Olympus SP-810UZ Manuale utente

Instruction Manual

DIGITAL CAMERA

●Thank you for purchasing an Olympus digital camera. Before you start to use your new camera, please read these

instructions carefully to enjoy optimum performance and a longer service life. Keep this manual in a safe place for

future reference.

●We recommend that you take test shots to get accustomed to your camera before taking important photographs.

●In the interest of continually improving products, Olympus reserves the right to update or modify information

contained in this manual.

SP-810UZ

Checking the contents of the box

Digital camera Strap Lens cap and

lens cap strap

Lithium Ion

Battery

(LI-50B)

USB cable

(CB-USB8)

AV cable

(CB-AVC3)

USB-AC

adapter

(F-2AC)

OLYMPUS Setup

CD-ROM

Names of Parts

Camera unit

1Flash

2AF illuminator

Self-timer lamp

3Microphone

Lens

Card slot

6Battery/card compartment

cover

Tripod socket

8Strap eyelet

9Speaker

Other accessories not shown: Warranty card

Contents may vary depending on purchase location.

1Monitor

2button

3Rbutton (record movies)

4qbutton (switching

between shooting and

playback)

5Abutton (OK)

Wheel controller

INFO button (changing

information display)

button (erase)

Ebutton (menu guide)

8Connector cover

9Multi-connector

10 HDMI micro connector

11 Indicator lamp

12 Zoom lever

13 Shutter button

14 nbutton

Attaching the camera strap and lens cap

• Attach the strap to the other

eyelet in the same manner.

Pull the strap tight so that it does not come loose.

Monitor

Shooting mode display

ORM

0.00.0

AUTO

ISO

AUTO

ISO

00:3400:34

DATE

1/100 F3.01/100 F3.0

15161718 14 13 12 1011

2627

Battery check..........p. 13, 55

Shooting mode .......p. 16, 23

Flash.............................p. 19

Flash standby/ﬂash charge

....................................p. 54

Macro/super macro ......p. 28

Self-timer ......................p. 28

Exposure compensation

....................................p. 29

White balance...............p. 29

ISO ...............................p. 30

Drive .............................p. 30

Recording with sound

(movies)......................p. 38

Date stamp ...................p. 37

World time ....................p. 48

Image stabilization (still

images)/Digital image

stabilization (movies)

....................................p. 36

Metering .......................p. 35

Shadow Adjustment

Technology..................p. 35

Compression (still images)

..............................p. 34, 62

Image size (still images)

..............................p. 34, 62

Number of storable still

pictures (still images)

....................................p. 16

Current memory ...........p. 60

Movie recording icon ....p. 17

Remaining recording time

(movies)......................p. 17

Image size (movies)

..............................p. 34, 63

Histogram .....................p. 20

AF target mark..............p. 17

Camera shake warning

Aperture value..............p. 17

Shutter speed...............p. 17

Playback mode display

●Standard display 1Battery check..........p. 13, 55

23D image ......................p. 32

3Print reservation/number of

prints..................p. 52/p. 51

4Eye-Fi transferred.........p. 42

5Protect ..........................p. 41

6Adding sound .........p. 38, 39

7Current memory ...........p. 60

8Frame number/total number

of images ....................p. 20

Elapsed time/total shooting

time (movies)

....................................p. 21

9Volume ...................p. 20, 44

10 Histogram .....................p. 20

11 Shutter speed ...............p. 17

12 Aperture value ..............p. 17

ISO ...............................p. 30

Exposure compensation

....................................p. 29

White balance...............p. 29

Compression (still images)

..............................p. 34, 62

Image quality (movies)

..............................p. 34, 63

Image size........p. 34, 62, 63

File number

Date and time.........p. 15, 48

Shadow Adjustment

Technology..................p. 35

Shooting mode .......p. 16, 23

10103D3D

00:0000:00

4/30

’11/10/26’11/10/26

1786542 3

Still image Movie

00:12/00:3400:12/00:34

●Advanced display

1/1000 F3.0 2.0

AUTO

100

ISO

ORM

FILE

100 0004

00:00

10103D3D

4/304/30

’11/10/26

1/1000 F3.0 2.0

AUTO

100

ISO

ORM

FILE

100 0004

00:00

’11/10/26

1786542 3 11 12 1413

Camera Settings

Using the Buttons

Frequently used functions can be accessed using the buttons.

