Opticron Imagic IS 10x30 Manuale utente

Imagic IS

User Guide and Guarantee

Models

10x30

12x30

14x30

Features & Speciﬁcations

AMulti-stage rotating retractable

eyecup assembly

BDioptre adjustment ring

CAnchor points for connecting

binocular strap

DImage stabilisation ON/OFF switch

EWide band focusing (inﬁnity to

2.9 metres close focus)

Speciﬁcations 10x30 12x30 14x30

Product Code

Field (m/1000m)

Close Focus (m)

Eye relief (mm)

IPD (mm)

HxW (mm)

Weight (g)

30730

2.9

54~74

151x118

534

30731

2.9

54~74

151x118

537

30732

2.9

54~74

151x118

537

Accessories (included)

Soft Vinyl Case Rainguard Neoprene Strap and Anti-ﬂip Loop Microﬁbre

Cleaning Cloth

Accessories (optional)

31018 Nylon Harness

with Quick Release

31048 Elastic Harness

with Quick Release

Binoculars can be a useful companion when travelling, going to sporting and leisure events or used as part of a

hobby such as birdwatching or astronomy. To help you get the best results from your equipment please read the

following instructions carefully.

Retractable rubber eyecups and wearing glasses. Imagic IS binoculars provide the full ﬁeld of view when wearing

glasses. To get the maximum ﬁeld of view with glasses on, turn the eyecup clockwise into the ‘down’ position.

Remember to return them to the upright position if you or anybody else wants to use them without glasses.

Adjusting to obtain a single picture.

To adjust to match the spacing of your eyes, rotate the two eyepieces until a single

rounded picture is obtained.

Adjusting for maximum sharpness

Many people have slightly different vision between their eyes.

When using binoculars, this difference can be compensated for

by setting the single eyepiece adjustment located on the right hand side of the binocular below

the eyepiece.

To set the binoculars correctly, close your right eye and look through the left eyepiece with your

left eye and using the centre focus wheel - focus on an object of your choice until it is clear and

sharp. Next, close your left eye and look through the right eyepiece with your right eye. You may ﬁnd the object

being viewed is not absolutely sharp and this can be corrected by rotating the right hand side adjustment ring (but

without turning the centre focus wheel) until the object being viewed becomes sharp. The binoculars are now set

and a perfectly clear and sharp image should be attainable when using both eyes together. To focus at different

distances simply rotate the centre focus wheel.

User Instructions

Using the Image Stabilisation System

The image stabilisation system is controlled using the ON/OFF switch located on the top side of the main body.

Changing the Batteries

The Imagic IS is powered by 2x AAA 1.5V batteries located on the underside of the main body.

To change the batteries, pinch the end cap and pull out. Replace batteries and ﬁx the end cap

back into place. Please recycle used batteries at your local recycling centre.

Care and cleaning. Binoculars require little maintenance but occasionally the outside surfaces of the eyepieces and

objective lenses will need cleaning. To avoid damaging these surfaces please read the following carefully.

(i) Gently remove excess dirt and dust using compressed air or a lens cleaning brush.

Caution: Hard and persistent rubbing of dirty surfaces can cause abrasive scratches on the surface of the glass

which may distort viewing.

(ii) Breathe on exposed glass surface and then wipe with an optical cleaning cloth (code 30277) in a circular motion

until the surface is clean again.

Do not attempt to dismantle the instrument as this will invalidate the guarantee.

Cold weather. In cold weather the external lens surfaces may steam up when moving the instrument from cooler air

outside to warmer air inside. If this happens, leave the instrument to stand for a few minutes until any condensation

evaporates.

WARNING Never under any circumstances use a binocular to view the Sun. Doing so may cause serious damage to

your eyes.

We hope you will get a great deal of pleasure from your Opticron Imagic IS binocular. If you have any problems or

damage the instrument in any way please contact our Service Department.

User Instructions

Guarantee

Please keep this Guarantee Card in a safe place

Model:........................................................................................................................................................................

Serial No: ................................................................. Purchase Date:...................................................................

Dealer: .......................................................................................................................................................................

Opticron Imagic IS binoculars are of a very high quality both in their performance and construction.

We guarantee some parts in these instruments for up to 10 years under the following conditions:

Image Stabilisation System

The stabilisation system and electronic components are guaranteed for 2 years from date of purchase.

Binocular (excluding image stabilisation system)

(i) In the case of defects attributable to faulty processing or materials, we will assume responsibility for the labour

and material costs during the ﬁrst 5 years after purchase. We reserve the right to decide whether defective parts

should be repaired or replaced.

(ii) During the next 5 years we will assume responsibility for material costs only, charging corresponding labour

costs.

(iii) We will accept no liability for damage caused by incorrect use, or for any repairs or actions which have been

carried out outside our ﬁrm.

(iv) Parts such as carrying straps, rubber eyecups, rubberised coatings etc. are excluded from the guarantee.

This guarantee is in addition and does not affect your statutory rights.

Registration

If you would like to register your purchase with us please visit www.opticron.co.uk and complete the online

Product Registration Form.

Alternatively please telephone us during normal working hours on the numbers given. We will need the product

name and serial number (if applicable), purchase date and outlet, your name and postcode.

Registration is voluntary and failure to register will not diminish your rights under the guarantee.

Privacy

Opticron takes your privacy seriously and we do not share personal information with other companies.

Address: Opticron, Unit 21, Titan Court, Laporte Way, Luton, Bedfordshire, LU4 8EF, UK

Phone: +44 (0)1582 726522 Email: [email protected]
