not fully explain the feature in detail. The core

reference manuals should be consulted for additional

information.

The table below shows the different technologies, as well as

the different types of cores that are used by the different

families of devices, starting with the first fully integrated

Power Architecture core with embedded nonvolatile flash

memory and peripherals (MPC555). There was an earlier

Automotive Power Architecture, the MPC505/MPC509,

however, it did not have integrated flash or peripherals.

Freescale Semiconductor Document Number:AN4802

Application Note Rev 0, 10/2013

Qorivva MPC57xx e200zx Core

Differences

c55 process migration

by: Randy Dees

Contents

1 Introduction................................................................1

1.1 MPC57xx core instantiations.........................2

2 Differences between MPC57xx e200zx

cores...........................................................................3

2.1 e200zx core execution options....................... 3

2.2 e200zx bus interface and memory

options........................................... ................ 5

2.3 e200zx debug options............. .......................7

A Revision history.......................... ............................ 10

Table 1. Automotive Power Architecture MCU technologies

Family Manufacturing

technology

Transistor geometry Cores used

MPC555 CDR1 350 nm1RCPU (Automotive RISC)

MPC56x Family CDR3 250 nm2

Qorivva MPC55xx

Family

HiP7 120 nm e200z0, e200z1, e200z3, e200z6

Qorivva MPC56xx

Family

c90 90 nm e200z0, e200z3, e200z4, e200z6, e200z7

Qorivva MPC57xx

Family

c55 55 nm e200z0, e200z2, e200z4, e200z7

1. 0.35 micron

2. 0.25 micron

1.1 MPC57xx core instantiations

Many of the different devices in the MPC57xx family have a varying number of cores, including devices with different types

of cores. The following table shows the cores that are instantiated on the different devices in the family. In addition, it shows

the core that debuggers can access after reset with a blank flash (or when a valid reset configuration is not programmed into

the flash). The table also shows whether any of the cores has the option of enabling a lock-step core. On this generation of

MCUs, the lock-step core cannot be used as an independent core, it can only be enabled as a lock-step core. The lock-step

core can be disabled to save power, however, this is not a significant amount of power.

Table 2. MPC57xx core summary

Device Revision Core 0 Core 1 Core 2 Lock-Step core1

MPC5726L 12e200z215An3 — — —

MPC5744K 13e200z420n3 — e200z225n34Core 0 (e200z419)

MPC5744K 22e200z410Dn3 — e200z225Bn34Core 0 (e200z409)

MPC5744P 13e200z4201n3 — — Core 0 (e200z419)

MPC5744P 2 e200z4251n3 — — Core 0 (e200z424)

MPC5746M 1.0/1.13e200z420n3 e200z420n3 e200z425n34Core 0 (e200z419)

MPC5746M 2 e200z410n3 e200z410n3 e200z425Bn34Core 0 (e200z409)

Future device 1 13e200z425n3 e200z425n34— Core 0 (e200z424)

Future device 1 2 e200z425n3 e200z425n34— Core 0 (e200z424)

MPC5748G 1 e200z4204n34e200z4204n3 e200z210n3 —

MPC5775K 1/1.13e200z4201n3 e200z7260n3 e200z7260n3 Core 0 (e200z419)

MPC5775K 2 e200z4201n3 e200z7260n3 e200z7260n3 Core 0 (e200z419)

Future device 2 1 e200z759n34e200z759n3 — Core 1 (e200z758)

MPC5777M 13e200z720n3 e200z720n3 e200z425Bn34Core 0 (e200z719)

MPC5777M 2 e200z710n3 e200z710n3 e200z425Bn34Core 0 (e200z709)

1. This column shows which core the lock-step core is associated with.

2. This device will not be supported by Freescale.

3. This revision is not intended for production.

Introduction

Qorivva MPC57xx e200zx Core Differences, Rev 0, 10/2013

2 Freescale Semiconductor, Inc.

4. Initial default boot core that executes code from the Boot Assist Flash (BAF). Debuggers have access to this core initially

as well.

