Olympus C-50 - Camedia 5MP Digital Camera Guida all'installazione

DIGITAL CAMERA

APPAREIL PHOTO NUMÉRIQUE

DIGITALKAMERA

CÁMARA DIGITAL

BASIC MANUAL

MANUEL DE BASE

EINFACHE ANLEITUNG

MANUAL BÁSICO

ENGLISH

FRANÇAIS

DEUTSCH

ESPAÑOL

Before using your camera, read this manual carefully to ensure correct use.

We recommend that you take test shots to get accustomed to your camera before taking important

photographs.

Avant d’utiliser votre appareil photo, veuillez lire attentivement ce mode d’emploi, de manière à

obtenir les meilleurs résultats possibles.

Avant d’effectuer des prises de vues importantes, nous vous conseillons par ailleurs de faire

quelques essais afin de vous familiariser avec le maniement de l’appareil photo.

Bitte lesen Sie vor Gebrauch dieser Kamera sorgfältig diese Bedienungsanleitung, um optimale

Ergebnisse beim Fotografieren zu erzielen.

Wir empfehlen, vor wichtigen Aufnahmen Probeaufnahmen durchzuführen, um sich mit der

Bedienung und den Funktionen der Kamera vertraut zu machen.

Antes de usar su cámara lea este manual detalladamente para asegurar el uso correcto.

Nosotros le recomendamos que tome fotografías de prueba para familiarizarse con su cámara

antes de tomar fotografías importantes.

C-50 ZOOM

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 1

CONTENTS/TABLE DES MATIÈRES/

INHALT/CONTENIDO

ENGLISH..................................................................................2

FRANÇAIS ............................................................................40

DEUTSCH ..............................................................................78

ESPAÑOL ............................................................................116

Names of parts 4

Monitor indications 6

How to use this manual 10

Getting started 11

Shooting 18

Playback 30

Formatting cards 33

Transferring pictures to a computer 34

Error codes 36

Specifications 38

CONTENTS

Thank you for purchasing an Olympus digital camera. Before you start to use

your new camera, please read these instructions carefully to enjoy optimum

performance and a longer service life. Keep this manual in a safe place for

future reference.

These instructions are only for quick reference. For more details

on the camera functions described in this manual, refer to the

camera Reference Manual on the CD-ROM enclosed in the camera

package.

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 2

For customers in Europe

“CE” mark indicates that this product complies with the European

requirements for safety, health, environment and customer

protection. “CE” mark cameras are intended for sales in Europe.

For customers in North and South America

Trademarks

• Microsoft and Windows are registered trademarks of Microsoft Corporation.

• Macintosh is a trademark of Apple Computer Inc.

• All other company and product names are registered trademarks and/or

trademarks of their respective owners.

• The standards for camera file systems referred to in this manual are the

“Design Rule for Camera File System/DCF” standards stipulated by the

Japan Electronics and Information Technology Industries Association

(JEITA).

For customers in USA

Declaration of Conformity

Model Number : C-50 ZOOM

Trade Name : OLYMPUS

Responsible Party : Olympus America Inc.

Address : 2 Corporate Center Drive, Melville, New York

11747-3157 U.S.A.

Telephone Number : 1-631-844-5000

Tested To Comply With FCC Standards

FOR HOME OR OFFICE USE

This device complies with Part 15 of the FCC rules. Operation is subject

to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including

interference that may cause undesired operation.

For customers in Canada

This Class B digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 3

Names of parts

Zoom lever (W/T)/( / )

Shutter button

Self-timer/Remote control lamp

Remote

control

receiver

Lens barrier

Strap eyelet

Lens

VIDEO OUT jack

Connector cover

USB connector DC-IN jack*

* Remove the cover before

connecting the AC adapter.

