WELCOME
Thank you for choosing an Oki B6200/B6300 Series printer. This is a
guide to help you set up, install and operate your printer. To understand
its features fully and to use the printer correctly and effectively, please
read this guide before using the printer.
This guide is applicable to the B6200/B6300 Series printers in general
although illustrations used are based on the B6300.
This guideassumes that you are familiar with the basics of how to operate
your computer and, if required, network environment.
This User’s Guide and other important user documents including the
Reference Guide, are on the CD-ROM supplied with your printer.
INTRODUCTION > 7
FEATURES OVERVIEW
A brief overview of the main features of your printer is given here:
• Multiple up printing
• 2-sided printing
• Watermark printing
• Poster printing
• Booklet printing
• Transparency separation
• Favorites
• Special media printing
• Secure printing (requires the Hard Disk option)
• Proof printing (requires the Hard Disk option)
• Delayed printing (requires the Hard Disk option)
• Receiving restriction
8 > ABOUT THIS GUIDE
ABOUT THIS GUIDE
CONVENTIONS
Throughout this guide, the four sides of the printer are referred to as front,
rear, right and left. Standing at the front of the printer you can view the
control panel and the rear of the printer is opposite the front. The right and
left sides of the printer are defined as the sides to the right and left,
respectively, of a person who is facing the front of the printer.
The following conventions are used throughout this guide to emphasize
certain procedures or information:
[ ]: Indicates items displayed on the computer and the printer control
panel. Also indicates the title of printed reports/lists from the printer.
< >: Indicates items such as hard buttons and indicators on the
keyboard and printer.
NOTE
A note provides additional information to supplement the main text which
may help you to use and understand the product.
CAUTION!
A caution provides additional information which, if ignored, may result in
equipment malfunction or damage.
WARNING!
A warning provides additional information which, if ignored, may result in
a risk of personal injury.
INSTALLATION AND RELOCATION PROCEDURE > 9
INSTALLATION AND RELOCATION
PROCEDURE
The following sections guide you through the process of installing and
setting up your printer right through to making a test print from an
application. Complete the entire installation procedure to ensure a proper
installation.
SAFETY PRECAUTIONS
This printer is available in either of the following power specifications:
110V and 220 – 240V. The specifications that apply to your printer
depend on your configuration. To prevent fire or shock hazards, connect
the power plug only to a properly rated power outlet.
HANDLING THE PRINTER
• The printer is very heavy and should always be lifted by two
people. The printer with consumables weighs 20.4kg (45lb)
(B6200) or 22.6kg (50lb) (B6300). Never attempt to lift the
printer alone.
• To lift the printer, have two individuals facing each other from the
front and rear of the printer grasp the recessed areas on each side
of the printer. Do not lift the printer by grasping any area other
than these recessed areas.
• When lifting the printer, maintain proper lifting posture to prevent
injuries.
• Other safety information is contained in the Installation Safety or
Warranty and Regulatory Information booklet supplied with this
product and should be read prior to setting up the printer.
10 > INSTALLATION AND RELOCATION PROCEDURE
CHECKING THE PACKAGE CONTENTS
Check that all items listed below are included in the printer packaging. If
any items are missing or damaged, contact your dealer.
•Printer
• Drum-toner cartridge (for approximately 6,000 Letter
pages at 5% coverage, i.e. 5% of the addressable print area
is printed)
• 250-sheet Paper Tray
• Face Up (Rear) Tray (B6300 only)
• Power cord(s)
• Unpacking instructions and Quick Setup Guide
• Safety and Warranty Booklet
•CD-ROM
The CD-ROM contains printer drivers, software and
documentation designed to help you fully utilize your new
printer. Oki has provided an interface, under MS Windows,
to assist you in selecting the appropriate document or
application.
NOTE
Retain the packaging material and box for future use if there is a possibility
that the printer will be moved over long distances.
NOTE
When the duplex unit is provided with your printer as a standard
configuration, refer to “Installing the optional accessories” on page 15 to
install the unit.