2 Differences between MPC57xx e200zxcores

The second major generation of the e200zxcores has minor variations for different devices. The following sections show all

of the devices in the MPC57xx family and the variations of the cores used in each device (and version). The core options

have been divided into three sections:

• Core instruction set and execution options (signal processing instruction options, saturated math instructions, floating

point type options, instruction issue option, lock-step option etc.).

• Core bus interface options (memory protection options, end-to-end error correction code options, crossbar bus width,

local memory options, and cache options)

• Core debug options (Nexus class, timestamp option, trace port width, and whether it has the fixed JTAG Nexus register

access sequence)

The tables in the following sections are arranged by core complexity. The e200z210 is the "simplest" core (feature-wise) and

with the e200z759 being the most complex.

2.1 e200zx core execution options

The first set of options that are available to be integrated into the cores instantiated into a particular MCU directly affect the

cores, including what instructions are supported and how the instructions execute. These options are shown in the following

table, then each of the options is explained in more detail.

Table 3. e200zxcores instruction differences

Device

Revision

Instantiation

Core Name

Book E

Dual Issue

Lockstep

General Purpose Registers

Signal Processing

Saturation

Floating Point

e200z210 based cores

MPC5748G 1.0 Core 2 e200z210n3 No Single No 32x32 No No No

e200z215 based cores

MPC5726L 1.0 Core 01e200z215An3 No Single No 32x32 No No Scalar

e200z225 based cores

MPC5744K 1.0 Core 21e200z225n3 No Single No 32x32 LSP No Scalar

MPC5744K 2.0 Core 21e200z225Bn3 No Single No 32x32 LSP Yes Scalar

e200z410 based cores

MPC5746M 2.0 Core 0/1 e200z410n3 No Single Delayed 32x32 No Yes Scalar

MPC5744K 2.0 Core 0 e200z410Dn3 No Single Delayed 32x32 No Yes Scalar

Table continues on the next page...

Differences between MPC57xx e200zx cores

Qorivva MPC57xx e200zx Core Differences, Rev 0, 10/2013

Freescale Semiconductor, Inc. 3

Table 3. e200zxcores instruction differences (continued)

Device

Revision

Instantiation

Core Name

Book E

Dual Issue

Lockstep

General Purpose Registers

Signal Processing

Saturation

Floating Point

e200z420 based cores

MPC5744K 1.0 Core 0 e200z420n3 No Dual Delay

ver.

32x32 No No Scalar

MPC5746M 1.0/1.1 Core 0/1

MPC5744P 1.0 Core 0 e200z4201n3 No Dual Delay

ver.

32x32 No No Scalar

MPC5775K 1.0/1.1/

2.0

Core 0 e200z4201n3 No Dual Delay

ver.

32x32 No No Scalar

MPC5748G 1.0 Core

01/1

e200z4204n3 No Dual No 32x32 No No Scalar

e200z425 based cores

MPC5746M 1.0 Core 21e200z425n3 No Dual No 32x32 LSP No Scalar

Future device 1 1.0 Core

0/11e200z425n3 No Dual Delayed 32x32 LSP No Scalar

Future device 1 2.0 Core

0/11e200z425n3 No Dual Delayed 32x32 LSP Yes Scalar

MPC5777M 1.0 Core 21e200z425Bn3 No Dual No 32x32 LSP No Scalar

MPC5746M 2.0 Core 21e200z425Bn3 No Dual No 32x32 LSP Yes Scalar

MPC5777M 2.0

MPC5744P 2.0 Core 0 e200z4251n3 No Dual Delayed 32x32 LSP No Scalar

e200z710 based cores

MPC5777M 2.0 Core 0/1 e200z710n3 No Single Delayed 32x32 No Yes Scalar

e200z720 based cores

MPC5777M 1.0 Core 0/1 e200z720n3 No Dual Delayed 32x32 No No Scalar

e200z7260 based cores

MPC5775K 1.0/1.1/

2.0

Core 1/2 e200z7260n3 No Dual No 32x64 SPE2 No Vector

e200z759 based cores

Future device 2 1.0 Core

0/11e200z759n3 Yes Dual Delayed 32x64 SPE1.1 No Vector

1. Initial boot core.

Book E Support - Previous e200z3 through e200z7 cores supported both the Power Architecture Book E instruction set and

a more size efficient Variable Length Encoded (VLE) instruction set. The previous e200z0 cores used on some of the

MPC5500 and MPC5600 devices supported only the VLE instruction set. Most of new MPC57xx devices support only the

VLE instruction set, however, there is at least one device planned in the future that will support the full Book E instruction

set.

