SERVICE MANUAL

SI : TSE: Check: Approved:

Date Revise Version Description

2007.07.19 V1.0 Initial Issue

2007.08.07 V2.0 Edit 2-1, 2-4, 2-11, 4-9

2007.10.07 V3.0 Add HD803

2008.06.13 V4.0 Add HD80-LV, HD803-LV

2009.4.27 V5.0

1. Add HD8000, HD800X, HD800X-LV, HD806,HD8000, HD800X, HD800X-LV, HD806,

HD803S, HD805S, HD8000LV.

2. Add “Re-write Display Hour“ in CH 2.

3. Modify “Auto Shut Down” in CH 3.

4. Modify “Light Leak” in CH 4-6.

2010.02.22

V6.0

Modify CH 4 "Defect specication table"

HD80/HD80-LV/HD803-LV Series

HD80 Series HD80, HD803, HD8000, HD800X

HD80-LV Series HD80-LV, HD8000LV, HD805S

HD803-LV Series HD803-LV, HD806, HD800X-LV, HD803S

HD80/HD80-LV/HD803-LV Series Condential I

HD80/HD803-LV/HD80-LV Comparison List

Model

Part HD80 HD803-LV HD80-LV

FORMATTER BD

80.87Z06G021

(EMEA)EMEA)) 80.87Z06G011

80.87Z06G031

(USA)USA))

SCALER BD

70.87Z21GR01

(USA)

70.87Z25GR01

(USA)

70.87Z31GR01

(USA)

70.87Z21GR11

(EMEA)

70.87Z35GR01

(EMEA)

70.87Z32GR01

(EMEA)

ENGINE MODULE 70.87Z19GR01

70.87Z29GR01

(USA/EUROPE/UK) 70.87Z19GR01

70.87Z19GR01

(Others)

COLOR WHEEL

MODULE 70.85H24GR01 70.87Z40GR01

DMD 48.87CDMGD01 48.87ZDMGD01 48.87CDMGD01

HD80 Series Comparison List

Model

Part HD80 HD8000 HD803 HD800X

FORMATTER

80.87Z06G021

(EMEA)80.87Z06G003 80.87Z06G002 80.87Z06G011

80.87Z06G031

(USA))

SCALER BD

70.87Z21GR01

(USA) 80.87Z01G004 80.87Z01G003 70.87Z35GR01

70.87Z21GR11

(EMEA)

ENGINE

MODULE 70.87Z19GR01 70.87Z29GR01

DMD 48.87CDMGD01 48.87ZDMGD01

Condential II

HD80/HD80-LV/HD803-LV Series

HD803-LV Series Comparison List

Model

Part HD800X-LV HD806 HD803-LV HD803S

SCALER

BD 70.87Z35GR01 70.87Z25GR01

70.87Z25GR01

(USA) 70.87Z26GR01

70.87Z35GR01

(EMEA)

ENGINE

MODULE 70.87Z29GR01

70.87Z29GR01

(USA/EUROPE/UK) 70.87Z19GR01

70.87Z19GR01

(Others)

DMD 48.87CDMGD01 48.87ZDMGD01

HD80-LV Series Comparison List

Model

Part HD805S HD8000LV HD80-LV

SCALER BD 70.87Z27GR01 70.87Z33GR01 70.87Z31GR01(USA)

70.87Z32GR01(EMEA)

Condential II

HD80/HD80-LV/HD803-LV Series

Preface

This manual is applied to HD80/HD80-LV/HD803-LV Series projection system. The

manual gives you a brief description of basic technical information to help in service and

maintain the product.

Your customers will appreciate the quick response time when you immediately identify

problems that occur with our products. We expect your customers will appreciate the

service that you offer them.

This manual is for technicians and people who have an electronic background. Please

send the product back to the distributor for repairing and do not attempt to do anything that

is complex or is not mentioned in the troubleshooting.

Notice:

The information found in this manual is subject to change without prior notice. Any

subsequent changes made to the data herein will be incorporated in future edition.

