●Thank you for purchasing an Olympus digital camera.

●Follow the procedures in this manual to install the USB driver. Following

other procedures may result in incorrect installation.

CONNECTING

THE CAMERA

TO A PC

DIGITAL CAMERA

C-100

D-370

OPERATION MANUAL

INTRODUCTION

This manual explains in detail how to connect your camera to a personal

computer. Read it carefully and keep it in a safe place for future reference.

ABOUT THIS MANUAL

●The contents of this publication are subject to change without notice. For

the latest information, please contact your local Olympus representative.

●Considerable care was taken in preparing this manual. If, however, you

have any queries or note any errors or omissions, please contact your

local Olympus representative.

●Duplication of this manual, in whole or in part, other than for personal

use, without the prior permission of Olympus is prohibited. Reproduction

without permission is strictly prohibited.

TRADEMARKS

●Microsoft products, such as Windows and Internet Explorer are registered

trademarks or trademarks of Microsoft Corporation in the United States of

America and in other countries.

●Macintosh and Apple are registered trademarks of Apple Computers, Inc.

●Other brand names and product names mentioned in this manual are

trademarks or registered trademarks of their respective owners.

INDEX

FOR Windows (98/Me/2000) USERS 5

FOR Macintosh (Mac OS9) USERS 15

FOR OTHER OS USERS 21

Windows Macintosh

FLOW

Checking

Connecting

Installing (First time only for Windows)

Saving

Disconnecting

There are various items to be

checked before you start.

Connect the camera to the

PC using the USB cable.

Install the driver in the PC to

ensure detection of the

camera.

After checking that the PC

detects the camera, you can

copy and save images on the

PC.

Disconnect the camera from

the PC.

➜➜➜➜

Windows

CHECKING

• When a SmartMedia card is inserted, you can download the images

stored on the card.To download images from the internal memory,

remove the SmartMedia card.

• Turn the PC on and check that Windows is running.

• Quit all applications that may be running.

• Olympus recommends the use of an optional AC adapter. If you

are using batteries and the power runs out while you are accessing

the SmartMedia card in the camera from the PC, the camera may

stop functioning mid-operation and files (image data) may be lost.

• If you are not using an AC adapter, check the battery level to make

sure that there is enough power left.

• Do not connect or disconnect the AC adapter while the camera is

connected to the PC.

Caution

•Olympus cannot guarantee operation on a PC that has been

upgraded from Windows 95 to Windows 98 even if it has a USB

connector.

•If the camera is connected to the PC with the batteries still

loaded in the camera, connecting and disconnecting the AC

adapter may lead to damage or loss of the image data on the

SmartMedia card or computer system lockup.

•Use the USB cable to connect the PC and the camera.

We cannot guarantee operation if you connect the PC and the

camera by HUB adapter (for connecting several peripheral devices).

•Olympus cannot guarantee operation on a PC whose

operating system is not pre-installed at the time it leaves the

factory or a PC assembled by the user, as the operating

environment of such PCs is not guaranteed by the

manufacturer.

Connecting your camera to the PC ........................................ 6

Installing the driver (First time only) ....................................... 7

Saving images from your camera on the PC ....................... 10

Disconnecting your camera from the PC ............................. 13

FOR Windows

(98/Me/2000) USERS

Windows

CONNECTING YOUR CAMERA TO THE PC

1Insert the connector on one end of the USB cable into

the USB port of the PC.

Note

The position of the USB port varies depending on the PC. Refer

to the operation manual for the PC.

2Make sure that the lens barrier of the camera is closed.

3Open the connector cover on

the camera.

4Insert the connector on the

other end of the USB cable

into the USB connector on the

camera.

5The green lamp lights.

The camera is now connected to the

PC.

Caution

All buttons on the camera are ignored when it is connected to

the PC.

This mark is engraved

on the connector

Connector

USB port

Green lamp (lights)

Connector cover

Connector

USB

connector

Windows

INSTALLING THE DRIVER (FIRST TIME ONLY)

If you are using Windows 98, install the driver by following the procedures

explained below. If you are using Windows Me/2000, you need not follow

these procedures as the driver will be installed automatically. Proceed to

“Saving images from your camera or the PC”( p.10).

1The New Hardware Found window will be displayed on

the PC monitor.

2Click on [Next].

3Select [Search for the best

driver for your device.

(Recommended)] and click on

[Next].

4Insert the CD-ROM supplied

with the camera into the CD-

ROM drive of the PC.

If the CAMEDIA window is

automatically opened, click on

[close].

Windows

INSTALLING THE DRIVER (FIRST TIME ONLY)

5Select [Specify a location:]

and click on [Browse].

6Click on +on the left of the

CD-ROM drive icon.

7Click on +on the left of the

[Usb] folder.

8Select the [Win98] folder in

[USB] folder and click on

[OK].

Windows

INSTALLING THE DRIVER (FIRST TIME ONLY)

9Click on [Next].

Click on [Next] when the

driver has been detected.

Installation of the driver will start.

Do not turn the PC off or disconnect

the camera from the PC during

installation.

Click on [Finish].

Installation of the driver is

now completed. Proceed to

“Saving images from the

camera on the PC” on next

page.

Windows

SAVING IMAGES FROM YOUR CAMERA ON THE PC

This function enables you to save images on the PC. The My Documents

folder is used in this manual as an example. You choose or create a different

folder if desired.

1Double-click on the [My

Computer] icon on the PC

desktop and open the window.

2Double-click on the

[Removable Disk] icon.

The [Removable Disk] icon will be

displayed when the camera is

connected to the PC, indicating that

the camera is recognized as the

[Removable Disk].

Note

•If the [Removable Disk] icon is not displayed, or if an error

message is displayed when you double-click on the

[Removable Disk] icon, one of the following may have

occurred:

1There is a problem with the power supply to the camera

(the AC adapter is not connected properly or the batteries

are exhausted).

2There is a problem with the SmartMedia card.

Check that you can confirm recorded images on the

camera’s monitor.

3There is a problem with the connectivity between the

camera and the PC via the USB cable.

•If no SmartMedia card has been inserted in the camera, the

internal memory will be indicated by a [Removable Disk] icon.

If a SmartMedia card has been inserted, the card will be

indicated by a [Removable Disk] icons.

3Double-click on the [Dcim]

icon and open the folder.
