Ocean Digital WR-210CB Manuale utente

WR-210CB

Internet Radio with Bluetooth

Please read this user manual carefully before using the receiver.

User Manual

Contents

Location of Controls .......................................1

Remoter control .............................................2

Remote control character list ..........................3

Switching on the radio ....................................4

Connecting to your WiFi Network ...................5

Internet Radio ...............................................6

Aux In ...........................................................8

DLNA ............................................................8

Bluetooth ......................................................8

Media Center ................................................9

Information Center .......................................10

Conﬁguration ...............................................11

Trouble Shooting .........................................18

Technical Speciﬁcation .................................21

Location of Controls

1. Standby button

2. Right button

3. Left / Back button

4. Preset button

5. Local button

6. Home

7. Infrared remote sensor

8. Speaker

9. TFT display 2.4”

10. Rotary control knob for Volume/Dial/Select – Rotate

to adjust the volume/browsing menu, press the knob to

select for conﬁrmation

11. Aux-in jack

12. Earphone jack

13. Line out jack

14. DC IN jack

DCIN5.9V

Aux-in

11 12 13 14

- 01 -

1. : Mute

2. : Standby button

3. 0-9: Favorite station key / input letters

and numbers for WiFi Encryption

code

4. : Preset the current playing station

to Favorite

5. : Recall the favorite list

6. ▲: Cursor up

7. t: Cursor left / back to previous menu

8. u: Cursor right

9. ▼: Cursor down

10. OK: confirm button

11. : Alarm button

12. : Sleep Timer

13. Vol+: Volume up

14. Vol-: Volume down

15. : Main Menu

16. Mode: Switch between the modes of

radio

17. EQ: Equalizer

18. : Previous station on the list /

previous track on UPnP

19. : Play/pause for internet radio

20. : Next station on the list/next track

on UPnP

21. Local: Access the local station list

(Local area set up in

Configuration)

22. Info: View the detailed information of

the radio channel or music

under UPnP.

23. Dimmer: Dim down the back-light of

the display

Remoter control

- 02 -

Remote control character list

Key“0”―― 0,‘DEL’

Key“1”―― ‘1’->‘@’->‘ ’（space）->‘！’-> “ (double quotes)

->‘#’->‘$’->‘%’->‘&’-> ’（single quotes）->‘（’

->‘）’->‘*’->‘+’->‘，’->‘-’->‘.’->‘/’->‘:’->‘;’->‘<’->‘=’-

>‘>’->‘?’-

>‘[’->‘\’->‘]’->‘^’->‘_’->‘`’->‘{’->‘|’->‘}’->‘~’

Key “2”―― 2,A,B,C,a,b,c

Key“3”―― 3,D,E,F,d,e,f

Key“4”―― 4,G,H,I,g,h,i

Key“5”―― 5,J,K,L,j,k,l

Key“6”―― 6,M,N,O,m,n,o

Key“7”―― 7,P,Q,R,S,p,q,r,s

Key“8”―― 8,T,U,V,t,u,v

Key“9”―― 9,W,X,Y,Z,w,x,y,z

Note: press ’→’ to move to the next character and press ’OK’

button to conﬁrm.

You can also press ↑ ↓ to change the character /number, then

press the right key to conﬁrm the entry.

After you ﬁnish the entry, press the select button to conﬁrm.

- 03 -

Switching on the radio

Connect the main adapter to the radio unit, one end to the DC IN

on the radio and the other end to the AC main wall socket.

Caution: Use only the main adapter supplied with the radio.

Connecting a power supply with a different rating will cause

permanent damage to the radio, and may be hazardous.

The display on the front of the radio will light up and show:

Then you can select your preferred language on the radio.

It will ask you if you want to Enable the <Check Network when

Power on>; it is suggested to select <Yes>. Then, the radio will

always check the available WiFi network automatically.

Welcome

• English

Deutsch

Français

< 2/7 8

01:44

- 04 -

Connecting to your WiFi Network

The screen below will appear. You can select <Yes> to proceed to

search for an available WiFi network. If your router has the WPS

function, you can select <Yes(WPS)> to proceed.