Tripod socket

Flash

Battery/Card

compartment cover

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 4

Names of parts

AF target

mark

Orange lamp

Green lamp

Macro/Spot button ( )

Protect button ( )

Flash mode button ( )

Erase button ( )

Viewfinder

Arrow pad (ÑñÉí)

Card access lamp

Monitor OK/Menu button ( )

Monitor button

(Quick View/ )

Mode dial

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 5

Monitor indications

Indications during shooting

Indications during still picture playback

Indications during movie playback

When INFO is set to OFF When INFO is set to ON

12 3 4

ISO 80

’02.09.12 12:30

SIZE: 320x240

’02.09.12 12:30

FILE: 100–0020

’02.09.12 12:30

9*()

SIZE: 2560x1920

F2.8 1/800 +2.0

ISO80

’02.09.12 12:30

FILE: 100–0020

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 6

Monitor indications

Control panel indications

Items Indications

1Shooting mode , P, A, S, M,

, , , , , ,

2Aperture value F2.8 – F8.0

3Shutter speed 8 – 1/1000

4Exposure compensation –2.0 – +2.0

Exposure variance –3.0 – +3.0

5AF target mark

6Number of storable 24

still pictures/

Seconds remaining 24"

7Record mode TIFF, SHQ, HQ, SQ1, SQ2

8Memory gauge

9Battery check

0Self-timer/

Remote control

!Drive mode , , BKT

@White balance , , ,

#ISO ISO80, ISO160, ISO320

$Green lamp O

%Flash stand-by mark

^Flash mode , , ,

SLOW,

SLOW

&Spot metering/ , ,

Macro mode

,,,

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 7

Monitor indications

Items Indications

*Print reserve

(Number of prints x2 –x10

)Protect

qDate ’02. 12. 24, ’03. 01. 12

wTime 07:15, 12:30, 17:45

eFrame number 20

rPixel resolution 2560 x 1920, 1600 x 1200

tMovie mark

yFile number/ FILE:100 –0020

Recording time 0"/15" (during movie playback)

Total recording time

0" / 15"

Playing time

●The monitor indications differ depending on the camera’s settings.

●You can select the amount of information displayed on the monitor.

Note

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 8

Monitor indications

If the remaining battery power is low, the battery check indication changes as

follows when the camera is turned on or while the camera is in use.

Battery check

Memory gauge

The memory gauge lights when you take a picture. When the gauge is lit, the

camera is storing a picture on the card (xD-Picture Card). The memory gauge

indication changes as shown below depending on the shooting status. When

the memory gauge is full, wait until the light goes out before you take any

more shots.

When taking still pictures

Before shooting

(Gauge is off)

Shoot

Wait

When recording movies

During shooting (Gauge lit)

●Shooting is not possible until the light goes out completely.

●Movie recording finishes automatically when the memory

gauge is fully lit.

Shoot

If you continue shooting

Wait

Before shooting

(Gauge is off)

If you continue shooting

During shooting (Gauge lit)

Lights

(green)

Ready for shooting.

Lights

(red)

Remaining power level: low. If

you plan to use the camera

for a long time, charge the

battery soon.

No indication

(The green lamp and

orange lamp next to the

viewfinder blink.)

Remaining power level:

exhausted. Replace with a

charged battery.

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 9

How to use this manual

3Press ñon the arrow pad to select .

4When is selected on the screen, press

Ññ to select the date format.

●Select any one of the following formats:

D-M-Y (Day/Month/Year)

M-D-Y (Month/Day/Year)

Y-M-D (Year/Month/Day)

●The following instructions show the

procedure used when the date and time

settings are set to Y-M-D.

CARD SETUP

screen

SELECT SET

Aperture setting (Aperture priority shooting)

1In the top menu, select MODE MENU TCAMERA TP/A/S/M TA.

Press . Press again to cancel the menu.

2Set the aperture value.

To increase the aperture value (F-number), press Ñ.

To decrease the aperture value (F-number), press ñ.

3Take the picture.

Available

modes

Ñ, ñ, Éand íused in instructions correspond to the

buttons on the arrow pad as shown.

Step through the menus in the order of the arrows.

Set the camera to any of the modes shown.

If a button is shown in gray, press it as part of the step.

1 C-50ZBasic-E1 02.9.6 4:28 PM Page 10
