Optoma H56 Manuale di installazione

H56 RS232 Protocol function list

Interface

3 wires RS-232C Protocol

Baud Rate : 57600

Data Bits: 8

Parity: None

Stop Bits: 1

Flow Control : None

Write Command Syntax

Write Basic Protocol

Header :

Address Code :

Command Code :

Data :

Terminator Code :

Delimiter : Space

‘*’

‘0’ fixed

ASCII Text

Fixed 3 digits

Carriage Return

Example:

Display menu

* 0 IR 008 [Carriage Return]

[Projector Response] Receive Ok

Read Command Syntax

Read Basic Protocol

Header

Address Code

Command Code

Data

Terminator Code

Delimiter

‘*’

‘0’ fixed

ASCII Text

‘?’ fixed

Carriage Return

Acknowledgement Syntax

Basic Protocal

ReceiveOK

Unknown Command

Invalid Command

In current source

Data value out of range

Data response

?*000<CR>?

?*255<CR>?

?*001<CR>?

?*002<CR>?

As Write Command

Format

Function Comand

Power On

Power Off

Keystone

Zoom

Freeze

Down

Right

Left

Enter

Re-Sync

Source:S-Video

Source:Composite Video

Source: VGA

Source: DVI terminal

Aspect ratio 16: 9

Aspect ratio 4: 3

Brightness

Contrast

Color Temperature

Advanced adjustment : Red contrast

Advanced adjustment : Green contrast

Advanced adjustment : Blue contrast

Advanced adjustment : Red Brightness

Advanced adjustment : Green Brightness

Advanced adjustment : Blue Brightness

De-interlacing : Auto

De-interlacing : Flim

Signal : Horizontal

Signal : Vertical

Signal : Frequency

Signal : Phase

Aspect Ratio : Native

Aspect Ratio : Window

Aspect Ratio : Letter Box

Language

Bulb (lamp information)

Auto Image :On

Auto Image : Off

Auto Shutdown :On

Auto Shutdown :Off

Gamma

Sharpness

Color

TINT

Image mode (De-gamma)

White peaking

OKOKOKOKOK*

IR 002

IR 004

IR 005

IR 007

IR 008

IR 009

IR 010

IR 011

IR 012

IR 013

IR 014

IR 018

IR 019

IR 052

IR 051

IR 021

IR 022

IR 025

IR 026

IR 027

IR 028

IR 029

IR 030

IR 031

IR 032

IR 033

IR 034

IR 035

IR 036

IR 037

IR 038

IR 039

IR 040

IR 041

IR 042

IR 043

IR 044

IR 045

IR 046

IR 047

IR 048

IR 049

IR 050

IR 053

IR 054

IR 055

IR 056

* Yes the power ON command is correct and is the only command that uses this unique syntax structure. The power

on command OKOKOKOKOK must have a delay of 0.001 sec between each character so:

O[0.001sec]K[0.001sec]O[0.001sec]K[0.001sec]O[0.001sec]K[0.001sec]O[0.001sec]K[0.001sec]O[0.001sec]K[0.001

sec]

Read(Query) Command

Basic Return Status Meaning

Lamp Status Lamp ? Lamp 0

Lamp 1 Lamp Off

Lamp On

Source Src ? Src 0

Src 1

Src 2

Src 3

Src 4

Src 5

Src 6

No signal connect

Analog RGB display

Digital RGB display

HDTV display

S-Video display

Composite Video Display

Component Video display

Crestron Users

If using with a Crestron module The power on command OKOKOKOKOK must have a delay of

0.001 sec between each character so:

O[0.001sec]K[0.001sec]O[0.001sec]K[0.001sec]O[0.001sec]K[0.001sec]O[0.001sec]K[0.001s

ec]O[0.001sec]K[0.001sec]

So in Crestron language the power on command is:

OKOKOKOKOK\x0D\x20

With a 1 Tick delay between each character