It will then start scanning the network. After the search is done, it

will display a list of the available routers.

Choose your router from the list and enter the WEP (Wired

Equivalent Privacy) or WPA(WiFi Protected Access) code. If your

network is not encrypted with the WEP or a WPA code, the unit

will connect to the router automatically.

Note: The encryption code would have been set by the

person who set up and conﬁgured your network.

Please follow the steps below to enter the encryption code of

your router.

- Turn the rotary knob to browse the characters

- Press the Úright button to skip to the next entry

- After you're ﬁnished entering the code, press the Rotary knob to

conﬁrm.

The radio will start connecting to the network.

After the router is connected successfully, it will display the main

menu as follows:

You can now start enjoying the internet radio.

01:01

Would you like to

configure Network now?

Yes(WPS) NOYes

01:44

Linksys

Homeaudio

Demo

MOVE INPUT:OK

Ent er

Password

1/1

16:23

08:58

Internet Radio

- 05 -

Choose <Internet Radio> from the menu, and you will see

several listed options.

To start listening to the radio stations worldwide, select <Radio

Station/Music>.

My Favorites

This is to show the list of your Favorite stations which have been

assigned to the presets.

To preset a station:

While you are playing a favorite station, press and hold the

<Preset> button and the <Add to My Favorite> menu will

display. Press the rotary knob to conﬁrm. The playing station will

be added to the preset list automatically.

The presets will be stored in ascending order. You can store up to

250 presets.

Note: Preset 1 to 5 are reserved for your own choice of the

dedicated radio channels. The preset will be intended to

store from no. 6 onward. You can scroll to choose no. 1-5 at

your preference.

You can edit your favorite list at anytime. Go to <My Favourite>

on the menu or press the <Preset> button when it displays the list

of favorite stations, then press the -> right button. The following

options will display:

Delete – To delete the selected station

Shift up- To shift the selected station by one level up on the

ranking

Shift down – To shift the selected station by one level down on the

ranking

Rename – To rename the selected station

Play – press and play the selected station

Internet Radio

Press rotary knob to conﬁrm

The symbol on the top row means

station is added to preset list

- 06 -

Choose the radio station that you want to make changes to. Then

press the Right key, and you will see a list with the above options.

Then choose your desire action.

To recall a preset station:

Press the <Preset> button brieﬂy and choose your desired

station.

Radio Station / Music

Selecting this option allows you to ﬁnd your desired radio station

by Genre, Location., etc.

Local Radio

If you want to access quickly the radio stations located in your

area, select this function, and it will display the list of the stations

available in your area.

History

The radio will memorize the last 10 listened stations.

Service

Search Stations

You can ﬁnd your desired radio station by entering the name of

the station.

Add New Radio Station

If you cannot ﬁnd your desire station from the Radio station list,

and you have the streaming URL address, you can input the link

here and add it to your favorites list.

When the radio station is playing, the display will show a color

image transmitted from the radio station.

Internet Radio

Delete

Shift Up

Shift Down

< 1/5 >

iRadio

.977 The 80s Channel

977

Music

Internet Radio

- 07 -

Aux-In/DLNA/Bluetooth

Aux In

You can enjoy the music from other audio devices (such as smart

phones, MP3 players, etc) by connecting the audio cable to the

AUX IN connector at the rear of the unit.

DLNA

The Internet radio can stream music from DLNA compatible

devices, provided that the Internet radio and other DLNA devices

are under the same WiFi network.

The radio will be discovered as “AirMusic” when you try to search

it on other devices. If you want to change to something other

than AirMusic, go to Conﬁguration and DLNA setup to make the

change.

Bluetooth

1. The radio can receive and play music streamed by another

Bluetooth device.

Choose Bluetooth mode on the radio, and it will be

discoverable on other Bluetooth devices.

2. Turn on Bluetooth on your device, and look up the device

named “WR-210” from the list. Select it to start pairing.

3. If the connection is successful, it will show “Connected” on

your Bluetooth device list.

4. You can start playing music from your Bluetooth device now.

- 08 -