Differences between MPC57xx e200zx cores

Qorivva MPC57xx e200zx Core Differences, Rev 0, 10/2013

4 Freescale Semiconductor, Inc.

Dual Issue - Some versions of the cores can issue two instructions and execute two instructions at a time. Other versions of

the core will only execute a single instruction at a time. There are limitations of the instructions that can execute

concurrently. Each core in an MCU could be defined as either dual- or single-issue variation for a particular MCU.

Lock-step Type - For safety applications, two cores execute instructions in parallel and compare the results to identify errors

in the processor core. To reduce current requirements of the two cores running in parallel, one of the cores can be delayed by

one clock. This spreads the peak current requirements of the core. Not all cores support the lock-step option. In the previous

MPC56xx Family, the cores implemented a true lock-step where the two lock-step cores execute completely in parallel, with

no delay.

General Purpose Registers - Although all of the e200zxcores are 32-bit Power Architecture cores, some versions of the

cores support 64-bit registers that can be used by the Signal Processing Engine (SPE) Auxiliary Processing Unit (APU). Not

all devices support the SPE APU.

Signal Processing Instruction support - There are several options for signal processing extensions to the core, either the

Lightweight Signal Processing Unit or the Signal Processing Extension. These are shown in the following table. Some cores

do not support any signal processing instructions.

Table 4. Signal Processing instruction options

Signal Processing Instructions Version Description

Lightweight Signal Processing Unit

(LSP)

1 The Lightweight Signal Processing Unit (LSP) supports a limited

number of basic math instructions to speed digital signal processing

algorithms.

Signal Processing Extension

(SPE)

1.1 The Signal Processing Engine (SPE) Auxiliary Processing Unit

supports a full range of instructions for digital signal processing

algorithms. There are currently two major versions of the SPE (1.1 and

2.1) that are supported on the MPC57xx devices.

No signal processing instructions — Some core variations do not include any type of signal processing

extensions.

Saturation Instruction Support - To better support AutoSAR math functions, saturated math instructions are supported on

some variations/versions of the cores. This allows optimization of some AutoSAR system calls to a single instruction.

Floating Point - Basic floating point instructions are supported on some variations of the cores. These can be defined as part

of the base Power Architecture core. Either scalar or vector floating point options are supported. Vector mode is implemented

in the SPE APU.

2.2 e200zxbus interface and memory options

The cores interface to the rest of the system through a bus interface. The majority of the e200zxcores support a dual bus

structure (Harvard architecture) with a separate instruction fetch bus and a load/store bus.

The following table shows the differences between the e200z cores in regards to the cache sizes, local memory sizes, and bus

interface and control.

Table 5. e200zxcores bus interface and memory options

Device

Revision

Instantiation

Core Name

MPU

e2eECC

XBAR Bus

DTCM

ITCM

D-cache

I-cache

e200z210 based cores

Table continues on the next page...

Differences between MPC57xx e200zx cores

Qorivva MPC57xx e200zx Core Differences, Rev 0, 10/2013

Freescale Semiconductor, Inc. 5

Table 5. e200zxcores bus interface and memory options (continued)

