OmniPrint Direct Treater Dual Manuale utente
Table of Contents
What’s Included.....................................................................Page 1
Direct Treater Dual Specification……………….………....…Page 2
Direct Treater Dual Installation……………………....…….Page 3- 4
Direct Treater Dual Operation…...……………………………Page 5
Direct Treater Dual Setting Functions.................................Page 6
Direct Treater Dual Sub Menu Functions………………...Page 7-9
Anatomy of a Direct Treater Dual................................Pages 10-12
Before You Plug In Your Machine!.....................................Page 13
Setting Up Your Direct Treater Dual............................Pages 14-18
Direct Treater Dual Shut Down Procedure.................Pages 19-23
Replacing Nozzle Into Spraying Mechanism..............Pages 24-25
Official Settings Guidelines................................................Page 26
What’s Included In The Direct Treater Dual Pretreatment
Machine Package:
[1] Direct Treater Dual
Pretreatment Machine
[1] Drain Tube
[1] Controller Power Supply
[1] Pedal
Direct Treater Dual Specifications
Single V-nozzle type
Speed: 150~180 sheets / hour
Cleaning amount: 20Sec –150ml
Size (Unit: mm)
Close: 1004.44(L) X 522.10(W) X 934.64(H)
Open: 1733.55 (L) X 522.10(W) X 1041.4(H)
Power (Free-voltage)
AC100-220V~ (50/60Hz)
Working: 50W
Stand by: 17W
Weight: 70kg
2 Bottles for Pre-treatment liquid
1 Bottle for cleaning liquid (water)
1 Bottle for waste liquid
Direct Treater Dual Installation
1. Positioning
-Install on Flat and rigid area
-Check opened size in
Specification page
-Connect Power cable
2. Pour Pre-treatment liquid to
Bottle1 or Bottle2
From left two bottles for
Pretreatment liquid. And, third
one is for Cleaner.
And, last one is for waste liquid
Fill Liquid
3. Just select one liquid and
then, you can use this pre-
treatment machine
Select Liquid
How To Install The Pedal Switch
1. Plug male connector into
female connector on the
Pretreater
2. Screw in plastic piece on
male connector to lock the
connector assembly
3. Push in plastic and rubber
pieces for complete install
Direct Treater Dual Operation
1. Emergency stop button. It is
using It is using for emergency
situation. When this button
push, all electric power will be
stop. For re-start, just turn this
button clock wise.
CAUTION After turn it clock
wise, electrical power will come
back. So, you should check all
things before Re-start
2. For machine’s Power on / off,
you should use this switch
which is beside of Waste bottle
In case of power off, you should
close UI in touch screen for
machine’s stable system
Direct Treater Dual Sub Menu Functions
Tray Sensor: When the table tray is closed, it will not display. (If you don´t want to
use this sensor, you need touch this icon. That time, this icon will be change. For use
again, just it need touch again).
Position Reset: If user move the nozzle assembly by hand, machine lost nozzle
assembly’s position. This case, for check start position, it need to touch “Reset”.
Save: You can save and open your spray environment.
Setting: You can set language, purge and clean mode.
Power: When you touch power button, you will see “Power Off” menu. From here, there
are two selection. If you select “Off”, this touch screen will be off. Then, you need just
switch off. If you need nozzle cleaning option, you can select “Clean & off”.
In case of “Clean & off” it will showing valve check window first. Then, you can click
“OK”, it will work to clean mode. After cleaning (it will take 20 sec.) Touch screen will
be off automatically.
During cleaning, if you push “stop” button, it will come back to “Power Off” menu.
Settings functions:
-Language: You can select
Language
-Purge: This function is for
filling Pre-treatment liquid in
the nozzle, after cleaning with
cleaner.
Open the Top cover, and then,
check the Valve.
Open the exhaust Valve.
(Vertical way is open) Then,
touch the “Purge. This time,
pump will work 2 sec. and air
will be out from pump and
tubes
Step2: Close exhaust valve.
Then, push start button. This
time, pump will work for 2 sec.
and liquid will be fill until
nozzle.
