Olympus Zoom230 Manuale utente

INSTRUCTIONS

Infinity

Table of contents

Description ofcontrols

Beforeyoubegin

Loading the batteries

Checking the batteries

Adjusting the viewfinder

Attachingthestrap

Loading the film

Unloading the film

Simple point & shoot photography

How to take pictures

Auto flash photography

(1)Taking pictures in low light

(2)Taking backlit subjects

Advanced shooting techniques

Focus lock

Remotecontrol

Super macro photography

Spot mode

Auto-zoom mode

Continuous mode

Selftimer

AUTO-S flash photography

Flash OFF

FILL-IN flash

Night scene flash photography

How to use the filters (optional)

How to use the soft case (optional)

Care and storage

Questions and answers

Specifications

Thank you for purchasing the OLYMPUS Infinity Zoom 230. Please read this instruction manual carefully before using

the camera. This camera will not operate unless the batteries are loaded and the power switch is set ON. Before taking

important pictures, it is recommended that you shoot a roll of film just to familiarize yourself with the camera's

features.

Symbols used in this manual

Correct

Incorrect

Operation

Order

Operation order

Automatic operation

Attention

Operation sound

Lamp on

Lampblinking

Press lightly

Description of controls

Viewfinder

Super macro button

Zoom buttons

Shutter release button

Autofocus windows

Steady grip

Lens

Dioptric correction lever

Power switch

LCD panel

Flash reflector

Strap eyelet

Selftimer indicator

Light sensor

Lens barrier

Subject button

Flash mode button

Film window

Back cover

Tripod socket

Viewfinder

Back cover release

Battery compartment cover

Remote control unit

Rewind button

Viewfinder display

LCD panel

(flash) indicator (orange)

"AF" indicator (green)

Close-up

correction marks

Autofocus frame

Flash mode

Flash mode selection

Exposure counter

Auto-zoom

Continuous mode

Selftimer

Battery check

Spot mode

Super macro

Remote control

Before you

begin...

Remove battery cover on the side

of the grip.

*Before replacing the batteries, set the

power switch OFF.

Insert two 3V lithium batteries as

shown and replace the cover.

Use Panasonic CR123A, Duracell

DL123A, or equivalent.

*Do not mix different types of batteries or

new and old batteries at the same time.

*Remove batteries if you do not plan to use

the camera for an extended period of time

(more than a year).

Loading the

batteries

Checking the

batteries

Turn power ON by sliding the power

switch as shown.

The battery check indicator will be

displayed for 12 seconds.

When is displayed, batteries are

OK.

If flashes, batteries are low, have

spares handy.

If is displayed continuously,

batteries should be replaced

immediately.

*When the battery power is low, the

flash will take longer to recharge.

*To turn OFF, slide the power switch

again.

Adjusting the

viewfinder

A dioptric correction lever on the

viewfinder eyepiece allows you to

adjust the clarity of the viewfinder

image. This is especially helpful for

photographers who wear eyeglasses.

Attaching the

strap

Stopper

Green mark for super macro photography (see P.30)