HD80/HD80-LV/HD803-LV Series Service Manual

Manual Version 6.0

HD80/HD80-LV/HD803-LV Series Condential III

Table of Content

Chapter 1 Introduction

Highlight 1-1

Compatible Mode 1-4

Chapter 2 Disassembly Process

Equipment Needed & Product Overview 2-1

Disassemble Lamp Cover 2-2

Disassemble Lamp Module 2-2

Disassemble Lens Shelter and Focus Ring 2-3

Disassemble Top Cover Module 2-3

Disassemble Keypad Board 2-4

Disassemble Vent 2-4

Disassemble Rear Cover 2-5

Disassemble Formatter Board 2-5

Disassemble IRIS Module 2-6

Disassemble Scaler Board 2-6

Disassemble Fan Shetter1 2-7

Disassemble Ballast 2-8

Disassemble Fan Shetter2 2-9

Disassemble Optical Module 2-9

Disassemble Color Wheel 2-10

Disassemble DMD Chip 2-10

Disassemble Zoom Ring Cover 2-11

Disassemble LVPS 2-11

Disassemble Blower 2-12

Disassemble Bottom Cover Module & Elevator 2-12

Condential IV

HD80/HD80-LV/HD803-LV Series

Rod Adjustment 2-14

Re-write Lamp Usage Hour 2-15

Re-write Display Hour 2-15Re-write Display Hour 2-15

Chapter 3 Troubleshooting

LED Lighting Message 3-1

Main Procedure 3-2

Chapter 4 Function Test & Alignment Procedure

Test Equipment Needed 4-1

Service Mode 4-1

OSD Reset 4-2

Test Condition 4-2

Test Inspection Procedure 4-3

PC Mode 4-3

Calibration 4-7

IRIS Test 4-9

Optical Performance Measure 4-10

Video Performance 4-12

Other 4-13

Chapter 5 Firmware Upgrade

Equipment Needed 5-1

Setup Procedure 5-2

Firmware Upgrade Procedure 5-2

HD80/HD80-LV/HD803-LV Series Condential V

Chapter 6 EDID Upgrade

EDID Introduction 6-1

Equipment Needed 6-2

Setup Procedure (VGA Port) 6-3

DDC Key-In Procedure (VGA Interface) 6-3

Setup Procedure (DVI Port) 6-5

DDC Key-In Procedure (DVI Interface) 6-5

Make sure procedure 6-6

Setup Procedure (HDMI1 Port) 6-7

DDC Key-In Procedure (HDMI1 Interface) 6-7

Make sure procedure 6-8

Setup Procedure (HDMI2 Port) 6-8

DDC Key-In Procedure (HDMI2 Interface) 6-8

Make Sure Procedure 6-9

Appendix A Recommended Spare Parts I

Appendix B Serial Number System Denition XIV

PCBA Code Denition XV

Condential 1-1

HD80/HD80-LV/HD803-LV Series

Chapter 1

Introduction

1-1 Highlight

No Item Description

1 Dimensions (L x W x H) - 411 x 311 x 116 (mm)

2 Weight - approx. 10 lbs (< 11lbs)

3 Tilt Angle - +5/-2 degree with elevator mechanism

4 Power Supply

- Universal AC 100--240V; 50 / 60 Hz with PFC input

- Max. 430W (HD80/HD803/HD8000/HD800X)

Max. 435W (HD80-LV/HD803-LV/HD8000LV/HD805S/

HD806/HD800X-LV/HD803S)

- provide for Philips 300W 1.3 arc UHP E21.8 lamp at brite

mode,255W at ECO mode.

5 Light Source

- Lamp could be changed by customer, but should follow the

user manual instruction.