Zoom lever (p. 18, 22)

Shutter button (p. 17, 54)

Rbutton (shooting movies) (p. 17)

qbutton (switching between

shooting and playback) (p. 17,

20, 43)

button (p. 9)

Ebutton (menu guide) (p. 22)

G(down) /

button (erase) (p. 21)

F(up) /INFO button

(changing information display) (p. 19, 22)

I(right)

Abutton

The wheel controller can also be used to change the selections.

Wheel controller

H(left)

Operation guide

The symbols FGHI displayed for image selections

and settings indicate that the wheel controller is to

be used by pressing, not turning, the wheel controller

sections (p. 6).

10 26 00 00

:..

2011

SetCancel

Y M D Time

Y/M/DY/M/D

ORM

Single Print

4/304/30

00:00

ORM

FILE

100 0004100 0004

00:00’11/10/26’11/10/26

Operation guides displayed at the bottom of the screen

indicate that the button, Abutton, or zoom lever

can be used.

Erase/Cancel

Sel. Image 5/30

Set

ResetReset

Compression Normal

Shadow Adjust Auto

AF Mode

ESP/

Face/iESP

ESP

Digital Zoom Off

Image Size 14M

SetExit

Operation guide

Using the Menu

Use the menu to change camera settings such as the shooting mode.

There may be menus that are unavailable depending on other related settings or the shooting mode (p. 23).

Function menu

Press Hduring shooting to display the function menu. The function menu is used to choose the shooting mode

and provides access to frequently used shooting settings.

0.00.0

AUTO

ISO

AUTO

ISO

MENUMENU

3D3D

Program AutoProgram Auto

ORM

To select the shooting mode

Use HI to select the shooting mode and press the Abutton.

To select the function menu

Use FG to select a menu and use HI to select a menu option. Press the Abutton

to set the function menu.

Shooting

Selected option

Setup menu

Function menu

Shooting mode

1Press the button.

●The setup menu is displayed.

Compression Normal

Shadow Adjust

Auto

AF Mode

ESP/

Face/iESP

ESP

Digital Zoom Off

Image Size 14M

SetExit

ResetReset

2Press Hto select the page tabs. Use FG

to select the desired page tab and press I.

Set

Compression Normal

Shadow Adjust

Auto

AF Mode

ESP/

Face/iESP

Exit

ESP

Digital Zoom Off

Image Size 14M

ResetReset

Page tab

Compression Normal

Shadow Adjust

Auto

AF Mode

ESP/

Face/iESP

ESP

Digital Zoom Off

Image Size 14M

SetExit

ResetReset

Submenu 1

3Use FG to select the desired submenu 1

and then press the Abutton.

Compression Normal

Shadow Adjust

Auto

AF Mode

ESP/

Face/iESP

ESP

Image Size 14M

Set

Exit

ResetReset

Digital Zoom OffDigital Zoom Off

Compression Normal

Shadow Adjust

Auto

AF Mode

ESP/

Face/iESP

ESP

Image Size 14M

SetBack

ResetReset

Digital Zoom OffDigital Zoom Off

Digital Zoom

OffOff

Submenu 2

4Use FG to select the desired submenu 2

and then press the Abutton.

●Once a setting is selected, the display returns to

the Submenu 1.

There may be additional operations. “Menu

Settings” (p. 33 to 48)

Compression Normal

Shadow Adjust

Auto

AF Mode

ESP/

Face/iESP

ESP

Image Size 14M

SetExit

ResetReset

Digital Zoom OnOnDigital Zoom

5Press the button to complete the

setting.

