OCZ ONYX 2 SATA II 2.5 Manuale utente

to change prices, products, or specifications without notice.

Designed to offer the best of both worlds, the

SandForce-driven Onyx 2 delivers 275MB/s

read, 265MB/s write, and up to 10,000

random write IOPS (4k aligned), without the

higher costs normally associated with similar

multi-level cell (MLC)-based solutions. The

Onyx 2 SSD delivers an enhanced computing

experience for netbooks, laptops, and home

desktops with faster application loading, snappier

data access, shorter boot-ups, and longer

battery life and feature TRIM support as the

ultimate Windows 7 upgrade. OCZ Onyx 2

SSDs feature a durable yet lightweight housing,

and because they have no moving parts are

more rugged than conventional hard discs.

Available in ample 120GB and 240GB

capacities, the Onyx 2 is an ideal hard drive

replacement for first-time SSD upgraders in

need of primary laptop storage or a spacious

application and OS boot drive.

D e s i g n & T e c h n o l o g y :

Desktop PCs

Notebooks

Netbooks

A p p l i c a t i o n s

M e c h a n i c a l S p e c i f i c a t i o n s :

O C Z O n y x 2 S e r i e s

S A T A I I 2 . 5 i n S o l i d - S t a t e D r i v e s

to change prices, products, or specifications without notice.

P E R F O R M A N C E

Max Read¹

up to 275 MB/s

Max Write¹

up to 265 MB/s

Sustained Write²

up to 240 MB/s

4KB Random Write³

10,000 IOPS

Seek Time

0.1 ms

P H Y S I C A L

Capacities

120GB, 240GB

NAND Components

Multi-Level Cell (MLC)

Interface

SATA II / 3Gbps

Form Factor

2.5 Inch

Controller

SandForce 1222

Dimensions (L x W x H)

99.8 x 69.63 x 9.3 mm

Weight

77g

E N V I R O N M E N T A L

Power Consumption

Idle: 0.5 Watts Active: 2 Watts

Operating Temperature

0°C ~ +70°C

Storage Temperature

-45°C ~ +85°C

Shock Resistance

1500G

Certifications

RoHS, CE, FCC

R E L I A B I L I T Y

MTBF

1.5 million hours

ECC Recovery

Up to 24 bytes correctable per 512-byte sector

Product Health Monitoring

Self-Monitoring, Analysis and Reporting Technology (SMART)

C O M P A T I B I L I T Y

Serial ATA (SATA)

Fully compliant with Serial ATA International Organization: Serial ATA Revision 2.6. Fully compliant with

ATA/ATAPI-7 Standard Native Command Queuing (NCQ)

Operating System

Windows XP 32-Bit and 64-Bit; Windows Vista 32-Bit & 64 Bit; Windows 7 32-Bit and 64-Bit;

Linux, Mac OSX (Qualified at Apple Labs)

Power Requirements

Standard SATA Power Connector

A D D I T I O N A L F E A T U R E S

Performance Optimization

TRIM (requires OS support)

Service & Support

2-Year Warranty, Toll-Free Tech Support, 24 Hour Forum Support, Firmware Updates

¹ Maximum Sequential Speeds are determined using ATTO

² Sustained transfer rate is measured using Iometer 2008, Queue Depth 32, 128KB

³ Small file I/O performance is measured using Iometer 2008, Queue Depth 32, 4KB Aligned

S p e c i f i c a t i o n s :

P A R T N U M B E R S

U P C

Onyx 2 120GB

OCZSSD2-2ONX120G

842024021193

Onyx 2 240GB

OCZSSD2-2ONX240G

842024021186

O C Z O n y x 2 S e r i e s

S A T A I I 2 . 5 i n S o l i d - S t a t e D r i v e s
