Olympia electronics KLD-30/CBS/24V/ADR Manuale utente

KLD-30/CBS/24V/ADR , KLD-22/CBS/24V/ADR

& KLR-20/CBS/24V/ADR

922502052_09_007

MAINS VOLTAGE

LIGHT SOURCE INTENSITY

DEGREES OF COVER PROTECTION

PRODUCED IN ACCORDANCE WITH

RELATIVE HUMIDITY

CONSTRUCTION MATERIALS

KLD-30/CBS/24V/ADR

KLD-22/CBS/24V/ADR

KLR-20/CBS/24V/ADR

Technical Characteristics

Legend installation-replacement

LED Characteristics

15-30V DC

EN 60598-1, EN 60598-2-22, EN 55015, EN 61547

112lm

IP54

up to 95%

PC, Plexiglass PC

Olympia Electronics S.A.

45 °C max. across the board

11.2-13.2V DC

1209182

Built-in main board

KLD-30/CBS/24V/ADR

KLD-22/CBS/24V/ADR

KLR-20/CBS/24V/ADR

KLD-22 & KLD-30/CBS/24V/ADR /CBS/24V/ADR

KLR-20/CBS/24V/ADR

OPERATION TEMPERATURE RANGE

-30 to 50 C

VIEWING DISTANCE 22m 20m30m

TYPICAL WEIGHT 380gr.

775gr. 550gr.

GUARANTEE 3 years

MAXIMUM POWER CONSUMPTION

1.2W

EXTERNAL DIMENSIONS (LXWXH) 310x35x216mm 254x35x170mm254x35x180mm

European

manufacturers

Thank you for your trust in our products

Olympia Electronics - European manufacturer

Warranty

Olympia Electronics guarantees the quality, condition and operation of the goods. The

period of warranty is specified in the official catalogue of Olympia Electronics and also in

the technical leaflet, which accompanies each product. This warranty ceases to exist if

the buyer does not follow the technical instructions included in official documents given

by Olympia Electronics or if the buyer modifies the goods provided or has any repairs or

re-setting done by a third party, unless Olympia Electronics has fully agreed to them in

writing. Products that have been damaged can be returned to the premises of our

company for repair or replacement, as long as the warranty period is valid.

Olympia Electronics reserves the right to repair or to replace the returned goods and to

or not charge the buyer depending on the reason of defection. Olympia Electronics

reserves the right to charge or not the buyer the transportation cost.

72nd km. O.N.R. Thessaloniki-Katerini

P.C. 60300 P.O. Box 06 Εginio Pierias Greece

www.olympia-electronics.gr

info@olympia-electronics.gr

MANUFACTURER

MODEL NUMBER

VOLTAGE RANGE

CONNECTIONS

NOMINAL POWER

TEMPERATURE (tc)

IP54

Maintained

30m22m20m

Addressable

ADR

75lm

Light output

ADDRESSABLE EMERGENCY

ILLUMINATION SIGNS FOR CBS 24VDC

NOTE: LED= Light Emitting Diode

LABELING EXPLANATION:

Z: Central supply

1: Maintained operation

C: Including inhibiting mode

E: With non-replacable lamp(s) and/or battery

G: Internally illuminated safety sign

(*) Maintained operation: The luminary lights its illumination source, when it is

The light source of this luminary is not replaceable when the light source

reaches its end of life the whole luminary shall be replaced.

ATTENTION!!!

Addressing Table

922502052_09_007 922502052_09_007

Wall mounting

Luminary disassembly

Ενδεικτικά

>5mm

Accessories for installation

(After request)

After the desired installation follow the steps below

-L

To the next

luminaire

Insert the cable

communication

1. Operations for installation, maintainance or testing must be done by

authorized personnel only.

2. The device, must be connected only to the GR-8600 panel via its ADR

line.

3. First set the address before installation. To address the device refer to

the table below.

Address operation

For address operations refer to the installation manual of the panel.

Please see manual of CBS panel GR-8600 for maximum number of

luminaries that can be interconnected.

2 3 4 5 6

922502052_09_007

Addressing

dipswitch

Luminaire

Wall mounting accessorie

Ceiling mounting accessorie

Manual

Package contents

General

Installation methods

Hanging installation

Insert the

power cable

Insert the

cable grommet

Insert the

power cable

Insert the

power cable

Insert the

power cable

Insert the

cable grommet

Insert the

cable grommet

Ceiling mounting

Luminary assembly

Α-2130: Accessorie for ceiling (1m)

Α-2131: Accessorie for ceiling (0,5m)

Α-2132: Accessorie for ceiling (0,25m)

Α-2133: Accessorie for wall mounting

Α-2136: Accessorie for hanging installation (2,5m)

A-2520/PL: Suspended ceiling base

Address Address

Dipswitch

setting Dipswitch

setting