Setup menu

Press the button during shooting or playback to display the setup menu. The setup menu provides access

to a variety of camera settings, including options not listed in the function menu, display options, and the time and

date.

Menu Index

1Shooting mode ...........p.16, 23

P(Program Auto)

M(iAUTO)

(Scene Mode)

P(Magic Filter)

p(Panorama)

W(3D)

2Flash.................................p. 19

3Macro ...............................p. 28

4Self-timer ..........................p. 28

5Exposure compensation...p. 29

6White balance...................p. 29

7ISO ...................................p. 30

8Drive .................................p. 30

9p(Shooting menu 1)......p. 33

Reset

Image Size

Compression

Shadow Adjust

AF Mode

ESP/n

Digital Zoom

0q(Shooting menu 2) .....p.36

Image Stabilizer

AF Illuminat.

Rec View

Pic Orientation

Icon Guide

Date Stamp

aA(Movie menu) ..............p. 34

Image Size

Image Quality

IS Movie Mode

R(Movie sound recording)

bq(Playback) ..................p. 39

Slideshow

Edit

Erase

Print Order

R(Protect)

y(Rotate)

cr(Settings 1) .............. p. 42

Memory Format/Format

Backup

Eye-Fi

USB Connection

qPower On

KeepzSettings

Pw On Setup

ds(Settings 2) ............. p. 44

Sound Settings

File Name

Pixel Mapping

s(Monitor)

TV Out

Power Save

l(Language)

et(Settings 3) ............. p. 48

X(Date/time)

World Time

0.00.0

AUTO

ISO

AUTO

ISO

MENUMENU

3D3D

Program AutoProgram Auto

ORM

Set

Compression Normal

Shadow Adjust

Auto

AF Mode

ESP/

Face/iESP

Exit

ESP

Digital Zoom Off

Image Size 14M

ResetReset

Altri manuali per SP-810UZ

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Olympus Macchina fotografica digitale

Olympus

Olympus CAMEDIA D-535 ZOOM Manuale utente

Olympus

Olympus Stylus Verve - Stylus Verve 4MP Digital... Guida all'installazione

Olympus

Olympus TG-830 Manuale utente

Olympus

Olympus STYLUS TOUGH-8000 Guida all'installazione

Olympus

Olympus FE110 - 5 Megapixel Digital Camera Manuale utente

Olympus

Olympus E-P2 - PEN 12.3 MP Micro Four Thirds Interchangeable Lens Digital... Manuale utente

Olympus

Olympus SC30 Manuale utente

Olympus

Olympus FE 280 - Digital Camera - Compact Guida alla configurazione

Olympus

Olympus FE-5050 Manuale utente

Olympus

Olympus T-10 Istruzioni per il montaggio

Olympus

Olympus Stylus 7030 Manuale utente

Olympus

Olympus FE 180 - Digital Camera - 6.0 Megapixel Guida alla configurazione

Olympus

Olympus CAMEDIA C-350 Zoom Guida all'installazione

Olympus

Olympus 227460 Manuale utente

Olympus

Olympus E-PM1 Istruzioni per il montaggio

Olympus

Olympus CAMEDIA C-160 Manuale utente

Olympus

Olympus XZ-1 Manuale utente

Olympus

Olympus E-M5 Mark III Manuale utente

Olympus

Olympus CAMEDIA SP-500 UZ Guida all'installazione

Olympus

Olympus C-700 - CAMEDIA Ultra Zoom Manuale utente

Olympus

Olympus 1030SW - Stylus Digital Camera Manuale utente

Olympus

Olympus C030303ZOOM Manuale utente

Olympus

Olympus FE-240/X-795 Guida all'installazione

Olympus

Olympus Camedia C-450ZOOM Guida all'installazione

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Canon

Canon EOS ELAN7 Manuale utente