Device

Revision

Instantiation

Core Name

MPU

e2eECC

XBAR Bus

DTCM

ITCM

D-cache

I-cache

MPC5748G 1.0 Core 0 e200z210n3 No Yes 64I/64D No No No No

e200z215 based cores

MPC5726L 1.0 Core 0 e200z215An3 No No 32I/32D No No No No

e200z225 based cores

MPC5744K 1.0 Core 2 e200z225n3 8 Yes 64I/64D 48K 16K No No

MPC5744K 2.0 Core 2 e200z225Bn3 8 Yes 64I/32D 48K 16K No No

e200z420 based cores

MPC5746M 2.0 Core 0/1 e200z410n3 24 Yes 64I/64D 64K 16K 4K 8K

MPC5744K 2.0 Core 0 e200z410Dn

24 Yes 64I/64D 64K 16K 2K 4K

e200z420 based cores

MPC5744K 1.0/1.1 Core 0 e200z420n3 24 Yes 64I/64D 64K 16K 4K 8K

MPC5746M Core 0/1

MPC5744P 1.0 Core 0 e200z4201n3 24 Yes 64I/64D 64K No 4K 8K

MPC5775K 1.0/1.1/

2.0

Core 2 e200z4201n3 24 Yes 64I/64D 64K No 4K 8K

MPC5748G 1.0 Core 1/2 e200z4204n3 No Yes 64I/64D No No 4K 8K

e200z425 based cores

MPC5746M 1.0 Core 2 e200z425n3 24 Yes 64I/64D 32K 16K No 8K

Future device 1 1.0 Core 0/1 e200z425n3 24 Yes 64I/64D 32K 16K No 8K

Future device 1 2.0 Core 0/1 e200z425n3 24 Yes 64I/64D 32K 16K No 8K

MPC5777M 1.0 Core 2 e200z425Bn3 24 Yes 64I/32D 64K 16K No 8K

MPC5746M 2.0 Core 2 e200z425Bn3 24 Yes 64I/32D 64K 16K No 8K

MPC5777M 2.0

MPC5744P 2.0 Core 0 e200z4251n3 24 Yes 64I/64D 64K No 4K 8K

e200z710 based cores

MPC5777M 2.0 Core 0/1 e200z710n3 24 Yes 64I/64D 64K 16K 4K 16K

e200z720 based cores

MPC5777M 1.0 Core 0/1 e200z720n3 24 Yes 64I/64D 64K 16K 4K 16K

e200z7260 based cores

MPC5775K 1.0/1.1/

2.0

Core 1/2 e200z7260n3 24 Yes 64I/64D 64K No 16K 16K

e200z759 based cores

Future device 2 1.0 Core 0/1 e200z759n3 MMU No 64I/64D No No 16K 16K

Memory Protection Unit (MPU) - The Memory Protection Unit (MPU) allows memory regions to be protected from being

accessed by certain cores, protected from being modified by certain cores, protected from core execution, for enabling or

disabling of being cached, and for other safety protection features.

Differences between MPC57xx e200zx cores

Qorivva MPC57xx e200zx Core Differences, Rev 0, 10/2013

6 Freescale Semiconductor, Inc.

Memory Management Unit (MMU) - The Memory Management Unit is similar to the Memory Protection unit in that it

allows memory regions to be protected from being accessed by certain cores, protected from being modified, and for

enabling/disabling of the cache for that memory region. However, it also supports the capability of remapping a logical (or

virtual) memory address into a physical hardware memory address, including the capability to map addresses based on a

Process ID. The MMU is much more complicated than the MPU, this is only a brief summary of the MMU capabilities. For

more information about the MMU, see a core reference manual or device reference manual that supports the MMU.

End-to-End Error Correction Coding (e2eECC) - End-to-end (e2e) Error Correction Coding (ECC) provides an additional

layer of safety by including ECC on all bus transactions. The ECC for the transfer is generated on the transmitting end of the

transaction and checked at the receiving end. e2eECC is an optional feature that can be implemented with the core and

system interfaces.

Cross-Bar (XBAR) interface - In general, the e200zxcores have traditionally implemented a 64-bit bus interface to the

Cross-Bar switch. On the newer e200zxcores, the instruction bus interface remains 64-bit, however, the data load/store bus

on some versions of the cores are implemented with a 32-bit interface to save power and die area (cost).

Local Data Memory (DTCM) - Some cores support a fast local data memory (SRAM). This is sometimes referred to as a

tightly coupled memory (DTCM). The size of this SRAM is definable for a given core variant. Not all devices implement

local memory. The local data memory allows for fast access of variables that are required frequently by a single core.

