Olympus C-3000 - 3.2MP Digital Camera Manuale utente

151

MOVIE PICTURE DISPLAY MENU

*Press the Menu button to set the following items when the Mode dial is

set to and a movie picture is displayed on the LCD monitor. (p. 44)

Monitor Display

Use

Displaying movie pictures as a movie. (p. 152)

Displaying information about the image (date and

time, file name, etc.). (p. 154)

Creating a movie index (p. 156) and editing

movies. (p. 158)

Performing All-Frame erase (p. 160) or Card format.

(p. 162)

Making adjustments. [All reset (p. 194), Beep sound

(p. 204), Index-Display adjustment (p. 218),

Brightness (p. 215), Date/time set (p. 34)]

MODE

SETUP

CARD

SETUP

FUNCTION

INFO

MOVIE

PLAY

➠

➠➠➠

152

You can play movies you have recorded. will appear on the LCD

monitor for movies.

Set the Mode dial to .

• The LCD monitor turns on

automatically.

Display a picture with on

the LCD monitor using the

Jog dial.

• Picture information is displayed

for 5 seconds. Press the Erase

or Menu button to display the

picture information again.

Press the Menu button to

display the Menu.

Press the top/bottom arrows

on the Jog dial to select

MOVIE PLAY.

• To cancel, press the Menu

button.

Press the right arrow on the

Jog dial to select START.

Press the OK button to start

the movie.

• The card access lamp blinks

for a moment, then the movie

starts.

A/S/M

OFF

PLAYING MOVIES

MOVIE

PLAY

CARD

SETUP

START

[1/1]24

MODE

SETUP

FUNCTION

INFO

542 1

153

Press the OK button during

the movie to pause it. Press it

again to restart.

• The following operations can

be performed during pause.

Press the top arrow on the Jog

dial to pause at the beginning

of the movie. Press the bottom

arrow to pause at the ending of

the movie.

Press the right arrow on the

Jog dial to start the movie.

Press the left arrow to play it

backwards.

Press the Menu button when

movie playback is finished.

The Menu reappears. Press it

again to exit the Menu.

12.23.’00 21:56 24

Note:

•Sound cannot be played back by this camera. Connect it to a TV or

personal computer for sound playback.(p. 124)

154

PICTURE INFORMATION

You can display picture information (settings, date/time, file number, etc.)

on the LCD monitor.

Set the Mode dial to .

Press the Menu button to

display the Menu.

Press the top/bottom arrows

to select INFO.

•To cancel, press the Menu

button.

Press the right arrow on the

Jog dial, then press the

top/bottom arrows to select

ON.

Press the left arrow on the

Jog dial to confirm the setting.

Press the OK button to save

the setting and cancel the

Menu.

A/S/M

OFF

[1/1]24

MOVIE

PLAY

CARD

SETUP

MODE

SETUP

FUNCTION

INFO

OFF

543 1

155

SIZE: 320 240

0" / 100"

12.23.,00 21:56

Sound record

Protect

Movie picture

Battery check

Recording mode

Image size

White balance

Date/Time

Seconds

During movie recording

FILE: 123-3456

Movie picture

Battery check

File name

When a movie picture is selected

Note:

•When picture information is displayed, the frame number will not be

displayed.

•Unless OFF is selected in All Reset, the setting will be canceled when the

power is turned off. (p. 194)

• The information is displayed for a period of 5 seconds.

156

FUNCTIONS

These functions enable you to create an index of recorded images and to

edit images.

CREATING AN INDEX

Recorded movies can be displayed as an index. After an index is

created, it can be saved on the card as a still picture image.

Set the Mode dial to .

Using the Jog dial, display an

image with the mark on

the LCD monitor.

Press the Menu button to

display the Menu.

Press the top/bottom arrows

on the Jog dial to select

FUNCTION.

After pressing the right arrow

on the Jog dial, press the

top/bottom arrows to select

MOVIE INDEX, then press the

OK button.

Press the right/left arrows on

the Jog dial to select the first

frame for the index display,

then press the OK button.

•If the top arrow on the Jog dial

is pressed, the first frame is

displayed, and if the bottom

arrow is pressed, the last

frame is displayed. When the

first frame is selected, the

displayed images other than

the last frame will change

accordingly.

A/S/M

OFF

[1/1]24

MOVIE

PLAY

CARD

SETUP

MODE

SETUP

FUNCTION

INFO

MOVIE

INDEX

MOVIE

EDIT

765

157

•The total movie time and time

of the current frame will

appear in the left corner on the

LCD monitor.

•To go to the next frame, press

the right arrow on the jog dial

and to go the previous frame,

press the left arrow.

Press the right/left arrows on

the Jog dial to select the last

frame for the index display.

•Just as when the first frame is

selected, the image can be

selected by using the Jog dial.

When the last frame is

selected, the displayed images

other than the top frame will

change accordingly.

•Press the Menu button to go to

back to first frame selection.

Press the OK button to record

the index image in the card

and cancel the Menu.

•The index image will be

recorded in the corresponding

mode listed below.

HQ [SQ2 (1024 x 768/HIGH)

SQ [SQ2 (640 x 480/HIGH)

CANCEL

0" / 88"

CANCEL

Note:

• The index can be displayed in 9 frames only.

158

FUNCTIONS (Cont.)

EDITING A MOVIE

This function is used to delete unnecessary portions of recorded movies

or to split one movie into two.

Set the Mode dial to .

Using the Jog dial, display an

image with the mark on

the LCD monitor.

Press the Menu button to

display the Menu.

Press the top/bottom arrows

on the Jog dial to select

FUNCTION.

After pressing the right arrow

on the Jog dial, press the

top/bottom arrows to select

MOVIE EDIT, then press the

OK button.

A/S/M

OFF

[1/1]24

MOVIE

PLAY

CARD

SETUP

MODE

SETUP

FUNCTION

INFO

MOVIE

INDEX

MOVIE

EDIT

876

542

159

Press the right/left arrows on

the Jog dial to select the first

frame, then press the OK

button.

•If the top arrow on the Jog dial

is pressed, the first frame of

the movie is displayed, and if

the bottom arrow is pressed,

the last frame is displayed.

Press the right/left arrows on

the Jog dial to select the last

frame, then press the OK

button.

•Just as when selecting the top

frame, the top/bottom arrows

on the Jog dial can be used to

select the frame.

Press the right/left arrows on

the Jog dial to select NEW or

ERASE.

•If NEW is selected, the edited

movie is saved as a new

movie with a different name.

•If ERASE is selected, the

edited movie is saved under

the original name. The original

movie is discarded.

Press the OK button to record

the movie and cancel the

Menu.

0" / 88"

CANCEL

0" / 88"

CANCEL

NEW ERASE

160

CARD SETUP

ALL-FRAME ERASE

Set the Mode dial to .

Display a picture with on

the LCD monitor using the

Jog dial.

Press the Menu button to

display the Menu.

Press the top/bottom arrows

on the Jog dial to select CARD

SETUP.

Press the right arrow on the

Jog dial, then press the

top/bottom arrows to select

Press the OK button to display

YES NO

542

A/S/M

OFF

[1/1]24

MOVIE

PLAY

CARD

SETUP

MODE

SETUP

FUNCTION

INFO

YES NO
