DEVICENET
for seamless automation solutions
Optimising industrial networking
Advanced Industrial Automation
DeviceNet is an innovative industrial network system that enables a wide range of devices to be
easily networked and managed remotely Everything - from PLCs and remote I/O,
to fibre optic sensors, vision systems controllers, servos and inverters - can be seamlessly
integrated into DeviceNet, making it one of the best industrial field busses around
And the trend is for DeviceNet to become even more popular with end-users
and OEMs who look for a simple yet effective solution to controlling their automation
processes, no matter how complex
Industrial network for total solutions
As a founding member of DeviceNet, Omron is one of the few companies
that integrates DeviceNet interfaces into its many core products
Omron is also the first company to introduce wireless communications
to the DeviceNet system And Omron has developed a user-friendly
software package that helps you configure all DeviceNet products
for optimum performance With such an unrivalled product portfolio
and DeviceNet enhancing capability, Omron is the logical choice
for anyone wishing to optimise their automation system
DeviceNet configurator
Intuitive use, from simp
detailed tuning of devic
of actual network config
functions for troublesho
Remote I/O
Omron’s latest remote I/Os have automatic baud rate recognition, which is
unique in DeviceNet They can be used as plug & play slaves, or fully configured
to suit the application Omron’s DRT2 series feature integrated preventive
maintenance functions These smart slaves monitor and log the power supply,
operating time, the number of I/O operations, output-to-input delay times, and
can signal when maintenance is due
PLC masters and slaves
When it comes to PLCs, Omron’s reputation for
quality, reliability and advanced technology is
unsurpassed Omron’s CJ1 offers the best
size/performance ratio in the industry Like all
current Omron PLCs, CJ1 has a DeviceNet interface
It can be used as master, slave, or both at the same
time Omron’s CPM2C micro PLC with integrated
DeviceNet slave interface allows truly seamless
distributed control Even PLC programming and
monitoring can be done through DeviceNet
DeviceNet and Omron – the benefits
Traditional industrial automation systems require a matrix of multi-core cables,
cable supports, junction boxes, control cabinets and data cables A DeviceNet
network simplifies wiring by using just a dual twisted pair cable to provide both
power and data This saves on wiring costs and the time needed for materials
installation What’s more, Omron can supply every product you’ll ever need on
DeviceNet to optimise your industrial automation system
r
ple drag & drop configuration to
ce parameters Enables upload
guration Features powerful
ooting and maintenance
Sensors
Omron’s V600 is an industrial RF-ID
system which can be fitted with a
DeviceNet interface for seamless
integration in PLC based systems
DeviceNet and Omron – afforda le and state-of-the-art
All of Omron’s products are optimised for seamless
integration into a DeviceNet system You can configure
Omron’s devices over the network on-the-fly, and add a device
or machine to a production line without powering down
DeviceNet is a flexible network, designed to accommodate
your growing needs Omron is a dedicated developer of
DeviceNet core technologies, so you’ll always have access to
state-of-the-art devices The result is that you get an
affordable, state-of-the-art solution for optimising your
industrial automation system!
Omron’s DeviceNet software - so easy to use
Omron’s DeviceNet configuration software is specially
developed to take the complexity out of DeviceNet by ensuring
that products integrate in a more user-friendly way than in
other bus systems Omron’s DeviceNet units have a default
mode that enables you to set the addresses, plug the
products in and watch everything run The configuration
software allows you to monitor and fine-tune the DeviceNet
products in your network for optimum operation The products
are literally plug-and-play, and the software is drag-and-drop
Nothing could be easier
HMI
Monochrome or colour touch-screen
terminals with DeviceNet option
module Explicit messaging
allows freely configurable access to
terminal data
Sensors
Omron’s E3X-series fibre-optic sensors
can be configured and operated through
DeviceNet Each slave interface can
support up to 16 sensor amplifiers
Temperature controllers
OMRON’s renowned single- and multi-loop
temperature controllers can be seamlessly
integrated into control systems, providing full
access to all control parameters over DeviceNet
Drives
Omron’s W-series servo
drives with DeviceNet slave
interface simplify distributed
control and information
management for servo
systems Most of OMRON’s
variable frequency drives can
also be networked using
DeviceNet option boards
Sensors
The F150 is a small yet powerful machine
vision system ideally suited for quality
inspection applications Its DeviceNet
interface can handle everything from
simple ‘PASS/FAIL’ data exchange to
detailed image property data transfer
Omron - the ideal one-stop-shop
Omron has seamlessly integrated DeviceNet interfaces into
all of its core products, including PLCs, I/O modules, HMI
terminals, wireless data links, temperature controllers,
sensors, and drives With such a comprehensive selection of
DeviceNet compatible products available, Omron is a virtual
one-stop shop for any customer
First with wireless interfacing - unique
As a leading global player in developing DeviceNet products,
it’s no surprise that Omron should be the first company to
introduce a wireless interface to this network Operating on
the standard 2 4 GHz frequency band, this unique interface is
the ideal wireless solution between two or more DeviceNet
bus segments, particularly when using a wired product
is difficult
Wireless DeviceNet link
This unique product links two or
more DeviceNet systems up to
60 metres apart using RF
It provides reliable multi-path
communication and frequency
hopping, which minimises the
risk of transmission errors
DeviceNet and Omron –setting the standards
DeviceNet is based on open standards and specifications
defined by the Open DeviceNet Vendors Association (ODVA),
a consortium whose main task is to promote DeviceNet
world-wide Omron is a founding member of ODVA and a
leading player in promoting DeviceNet, and is dedicated to
producing and improving products that work with DeviceNet
All Omron products are ODVA certified, making them fully
DeviceNet compatible Thanks to ODVA’s strong conformance
testing policies, DeviceNet also ensures the interchangeability
and interoperability of control devices from hundreds of
manufacturers world-wide
DeviceNet and Omron…
benefits at a glance!
Features
Benefits to you:
• An open communication standard
- Assures multi-vendor device interoperability
•All products ODVA certified
- Omron can supply every product you need for your
DeviceNet application
•Fast, easy installation
- Saves on space and time
•Future-ready for easy additions as your needs change
- DeviceNet is designed for easy network additions of
Omron products
•On-the-fly configuration and additions without
powering down
- DeviceNet doesn’t stop even when you’re adding to it
•Dedicated developer of DeviceNet core technology
- You’ll always be up-to-date with state-of-the-art products
•DeviceNet compatible software
- Omron’s DeviceNet drag-and-drop configuration
software ensures user-friendly operation
I/O modules of Omron
