Oakley Holeshot 3 Hand Manuale utente
®
TABLE OF CONTENTS
ENGLISH 02-13
ESPAÑOL 14-25
FRANCAIS 26-37
ITALIANO 38-49
PORTUGUÊS 50-61
MAGYAR 62-73
DEUTSCH 74-85
JAPANESE 86-95
©2007 Oakley, Inc. U.S. Patent D509444S
HOLESHOT 3-HAND
The technology of performance becomes the art of style with Oakley Holeshot, an
invention that brings sport into life. This true Swiss Made timepiece blends the
authenticity of Oakley design with the durability of 316L stainless steel and the
refinement of a pure sapphire crystal.
Aband of supple Unobtainium® offers all-day comfort. The date display can be
read at a glance, and luminous phosphors on the minute and hour hands improve
visibility in low light. Water resistance is 10 bar, equivalent to the pressure at a
depth of 330 feet (100 meters).
02 HOLESHOT 3-HAND INSTRUCTIONS MANUAL
SETTING THE TIME
The crown can be pulled out to two click positions for setting the date and time.
To set the date and time the first time (or to reset the date and time after the
battery is changed), do the following:
HOLESHOT 3-HAND INSTRUCTIONS MANUAL 03
TO SET THE TIME
1. Pull the crown out to the first click
position (a).
2. Turn the crown until yesterday’s date
appears.
3. Pull the crown out to the second click
position (b).
4. Turn the hands forward until today’s date
appears, then continue forward until the
current time is reached. If the current time
is in the afternoon or evening, move the
hour hand all the way around the dial to
pass 12 o’clock noon.
5. Push the crown back down.
Toset the exact second, wait until the
second-counting hand reaches “60” before
you pull out the crown. Set the time then
wait until the exact second is reached
before pushing the crown back down.
AB
Second Hand
Date
Crown
TO ADJUST THE TIME AND DATE FOR SUBSEQUENT SETTINGS, USE
THESE SHORT PROCEDURES
TO SET THE TIME
1. Pull the crown out to the second click position (b).
2. Turn the crown until you reach the correct time.
3. Push the crown back down.
TO SET THE DATE
1. Pull the crown out to the first click position (a).
2. Turn the crown until you reach the correct date.
If the current time is between 9 PM and
midnight, set the date to the following day.
(This is necessary to ensure the date
display will normally change at midnight
instead of 12 noon.)
3. Push the crown back down.
04 HOLESHOT 3-HAND INSTRUCTIONS MANUAL
AB
Second Hand
Date
Crown
POWER SAVING MODE
When the timepiece is not in use, the battery life can be prolonged by pulling the
crown out to the second click position (b). This will stop the hands and reduce
power consumption.
HOLESHOT 3-HAND INSTRUCTIONS MANUAL 05
06 HOLESHOT 3-HAND INSTRUCTIONS MANUAL
BATTERY REPLACEMENT
The miniature battery that powers the timepiece is designed to last approximately
46 months. However, because the battery is inserted at the factory for extensive
performance checks, its actual life, once in your possession, may be less.
Battery replacement may be performed only by an Authorized Oakley Service
Center. Any attempt to open the watch case by persons other than Authorized
Oakley Service Professionals will void the product warranty.
Within the United States, call Oakley global headquarters at 1-800-403-7449 to
find an Authorized Oakley Timepiece Dealer or Service Professional near you.
Customers outside the United States should contact their local Authorized Oakley
Timepiece Dealer or visit the Oakley website at www.oakley.com for the number
of the nearest Oakley distributor.
CLEANING
Failure to keep the case and band clean may result in a skin rash. Use a soft,
clean cloth to wipe off any moisture that adheres to the case or band.
HOLESHOT 3-HAND INSTRUCTIONS MANUAL 07
COMPOSITION
CASE BODY..............................................................................................Stainless steel
CASE BACK ..............................................................................................Stainless steel
MANUFACTURING..................................Impact forged, high-precision CNC machined
CRYSTAL ..............................................................Sapphire with anti-reflective coating
CROWN ......................................................................Double seal for water resistance
BRACELET COMPOSITION ..............................................Oakley Unobtainium® rubber
CLOSURE ......................................................................................Stainless steel buckle
08 HOLESHOT 3-HAND INSTRUCTIONS MANUAL
SPECIFICATIONS
MOVEMENT ................................................................................................Swiss Made
TYPE OF OSCILLATOR ........................................................................Quartz tuning fork
FREQUENCY OF OSCILLATOR ......................................................32,768 cycles per sec.
DRIVE SYSTEM ............................................................Two-pole step motor (180º/sec.)
ACCURACY....................................................................................-12 /+18 sec. per mo.
THERMAL OPERATING MIN ............................................................................0ºC (32ºF)
THERMAL OPERATING MAX. ......................................................................50ºC (122ºF)
WATER RESISTANCE ................................10 bar; equivalent to depth of 100m / 330ft
BATTERY....................................................................Silver oxide: No. 397, SR 726 SW
BATTERY ENDURANCE ....................................................................Approx. 46 months
HOLESHOT 3-HAND INSTRUCTIONS MANUAL 09
