Olympus SP 100EE Manuale utente

Thank you for purchasing an Olympus digital camera. Before you start to

use your new camera, please read these instructions carefully to enjoy

optimum performance and a longer service life. Keep this manual in a safe

place for future reference.

We recommend that you take test shots to get accustomed to your camera

before taking important photographs.

The screen and camera illustrations shown in this manual were produced

during the development stages and may differ from the actual product.

Instruction Manual

DIGITAL CAMERA

SP-100EE

Unpack the box contents

The following items are included with the camera.

If anything is missing or damaged, contact the dealer from whom you

purchased the camera.

Digital camera Strap Lithium Ion Battery

(LI-92B)

OLYMPUS Setup

CD-ROM

Lens cap and

lens cap strap USB-AC adapter (F-2AC) USB cable (CB-USB8)

Other accessories not shown: Warranty card

Contents may vary depending on purchase location.

Attaching the camera strap

• Attach the strap to the other eyelet in the same manner.

• Pull the strap tight so that it does not come loose.

• You can attach the lens cap to the strap.

Names of parts

1nbutton

2Indicator lamp

3Shutter button

4Zoom lever

5Built-in flash

6Strap eyelet

7Self-timer lamp/AF illuminator

8Dot sight

9Lens

0 Diopter adjustment dial

a Dot sight switch

bFlash switch

cAFL/FOCUS LIMIT button

dSide zoom lever

eTripod socket

fBattery/card compartment lock

gBattery/card compartment cover

h Speaker

1Stereo microphone

2Viewfinder (EVF)

3Monitor

4Dot sight adjustment dial

5Mode dial

6Control dial

7Fn button

8u(EVF) button

9Connector cover

0Multi-connector

aHDMI micro connector

bq(Playback) button

cArrow pad

dH(Left) button

eAbutton

fbutton

gR(Movie) button

hF(Up) / F(Exposure

compensation) button

iI(Right) /#(Flash) button

jG(Down) / jY(Sequential

shooting/Self-timer) / (Erase)

button

kINFO (Information display) button

Preparations for shooting

Inserting and removing the battery and card

Follow Steps 1 and 2

to open the battery/card

compartment cover.

• Turn off the camera before opening

the battery/card compartment

cover.

Battery/card compartment cover

Battery/card compartment lock

Insert the battery while sliding

the battery lock knob in the

direction of the arrow.

• Insert the battery as illustrated with

the Cmark toward the battery

lock knob.

• Slide the battery lock knob in the

direction of the arrow to unlock,

and then remove the battery.

Battery

lock knob

Insert the card straight until it clicks into

place.

• Always use the specified cards with this

camera. Do not insert other types of memory

cards. g“Using the card” (P. 89)

• Do not touch the metallic parts of the card

directly.

Write-protect switch

To remove the card

Press the card in until it clicks and

comes out slightly, then remove

the card.

Follow Steps 1 and 2to close

battery/card compartment cover.

• When using the camera, be sure to

close the battery/card compartment

cover.

Charging the battery

Connect the USB cable and USB-AC adapter to the camera

and charge the battery.

• The battery is not fully charged at shipment. Before use, be sure to

charge the battery until the indicator lamp turns off (up to 5 hours).

Connecting the camera

AC outlet

USB cable (supplied)

Connector cover

Multi-connector

Indicator lamp

On: Charging

Off: Charged

For charging the battery abroad, see “Using your charger and USB-AC

adapter abroad” (P. 88).

Never use any cable other than supplied or Olympus-designated USB cable.

This may cause smoking or burning.

The included F-2AC USB-AC adapter (hereafter referred to as USB-AC

adapter) differs depending on the region where you purchased the camera. If

you received a plug-in type USB-AC adapter, plug it directly into AC outlet.

Be sure to unplug the power plug of the USB-AC adapter from the wall outlet

when the charging is complete or the playback ends.

For details on the battery, see “Battery Handling Precautions” (P. 98). For

details on the USB-AC adapter, see “USB-AC adapter” (P. 99).

• If the indicator lamp does not light, check the USB cable and USB-AC adapter

connections.

• If “No Connection” is displayed on the back monitor, disconnect the USB

cable and set [Storage] in [USB Connection] (P. 61) before connecting the cable

again.

When to charge the batteries

Charge the battery when the

error message shown on the

right appears.

Error message

Battery Empty

Flashes in red

Turning on the camera and making the initial

settings

When you turn on the camera for the first time, a screen appears enabling

to set the language for the menus and messages displayed in the monitor,

and the date and time.

To change the selected date and time, see “Setting the date and time

d[X]” (P. 63).

Press the nbutton to turn on the camera, press

FGHI of the arrow pad to select your language and press

the Abutton.

Press FG of the arrow

pad to select the year for

[Y].

Back

Y/M/D

YMDTime

-- -- -- --

:..

2014

Press Iof the arrow pad

to save the setting for [Y].

Back

Y/M/D

Y M D Time

-- -- -- --

:..

2014

As in Steps 2 and 3, press FGHI of the arrow pad to

set [M] (month), [D] (day), [Time] (hours and minutes), and

[Y/M/D] (date order), and then press the Abutton.

• For precise time setting, press the Abutton as the time signal strikes

00 seconds.

Use HI to select the

time zone and then press

the Abutton.

• Use

FG to turn daylight

saving time ([Summer]) on

or off.

’14.02.26 12:30

Summer
