Olympus Air A01 Manuale utente
A01
Instruction Manual
A01
2
EN
Introduction
Unpack the box contents
• OLYMPUS AIR A01 (Body)
• AIR-CP01 AIR Coupling (already attached)
• AIR-ST01 Hand Strap
• CB-USB9 USB Cable
• Warranty card
• Welcome Card
• Safety Precautions
• Lens*
* In the case of a lens kit, the lens (or lenses) of the relevant kit is supplied.
A01
3
EN
Names of parts
157
90
43 6
8
a
e
d
c
f
2
b
1Body cap
2Stereo Microphone
3Shutter Button
4LED Illuminator
5ON/OFF button
6Open Button (AIR Coupling)
7Mount index (AIR Coupling)
8Accessory attachment mark
9Accessory Release Lever
0Lens Release Lever
aStrap eyelet (AIR Coupling)
bTripod socket
cRear Cover
dRadio switch
emicro USB Connector
fmicroSD card Slot
A01
4
EN
Preparation
Removing the AIR coupling
Turn the AIR coupling in the direction of arrow 2while pressing the accessory
release lever (arrow 1).
12
Charging
Connect OLYMPUS AIR to your computer using the USB cable (supplied).
1
Turn off OLYMPUS AIR.
• When the power is off, the LED illuminator on the body is off.
2
Connect the supplied USB cable to the micro USB connector.
3
Connect to a USB port on your computer.
• During charging, the LED illuminator on the body is lit orange.
• Charging takes a maximum of approx. 4 hours 30 minutes.
• When charging has finished, the LED illuminator goes off.
LED Illuminator
ON/OFF button
A01
5
EN
Inserting the card
Use a commercially available microSD card that complies with the SD standards.
Cautions
• Before inserting or removing the card, turn OLYMPUS AIR off and turn the radio
switch OFF.
• Do not forcibly insert a damaged or deformed card. Doing so may damage the card
slot.
1
Remove the OLYMPUS AIR rear cover.
2
Insert the microSD card.
• With the connector surface facing toward the outer side of OLYMPUS AIR, push in the
card until you hear a click.
3
Attach the rear cover.
Removing the card
Press the inserted card lightly and it will be ejected. Pull out the card.
A01
6
EN
Attaching a lens to the camera
You can use lenses of the Micro Four Thirds Mount standard.
1
Attach a lens to the camera.
12
• Remove the OLYMPUS AIR body cap and the lens rear cap.
• Align the lens attachment mark on OLYMPUS AIR (red mark) with the mount index on
the lens (red mark) and press the lens onto OLYMPUS AIR.
• Rotate clockwise (direction of arrow 3) until the lens clicks.
Cautions
• Do not operate the lens release lever.
• Do not touch any of the internal parts of OLYMPUS AIR.
2
Remove the lens cap.
1
1
2
Removing the lens from the camera
1
Turn the lens while pressing the lens release lever in the direction
indicated.
2
13
A01
7
EN
Attaching the AIR coupling
1
Attach the hand strap.
• Attach the hand strap to the strap eyelet on the AIR coupling.
2
Align the mount index on the AIR coupling with the accessory
attachment mark on OLYMPUS AIR, and attach.
3
Turn the AIR coupling in the indicated direction until you hear a
click.
A01
8
EN
Attaching to a smartphone
1
Press the open button to open
the AIR coupling.
2
Switch the adjustment lever
position to fit the size of your
smartphone.
3
Attach your smartphone
to the AIR coupling.
Width of compatible smartphones:
58.6 – 77.8 mm
• Secure attachment may not be
possible with smartphones of
certain shapes.
1
2
Cautions
• Use the hand strap to avoid inadvertently dropping the system during use.
• Firmly grip both OLYMPUS AIR and your smartphone. Before carrying around
OLYMPUS AIR, please detach your smartphone.
• If you hold only the smartphone, there is a risk it will detach from the AIR coupling.
Please hold both the camera body and lens.
• OLYMPUS will not be held responsible for any damage incurred to your smartphone,
smartphone case, protective film, or other smartphone accessories.
A01
9
EN
Connection settings
Connecting to a smartphone
OLYMPUS AIR connects to your smartphone over Bluetooth or Wi-Fi, and is
controlled using our dedicated app. To establish Bluetooth and Wi-Fi connections,
you will have to carry out one-time initial settings.
You will need to first install the dedicated app (OA.Central) on your
smartphone. Download the app from the App store or Google Play.
Cautions
• Smartphone not equipped with Bluetooth Smart will only work with a
Wi-Fi connection.
OLYMPUS AIR initial settings
Start the installed app and proceed with the settings as instructed by the app.
1
Start OA.Central.
■Setting for the first time
A01
10
EN
FAQ
Battery does not get charged.
• Please turn off the power of OLYMPUS AIR before charging.
OLYMPUS AIR does not turn on.
• Charge OLYMPUS AIR.
• If you cannot switch on OLYMPUS AIR using your smartphone, check your Bluetooth
settings.
LED is blinking (blue or green).
• Battery is missing. Please Charge.
• A movie is shooting.
LED is flashing slowly in green.
• OLYMPUS AIR is in sleep mode (energy saving mode).
OLYMPUS AIR will wake from Sleep Mode when operated. When in the Sleep Mode and
not operated for a specified time period, OLYMPUS AIR will automatically turn off.
No response to operations on OA.Central.
• OLYMPUS AIR has not been turned on.
• If the LED illuminator is on and there is still no response, press and hold down the ON/OFF
button (for approximately 8 seconds). This restarts OLYMPUS AIR.
I want to change the OLYMPUS AIR settings, such as image size.
• Perform settings on your smartphone using OA.Central. Various detailed settings can be
changed from the Camera Settings screen of the OA.Central app.
I want to return the network settings to the state at the time of purchase.
• Please operate the following with the power off and microSD card removed.
1. Push the ON/OFF button briefly with the shutter button pressed all the way down and
the lens release lever pulled all the way.
2. Once the power goes on, it will automatically turn off.
3. Again, turn the power on and you can use the network settings in the state at the time
of purchase.