Local Instruction Memory (ITCM) - Some cores support a fast local instruction memory (SRAM). This is sometimes

referred to as a tightly coupled memory (ITCM). The size of this SRAM is definable for a given core variant. Not all devices

implement local memory. The local instruction memory can be loaded with frequently executed software routines, this is

similar to the concept of locking some regions of cache for frequently used subroutines or functions.

Data Cache (D-Cache) - Data cache allows fast access to recently used data from the load/store bus from memory space

outside of the core complex, typically the device internal flash or external1(to the device) memory. Different sizes of D-

Cache can be instantiated (as defined for a device) in a particular core.

Instruction Cache (I-Cache) - Instruction cache allows fast access to recently loaded instructions from memory (typically

flash). Different sizes of I-Cache can be instantiated (as defined for a device) in a particular core.

2.3 e200zxdebug options

As with other features of the core, the debug options can be determined by the definition of the device requirements. These

allow different kinds of support depending on the requirements of the overall system. These options are shown in the

following table. Each of the options is then explained.

Table 6. e200zxcores debug feature options

Device

Revision

Instantiation

Core Name

Nexus class support

Timestamp

Nexus Port Width (MDO)

JTAG Nexus State

Machine Reset

DQM DQTAG packet type

e200z210 based cores

Table continues on the next page...

1. Not all devices support an external bus.

Differences between MPC57xx e200zx cores

Qorivva MPC57xx e200zx Core Differences, Rev 0, 10/2013

Freescale Semiconductor, Inc. 7

Table 6. e200zxcores debug feature options (continued)

Device

Revision

Instantiation

Core Name

Nexus class support

Timestamp

Nexus Port Width (MDO)

JTAG Nexus State

Machine Reset

DQM DQTAG packet type

MPC5748G 1.0 Core 2 e200z210n3 3+ Yes

(unbuffere

16 or 12 Fixed Fixed

e200z215 based cores

MPC5726L 1.0 Core 0 e200z215An3 3+ No 30 Fixed Fixed

e200z225 based cores

MPC5744K 1.0 Core 2 e200z225n3 3+ No 30 Fixed Fixed

MPC5744K 2.0 Core 2 e200z225Bn3 3+ Yes

(unbuffere

30 Fixed Fixed

e200z410 based cores

MPC5746M 2.0 Core 0/1 e200z410n3 3+ Yes

(unbuffere

30 Fixed Fixed

MPC5744K 2.0 Core 0 e200z410Dn3 3+ Yes

(unbuffere

30 Fixed Fixed

e200z420 based cores

MPC5744K 1.0 Core 0 e200z420n3 3+ No 30 — Variable

MPC5746M 1.0/1.1 Core 0/1

MPC5744P 1.0 Core 0 e200z4201n3 3+ No 30 or 4 Fixed Fixed

MPC5775K 1.0/1.1/

2.0

Core 0 e200z4201n3 3+ Yes

(buffered)

30 or 16 Fixed Fixed

MPC5748G 1.0 Core 1/2 e200z4204n3 3+ Yes

(buffered)

16 or 12 Fixed Fixed

e200z425 based cores

MPC5746M 1.0 Core 2 e200z425n3 3+ No 30 — Variable

Future device 1 1.0 Core 0/1 e200z425n3 3+ No 30 or 41Fixed Fixed

Future device 1 2.0 Core 0/1 e200z425n3 3+ No 30 or 41Fixed Fixed

MPC5777M 1.0 Core 2 e200z425Bn3 3+ No 30 Fixed Fixed

MPC5746M 2.0 Core 2 e200z425Bn3 3+ Yes

(unbuffere

30 Fixed Fixed

MPC5777M 2.0 Core 2

MPC5744P 2.0 Core 0 e200z4251n3 3+ No 30 or 4 Fixed Fixed

e200z710 based cores

MPC5777M 2.0 Core 0/1 e200z710n3 3+ No230 Fixed Fixed

Table continues on the next page...

