Oki CX 1145 MFP Manuale utente

Color Guide

CX1145 MFP

59315501, Rev. 1.0

PREFACE

Thank you for purchasing the Multifunctional Digital Systems OKI CX1145 MFP.

This color guidebook explains simply the functions of the OKI CX1145 MFP

such as “copy density adjustment”, “color adjustment”, and “image quality adjust-

ment” in color. To ensure effective use of the OKI CX1145 MFP, be sure to read

the Operator’s Manual for Basic Function as well.

Storage of Color Copies

- The copies should be kept in a place which is not exposed to light to prevent fading when

they are kept for a long time.

- If copies are kept with pressure applied between plastics made of chloroethylene for a long

time, the toner may melt and stick to the plastic. Keep them in polyethylene binders, etc.

- When a color copy is strongly folded, the toner at the fold can become separated.

- The toner on the copies may melt if it touches solvent or ink which is not dried completely.

Keep copies away from solvent.

- When copies are kept near an extremely high temperature source such as a heater, the

toner may melt. Keep them at room temperature without much variation.

1

Lighter Darker Not Adjusted

Adjusted to have

a lightened

background

Front Back

Original

OKI CX1145 MFP

INTRODUCTION OF FUNCTIONS

You can select functions by lightly touching the icons on the touch panel. The

functions (1) to (8) are explained here.

COPY DENSITY ADJUSTMENT BACKGROUND ADJUSTMENT

2

0

0

0

0

0

0

0

TEXT/PHOTO


TEXT PRINTED IMAGE

MAP IMAGE

SMOOTHING

YELLOW(Y) MAGENTA(M)

CYAN(C) BLACK(K)

RED(R) GREEN(G)

BLUE(B)

ORIGINAL MODE

COLOR BALANCE RGB ADJUSTMENT

* Black mode only

3

00

ONE-TOUCH ADJUSTMENT SHARPNESS ADJUSTMENT

TWIN COLOR COPY

WARM COOL

VIVID CLEAR SOFT SHARP

RED & BLACKTWIN COLOR SELECTABLE

ex.) [CHANGE BLACK TO] BLUE

[SECOND COLOR] MAGENTA

4

G

B

R

WC

M

Y

Y

M

C

KR

B

G

The 3 primary colors of light represent red, green and blue light. The more the colors

are mixed, the brighter the resultant color becomes. Equal mixing of these three colors

produces a colorless and transparent light (white light). Mixing these colors to make

another color is called “additive color mixing”.

The colors of the cathode-ray tube of a TV and PC displays are produced by this method.

The 3 primary colors of color materials such as paints or color toners represent Yellow

(Y), Magenta (M) and Cyan (C). The more the colors are overlaid, the darker the tone

becomes. Mixing these three colors equally produces a black. Mixing these colors to

make another color is called “subtractive color mixing”.

The colors of printed matter such as posters and brochures are produced by this

subtractive color process.

3 PRIMARY COLORS OF LIGHT AND ADDITIVE COLOR MIXING

3 PRIMARY COLORS OF COLOR AND SUBTRACTIVE COLOR MIXING
