oGrow OGAL-46 Manuale utente
Step 1:
is procedure will assist you with assembling the
OGrow Walk-In 4 . by 6 . Lawn and Garden
Greenhouse with Heavy Duty Aluminum Frame.
Step 2:
To complete this procedure, you will need a Hammer,
a Phillips Screwdriver, a Drill, een-sixty fourths
inch Drill Bit, and Gloves. Optionally, you may need a
Step Ladder, a Caulking Gun, and Silicone Glass Glue.
Note: Make sure the Greenhouse is located on a at,
level surface.
Step 3:
Position (K - 0 3 B), (K - A 0 2), and (K - 0 4) at right
angles to each other. Make sure the grooves are on the
outside.
Note: Make sure the assembly is at the location you
want the Greenhouse to be installed.
Step 4:
Insert (2) Bolts (K - A 3 1) into the holes at each
corner. Secure with (2) Nuts (K - A 3 1). Do not fully
tighten the Nuts.
Step 5:
Slide (K - 0 5) into position. Repeat for both corners.
Tighten the Nuts.
Step 6:
Insert (2) Bolts and (2) Nuts into (K - A 0 2) in the
indicated areas. Do not fully tighten the Nuts.
Step 7:
Insert (2) (K - A 0 3) onto the Bolts on the Base. Tight-
en all the Nuts.
Step 8:
Insert (1) Bolt into each (K - 0 5) and (K - A 0 3)
Frame. Attach (K - A 1 5) to the Bolts using (4) Nuts.
Make sure all the Nuts are tightened.
Step 9:
e UV-protected side of the sheet is covered with
Opal White Film and must face towards the sun.
Step 10:
Remove the Opal White Film from (3) (K - A 2 4)
Panels.
Step 11:
Slide (3) (K - A 2 4) Panels into the grooves of each
Beam.
Step 12:
Insert (4) Bolts and (4) Nuts into each hole of (K - A 0
6).
Step 13:
Slide the Bolts on (K - A 0 6) into the grooves of the
Beams, then fully tighten all of the Nuts.
Step 14:
Insert (4) Bolts and (4) Nuts into (K - 0 3 B) and (K - 0
4) in the indicated areas. Do not fully tighten the Nuts.
Step 15:
Insert (K - 2 0) and (K - 0 9) onto the Bolts in (K - 0 4).
Fully tighten the Nuts.
Note: Support these Beams until they have additional
supports.
Step 16:
Insert (K - 1 9) and (K - 1 0) onto the Bolts in (K - 0 3
B). Fully tighten the Nuts.
Note: Support these Beams until they have additional
supports.
Step 17:
Insert (3) Bolts each into (K - 1 9), (K - 2 0), (K - 1 0),
and (K - 0 9).
Step 18:
Insert (2) Bolts into each (K - 0 5).
Step 19:
Remove the Opal White Film from (K - A 2 1), (K - A
2 0), and (K - A 2 2) Panels.
Step 20:
Insert (K - A 2 2), (K - A 2 0), and (K - A 2 1) Panels
into the grooves of the Beams.
Step 21:
Slide (1) Bolt each into (K - 0 6) and (K - 0 7).
Step 22:
Insert the Bolts into the holes in (K - A 0 6) and secure
them with (2) Nuts.
Step 23:
Insert (2) Bolts each into (K - 0 6) and (K - 0 7).
Step 24:
Align (2) Bolts on (K - 0 5) and (2) Bolts on (K - 0 6) to
the holes in (K - 2 1). Attach (K - 2 1) using (3) Nuts.
Repeat on the other side.
Note: Another piece will be attached to the remaining
Bolts on both (K - 0 5) Frames in a later step.
Step 25:
Insert (2) Bolts each into (K - 0 6) and (K - 0 7).
Step 26:
Align (2) Bolts on (K - 1 0) and (2) Bolts on (K - 0
6) to the holes in (K - 2 1). Attach (K - 2 1) using (4)
Nuts. Align (2) Bolts on (K - 0 9) and (2) Bolts on (K -
0 7) to the holes in (K - 2 1). Attach (K - 2 1) using (4)
Nuts.
Step 27:
Insert (2) Bolts each into (K - 0 6) and (K - 0 7).