Differences between MPC57xx e200zx cores

Qorivva MPC57xx e200zx Core Differences, Rev 0, 10/2013

8 Freescale Semiconductor, Inc.

Table 6. e200zxcores debug feature options (continued)

Device

Revision

Instantiation

Core Name

Nexus class support

Timestamp

Nexus Port Width (MDO)

JTAG Nexus State

Machine Reset

DQM DQTAG packet type

e200z720 based cores

MPC5777M 1.0 Core 0/1 e200z720n3 3+ No 30 Fixed Fixed

e200z7260 based cores

MPC5775K 1.0/1.1/

2.0

Core 1/2 e200z7260n3 3+ Yes

(buffered)

30 or 163Fixed Fixed

e200z759 based cores

Future device 2 1.0 Core 0/1 e200z759n3 3+ No 16 or 12 Fixed Variable

1. Although a 4-bit parallel Nexus MDO port is implemented in the core, it is not possible to select this mode in the Nexus

Aurora Router (NAR).

2. Unbuffered timestamps had been planned for these cores.

3. Although a 16-bit parallel Nexus MDO port can be selected, pins are not available on the package to allow it to be

accessed.

Nexus Class support - The IEEE-ISTO 5001 standard supports multiple "Classes" of support. The e200zxcores can be

instantiated with different levels of support. An overview of the Nexus Class definitions can be found in AN4088

"MPC5500/MPC5600 Nexus Support Overview".

Nexus Timestamp Support - The IEEE-ISTO 5001 standard allows Nexus messages to have timestamps appended to the

message to better track the exact timing of the messages. Timestamps are an optional feature. When implemented on the

e200zxcores, the timestamps can either be implemented as buffered or non-buffered. In general, the unbuffered mode is

implemented on devices with a Nexus Aurora Router (NAR) as the Nexus output controller. Devices that instantiate the

Nexus Port Controller (NPC) use the buffered timestamps. This difference is due to the minimal time that messages spend in

the core Nexus buffers on NAR devices since the NAR implements dedicated input queues from each Nexus client on the

device. However, the NPC only acts as a switch from the output of the individual Nexus clients directly to the Nexus output

port. The NPC implements no buffers for holding messages. On NPC based devices, each client implements the buffers that

hold Nexus messages while other Nexus clients are transmitting their message out of the device.

Table 7. Nexus Timestamp support

Timestamp type Description

Buffered The buffered option appends the timestamp to the Nexus message when the message is

written into the e200zxcore Nexus message buffers.

Unbuffered The unbuffered option appends the timestamp to the Nexus message when the message

leaves the core buffers and is transferred to the device level NPC or NAR.

Nexus Port Width - The width of the Nexus Auxiliary port (trace information) is definable for the e200zxcore definition.

Typically, a 30-bit Message Data Output port is used when supporting the IEEE-ISTO 5001-2012 high-speed serial Nexus

Aurora port. Smaller sizes are generally used for a parallel Message Data Output Nexus port. Some core variations support

two port widths, while some variations support only a single port width. This is primarily to support either the Nexus Port

Differences between MPC57xx e200zx cores

Qorivva MPC57xx e200zx Core Differences, Rev 0, 10/2013

Freescale Semiconductor, Inc. 9

Controller (NPC, used on the previous MPC5500/MPC5600 devices) that supports selection between two different port

widths, and the Nexus Aurora Router (NAR, used on some of the MPC5700 devices) that supports only a single port width.

The port width, along with the port speed, define the maximum bandwidth that is available for trace information.

Table 8. Typical Nexus port width usage

Number of Message Data Outputs Typical use

4 Low-bandwidth parallel Nexus Auxiliary trace port

8 Medium-bandwidth parallel Nexus Auxiliary trace port1

12 Medium-bandwidth parallel Nexus Auxiliary trace port

16 High-bandwidth parallel Nexus Auxiliary trace port

30 Very high-bandwidth serial Nexus Aurora trace

1. This depends on the number of cores and the Nexus parallel port clock speed.

JTAG Nexus State Machine Reset - In some cases, the Nexus state machine in the e200zxcore does not get properly reset

when the JTAG TAP is changed to a different JTAG client (to a different core or other client). Previously, the Nexus JTAG

state machine was reset only if the JTAG IR changed the CMD/DATA. It has been modified to reset the Nexus state machine

anytime the JTAG state machine goes through the UPDATE_IR state.