- Replaceable Lamp should be provided by Coretronic or its

autherized agencies

6 Keystone correction

- ±5° Vertical (HD80/HD803/HD8000/HD800X)

±15° Vertical (HD80-LV/HD803-LV/HD8000LV/HD805S/

HD806/HD800X-LV/HD803S)

(according to Pixelworks PW392 scalar spec)

7Cooling system

- Advanced air ow

- One fan/ two blowers(in projector) with low system acoustic

noise level

- Temperature control circuits with adaptive voltage control

fan speed

- Max touch temperature follows UL60950 regulation

8 Brightness

HD80/HD803/HD8000/HD800X:

- Maximum 1,200 ANSI Lumens

- Typical 1,000 (HD80/HD8000/HD800X)/

940(HD803) ANSI Lumens

- Minimum 800 ANSI Lumens

HD80-LV/HD8000LV/HD805S:

- Maximum 2,200 ANSI Lumens

- Typical 1,740 ANSI Lumens

- Minimum 1,550 ANSI Lumens

HD803-LV/ HD806/HD800X-LV/HD803S:

- Typical 1,479 ANSI Lumens

- Minimum 1,320 ANSI Lumens

Condential 1-2

HD80/HD80-LV/HD803-LV Series

No Item Description

9 Contrast

HD80/HD803/HD8000/HD800X:

- 1,0000:1 full on\full off (with high contrast iris setting),

- 4,000:1 (Maximum)

- 2,500:1(HD80/HD8000/HD800X)(Typical)(Typical)

2,200:1(HD803) (Typical)

- 2,000:1 (Minimum)

HD80-LV/HD8000LV/HD805S:

- 7,000:1 full on\full off (with high contrast iris setting),

- 3,300:1 (Maximum)

- 2,700:1 (Typical)

- 2,200:1 (Minimum)

HD803-LV/HD806/HD800X-LV/HD803S:

- 7,000:1 full on\full off (with high contrast iris setting),

- 2,500:1 (Maximum)

- 2,000:1 (Typical)

- 1,500:1 (Minimum)

10 Uniformity

- 80% Japan standard (Maximum),

- 75% Japan standard (Typical),

- 65% Japan standard (Minimum)

11 Throw ratio -1.85 – 2.22:1 distance/width

12 Lamp door protection - Lamp power supply shut off automatically when door open

13 Projection lens - F/ 2.6~2.82, f = 39.12~46.94 mm. 1.2X Zoomed Focal

Lens

14 Lamp life

HD80/HD803/HD8000/HD800X:

- 1,700 hours typical, 50% survival rate in normal mode

- 2,200 hours typical in Eco mode

HD80-LV/HD8000LV/HD805S/HD803-LV/HD806/

HD800X-LV/HD803S:

- 1,250 hours typical, 50% survival rate in normal mode

- 1,600 hours typical in Eco mode

15 System controller - Dual DDP3021, DAD1000, PMD1000 for 1080p DMD.

Condential 1-3

HD80/HD80-LV/HD803-LV Series

No Item Description

16 Video compatibility

- Standards:

NTSC : NTSC M/J, NTSC 4.43

PAL : PAL B/D/I/G/H, PAL M, PAL N

SECAM : SECAM B/D/G/K/L

SDTV : 480i, 480p, 576i, 576p,

HDTV :

- HD80/HD803/HD8000/HD800X:

720p(50HZ), 720p(60HZ), 1080i(50HZ),

1080i(60HZ) and 1080p(60HZ)

- HD80-LV/HD8000LV/HD805S/HD803-LV/HD806/

HD800X-LV/HD803S:

720p(50Hz), 720p(60Hz), 1080i(50Hz),

1080i(60Hz), 1080P (50 & 60Hz) and 1080p-24

17 Intelligent zoom - By using “TI DDP3021” Chips to provide excellent quality

zooming.

18 SXGA / Compression - By using “DDP3021” Chips to compress SXGA image into

XGA display

19 Power consumption

HD80/HD803/HD8000/HD800X:

- Full power( normal ): typical 425W+/-10% at 110V AC

- ECO power(ECO): typical 360W+/-10% at 110V AC

- Standby mode: < 7 W at 110V AC

H D 8 0 - LV / H D 8 0 0 0 LV / H D 8 0 5 S / H D 8 0 3 - LV / H D 8 0 6 /

HD800X-LV/HD803S:

- Full power( normal ): typical 435W Max at 110V AC

- ECO power(ECO): typical 375W Max at 110V AC

- Standby mode: < 14 W at 110V AC
