Olympus Stylus Manuale utente
INSTRUCTIONS
Description of controls
LCD panel
Shutter release button
Flash reflector
Autofocus windows
Lens barrier
Rewind button
Light sensor
Self-timer button
Flash mode button
Self-timer signal
Viewfinder
Autofocus indicator
Flash indicator
Strap Eyelet
Back cover release
Film window
Tripod socket
Battery compartment cover
Exposure counter
Flash OFF
AUTO/AUTO-S flash
Battery remaining indicator
Fill-in flash
LCD panel
Autofocus frame
Close-up
correction marks
Viewfinder indicators
2
Table of contents
Description of controls.................................... 1
Beforeyou begin...........................................5
Loading the battery........................................ 5
Simple point & shoot photography .................... 7
Loading the film............................................ 7
Unloading the film........................................ 11
How to take pictures..................................... 13
Auto flash photography
(1) Taking pictures in low light......................... 18
Auto flash photography
(2)
Taking
backlighted
subjects
........................
20
Camera functions and controls........................ 21
Close-up (Macro) photography........................ 21
Focus lock.................................................. 22
Self-timer photography.................................. 24
Flash AUTO-S mode.................................... 25
Flash OFF mode.......................................... 27
FILL-IN
flash
mode
....................................
28
Attaching the strap/How to use the soft case..... 29
Troubleshooting...........................................31
Care and storage.......................................... 33
Specifications..............................................34
3
Thank you for purchasing the Olympus
Please read this instruction manual carefully before using the camera.
This camera will not operate unless the lens barrier is opened.
We also recommend that you shoot at least one roll of film to familiarize yourself
with the camera's features.
Symbols used in this manual
Correct
Incorrect
Operation
Order of operation
Automatic operation
Operating sound
Lamp on
Lamp blinking
Attention
Press lightly
4
Loading the
battery
Before you
begin
Open the battery compartment cover.
*Remove the battery if you do not plan to
use the camera for an extended period of
time.
Insert the new battery correctly as
indicated below and close the bat-
tery compartment cover tightly.
*Use a 3V lithium battery
(Duracell DL123A, Panasonic CR123A,
or equivalent.)
5
*Open the battery compartment cover
and remove the battery, as illustrated
below, when replacing the battery.
*Be sure to close the lens barrier when
replacing the battery.
Open the lens barrier as shown
below until you hear a "Click"
and check the battery power
remaining.
When is displayed (Approx. 12
sec.), battery is OK.
If flashes, battery is low, have spare
handy.
If is displayed continuously, battery
should be replaced immediately.
*When closing the lens barrier, slide
gently to allow the lens to retract as the
barrier is being closed.
6
Open the back cover by sliding
the back cover release toward the
top of the camera.
The camera back will open.
Simple point
and shoot
photography
Loading
the film
This camera is
designed to use DX
coded 35 mm film to
automatically set film
speed. If DX-coded
film is unavailable,
use ISO 100 film.
7
Prepare a "DX" film cartridge.
The camera will set itself auto-
matically for DX-coded film
speeds from ISO 50 to 3200.
*When using non-DX film, the film
speed is automatically set to ISO 100.
Insert the film cartridge into the
camera.
Avoid direct sunlight when load-
ing the film.
Be sure the film is lying flat.
8
Align the film leader with the red film loading indicator.
Adjust the length of the film leader before loading so that it matches
with the red loading indicator.
Make sure the film leader tip is not bent and the film perforations are
properly aligned and engaged as shown.
Close the camera back firmly.
(Make sure the back cover lock
snaps down.)
*
9