Data Acquisition Message (DQM) Data Tag (DQTAG) packet type - The Data Tag (DQTAG) packet of the Data

Acquisition Message (DQM) is defined by the IEEE-ISTO 5001 standard as a Fixed length field. Some versions of the cores

incorrectly implement the DQTAG as a Variable length packet instead of the Fixed length field.

Appendix A Revision history

The table below shows the complete revision history of this document.

Table A-1. Revision History

Revision Author Changes

0 Randy Dees Initial customer release.

Qorivva MPC57xx e200zx Core Differences, Rev 0, 10/2013

10 Freescale Semiconductor, Inc.

Indice

Altri manuali NXP Semiconductors Microcontrollore

NXP Semiconductors

NXP Semiconductors MPC5777C Manuale utente

NXP Semiconductors

NXP Semiconductors KIT33816FRDMEVM Manuale utente

NXP Semiconductors

NXP Semiconductors MC9S12G Manuale utente

NXP Semiconductors

NXP Semiconductors MPC-LS-VNP-RDB Manuale utente

NXP Semiconductors

NXP Semiconductors JN517x-DK005 Manuale utente

NXP Semiconductors

NXP Semiconductors LPC18xx series Manuale utente

NXP Semiconductors

NXP Semiconductors MC9S08QL8 MCU Series Manuale utente

NXP Semiconductors

NXP Semiconductors UM108 Series Manuale utente

NXP Semiconductors

NXP Semiconductors UM10741 Manuale utente

NXP Semiconductors

NXP Semiconductors MPC5606BK Manuale utente

NXP Semiconductors

NXP Semiconductors OM-SE051ARD Manuale utente

NXP Semiconductors

NXP Semiconductors AN11268 Guida alla risoluzione dei problemi

NXP Semiconductors

NXP Semiconductors SLN-VIZNAS-IOT Manuale utente

NXP Semiconductors

NXP Semiconductors IOTZTB-DK006 Manuale utente

NXP Semiconductors

NXP Semiconductors UM11527 Manuale utente

NXP Semiconductors

NXP Semiconductors PN7462 series Manuale utente

NXP Semiconductors

NXP Semiconductors freescale Kinetis TWR-KV10Z32 Manuale utente

NXP Semiconductors

NXP Semiconductors TWR-KL25Z Manuale utente

NXP Semiconductors

NXP Semiconductors TWR-K70F120M Istruzioni operative e di manutenzione

NXP Semiconductors

NXP Semiconductors LPC824M201JHI33 Manuale utente

NXP Semiconductors

NXP Semiconductors S32K1 Series Manuale di istruzioni

NXP Semiconductors

NXP Semiconductors KITMPXA6115AEVB Manuale utente

NXP Semiconductors

NXP Semiconductors S12ZVM-EWP Manuale utente

NXP Semiconductors

NXP Semiconductors freescale semiconductor ColdFire MCF51CN128... Manuale utente

Manuali Microcontrollore popolari di altre marche

AMS

AMS AS7261 Demo Kit Manuale utente

Novatek

Novatek NT6861 Manuale utente

Espressif Systems

Espressif Systems ESP8266 SDK Guida all'installazione

Nuvoton

Nuvoton ISD61S00 ChipCorder Guida

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuale utente

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuale utente

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuale utente

NEC

NEC 78GK0S/K 1+ Series Istruzioni per l'installazione e il funzionamento

Mikroe

Mikroe SEMITECH N-PLC Click Istruzioni per l'installazione e il funzionamento

Intel

Intel Agilex Manuale utente

Cypress

Cypress CY4607 HX2VL Manuale utente

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuale utente

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuale utente

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuale utente

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuale utente

Espressif Systems

Espressif Systems ESP8266EX Istruzioni operative

Abov

Abov AC33M8128L Manuale utente

Laird

Laird BL654PA Manuale utente
