Network Interface Card
Installation Guide:
for OKI B6100 Printer
07039201 Iss. 01
2Ethernet Network Interface Card Configuration Guide
The information in this guide may change without notice. The manufacturer assumes no responsibility for any
errors which may appear in this guide.
OKI, OkiLPR and OkiLAN are registered trademarks of Oki Electric Industry Company, Ltd. DEC,
thickwire, thinwire, VMS, VT100, and ULTRIX are trademarks of Digital Equipment Corporation. UNIX is
a registered trademark of The Open Group. Ethernet is a trademark of XEROX. NetWare is a trademark of
Novell Corp. AppleTalk, Chooser, and Macintosh are trademarks of Apple Computer Corp. Windows NT
andWindowsfor Workgroups are trademarks of Microsoft Corporation. Portionscopyright 1989, 1991, 1992,
1993 Regents of the University of California. All rights reserved. Used with permission. Portions of this work
are derived from the Standard C Library, copyright 1992 by P.J. Plauger, published by Prentice-Hall, and are
used with permission.
Copyright 2002. All rights reserved. No part of the contents of this book may be transmitted or reproduced
in any form or by any means without the written permission of the manufacturer.
Ethernet Network Interface Card Configuration Guide 3
About this Manual
This manual is organized in the following chapters and appendices:
Chapter 1 Introduction
This chapter describes the functionality and physical characteristics of the Ethernet Network Interface Card
(NIC).
Chapter 2 Ethernet Network Interface Configuration
This chapter will familiarize you with the configuration requirements for your NIC in a variety of different
environments to include AppleTalk, Local Area Transport (LAT), Netware and TCP/IP.
Chapter 3 Ethernet Network Interface Card (NIC) Installation
This chapter explains the procedure for installing the Ethernet Network Interface Card.
Chapter 4 Network Utility Software
This chapter provides information on network utility software included with your printer.
Appendix A Troubleshooting
This appendix offers various troubleshooting procedures and technical support advice.
Appendix B Frequently Used Commands
This appendix lists some of the most frequently-used commands of the Print Server command set.
◆◆◆
Ethernet Network Interface Card Configuration Guide 4
Chapter 1
Introduction
In this Chapter. . .
•“About this Chapter” on page 1-2
•“Product Description” on page 1-2
•“Physical Characteristics” on page 1-2
•“Protocols Supported” on page 1-3
1-2 Ethernet Network Interface Card Configuration Guide
About this Chapter
This chapter describes the functionality and physical characteristics of the Ethernet Network Interface Card
(NIC).
Product Description
The Ethernet Network Interface Card (NIC) is an internal multiprotocol print server that provides shared
network access to the printer for a variety of network protocols and operating systems. The NIC supports
the following protocols: TCP/IP, AppleTalk (EtherTalk), Local Area Transport (LAT), and IPX (NetWare).
The NIC can queue multiple pending jobs and service those jobs in the order that they are received from the
hosts.
Physical Characteristics
The front panel of the Ethernet NIC has a TEST/RESET button and four LEDs. The NIC supports
10BasetT and 100BaseT using an RJ45 connector for shielded and twisted pair standard Ethernet cabling.
Number Description
1TEST/RESET button - when pressed briefly while powering up the unit, returns
the NIC to its original factory default configuration.
2NIC LED - blinks yellow quickly at power on and slowly during normal operation
to show unit is functioning.
3BNC - Lights solid green to when a valid BNC network is attached to the NIC.
4RJ45 port - for 10Base-T or 100Base-T network connections.
5NET LED - blinks yellow to reflect network activity.
6BASE-T LED - lights solid green to indicate a valid 10Base-T or 100Base-T
connection.
1
234
56
Ethernet Network Interface Card Configuration Guide 1-3
NOTE: Once installed, the Ethernet NIC will automatically sense the network connection and will
automatically configure the RJ-45 connection accordingly.
Protocols Supported
The following protocols are supported by your Ethernet NIC:
• Novell NetWare (IPX/SPX)
•Telnet
•EtherTalk
•DECLAT
• TCP/IP
•SNMP
• Printer MIB Web-based status and control
◆ ◆ ◆
1-4 Ethernet Network Interface Card Configuration Guide
Chapter 2
Ethernet Network Interface
Configuration
In this Chapter. . .
•“About this Chapter” on page 2-2
•“Control Panel Settings” on page 2-2
•“EZWebCon Configuration” on page 2-5
•“Incoming Logins” on page 2-5
•“Services” on page 2-6
•“AppleTalk Configuration” on page 2-6
•“LAT Configuration” on page 2-7
•“NetWare Configuration” on page 2-8
•“TCP/IP Configuration” on page 2-11
2-2 Ethernet Network Interface Card Configuration Guide
About this Chapter
This chapter will familiarize you with the configuration requirements for your NIC in a variety of different
environments to include AppleTalk, Local Area Transport (LAT), Netware and TCP/IP.
Control Panel Settings
When you install network options in the network card slots 1 and 2, the Network 1 and Network 2 control
panel submenus appear within the Interface Menu. The interface submenu contains the settings relevant to
the data input sources, interpreter selection, etc.
Net 1 Setup
This menu selection is used to configure the printer’s Net 1 port.
NOTE: This entire Net 1 Setup menu tree is only visible when an optional network interface is installed in
the Net 1 slot.
Menu Paper Menu
Interface Menu Port
Parallel Setup
Serial Setup
Network 1 Setup
Network 2 Setup
PS Menu
PCL Menu
System Menu
Quality Menu
Functions
Flash Menu
Disk Menu
AVAILABLE SELECTIONS INTERPRETER
AUTO SWITCH (see Notes 1 and 3 below)
PCL
POSTSCRIPT 3
DEFAULT AUTO SWITCH
FORMAT (see Note 3 below)
NORMAL
BINARY
RAW
DEFAULT RAW
NETWORK CHANNEL
NETWARE
OFF
ON
DEFAULT ON
