Optoma Optoma EP730 Manuale utente

FCC Notice

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of FCC Rules. These limits are designed to pro-

vide reasonable protection against harmful interference

in a residential installation.

Trademarks

Trademarks are the rights of their respective owners.

English

Usage Notice

Precautions .......................................................................................... 2

Introduction

Product Features.................................................................................. 3

Package Overview ............................................................................... 4

Product Overview ................................................................................. 5

Installation

Connecting the Projector ...................................................................... 7

Powering On/Off the Projector.............................................................. 8

Adjusting the Projected Image.............................................................. 10

User Controls

Panel Control & Remote Control .......................................................... 12

On-Screen Display Menus ................................................................... 14

Appendices

Troubleshooting .................................................................................... 21

Changing the Lamp............................................................................... 24

Specifications ....................................................................................... 25

Compatibility Modes............................................................................. 26

Table of Contents

English

Precautions

Follow all warnings, precautions and maintenance as recommended in this

user’s manual to maximize the life of your unit.

Do:

qTurn off the product before cleaning.

qUse a soft cloth moistened with mild detergent to clean the display housing.

qDisconnect the power plug from AC outlet if the product is not being used for a

long period of time.

Don’t:

qBlock the slots and openings on the unit provided for ventilation.

qUse abrasive cleaners, waxes or solvents for your cleaning.

qUse under the following conditions:

- Extremely hot, cold or humid environment.

- In areas susceptible to excessive dust and dirt.

- Near any appliance generating a strong magnetic field.

- Place in direct sunlight.

Usage Notice

Warning- Do not look into the lens. The bright light may hurt your eyes.

Warning- To reduce the risk of fire or electric shock, do not expose this

product to rain or moisture.

Warning- Please do not open or disassemble the product as this may cause

electric shock.

Warning- When changing the lamp, please allow unit to cool down, and follow

all changing instructions.

Warning- This product will detect the life of the lamp itself. Please be sure to

change the lamp when it shows warning messages.

Warning- After changing a new lamp, please reset the lamp life from OSD

menu.

Warning- Before switching off the product, please keep the cooling fan

running for a few minutes.

Warning- Connecting the projector to computer, please turn on the projector

first.

English

Product Features

This product, is an SVGA single chip 0.7” DLPäProjector. The outstanding

features of it are listed as follows:

qTrue SVGA, 800 x 600 addressable pixels

q3.3 lbs. (1.5 kgs) lightweight compact design

qSingle chip DLPätechnology

qXGAcompression and VGA, SVGA re-sizing

q130 Watts user replaceable P-VIP lamp

qMac/NEC PC-98/FM Towns compatible

qNTSC/NTSC4.43/PAL/PAL-M/PAL-N/SECAM and HDTV (720P,480i/P)

compatible

qFull function remote control

qHigh definition TV compatibility

qUser friendly Multilingual on-screen display menu

qAdvanced electronic keystone correction

qUser friendly keypad control with backlight

qLuxurious carrying case included

Introduction

English

Package Overview

This projection display comes with all the items shown below. Check to make

sure your unit is complete. Contact your dealer immediately if anything is

missing.

Projection Display Power Cord

S-Video Cable RCA Audio Cable

VGA Signal Cable

Remote ControlCarrying Case

Warranty Card

Composite Video Cable

RCA to D-Sub Cable

Quick Start Card

Battery x 2 User’s Guide

English

Product Overview

Speaker

Focus Ring

Remote Control

Receiver

Zoom Ring

Zoom Lens Power Connector

Elevator Button

ConnectionPorts

HDTV/Component

Video & Computer

InputConnector S-videoInput

Connector

Audio Input

Connector

Composite Video

InputConnector

PanelControl

Power On / StandbyMenu

(On/Off)

Enter /

Resync

Source

FourDirectional

Select Keys

MuteVolume Lamp

Warning LED

MainUnit

Panel Control

Temperature

Warning LED

English

RemoteControl

Source

Resync

Reset

Freeze

Keystone Correction

Power / Standby

Volume ( + / - )

Mute

FourDirectional

Select Keys

Enter

Zoom In / Zoom Out

English

Connecting the Projector

Installation

vTo ensure the projector works well with your computer, please configure

the display mode of your graphic card to make it less than or equal to 800 X 600

resolution. Make sure timimg of the display mode is compatible with the projector.

Refer to the“Compatibility Modes”section on page 26.

Power Cord

S-Video Output

S-Video

Cable

Video Output

Audio Output

VGA Signal Cable

RGB Port

RGBPort

RCA to D-Sub Cable

Composite Video Cable

RCA Audio Cable

VGA Signal Cable

Digital Tuner Output

Antenna

English

uPowering On the Projector

1. Remove the lens cap.

2. Ensure that the power cord and signal cable are securely connected.

3. The “Power/Standby” indicator will flash.And press the “Power/Standby” button

again to start on your projector.

The startup screen will display for 20 seconds and the Power/Standby indicator will

light solid amber.

4. Turn on your source (computer, notebook, or video player ,etc.). The projector will

detect your source automatically.

* If the screen displays “No Signal” , please make sure the signal cables are

securely connected.

* If you connect multiple sources at the same time, use the “Source” button

onthe Remote Control or Panel Control to switch.

* Turn on the projector first and then the computer.

Power On/Off the Projector

Lens cap

Power /

Standby

English

uPowering Off the Projector

1. Press the “Power/Standby” button to turn off the projector lamp.

2. After pressing the “Power/Standby” button, you will see a message “Power off the

lamp?” on the on-screen display. Press the “Power/Standby” button again to confirm.

Otherwise the message will disappear after 5 seconds.

3. “Power/Standby” LED indicator will flash amber for about 30 seconds.

4. Disconnect the power cord from the electrical outlet and the projector.

* When the “LAMP” indicator lights solid orange; please change the lamp

module immediately.

* When the “TEMP” indicator lights solid orange, it indicates the projector

has been overheated. The display will automatically shut itself down.

Under normal conditions, the display can be switched on again for your

presentation. If the problem persists, you should contact your local dealer or

our service center.

* No matter the video source is input or not, if you press“Power/Standby” by

accident, a “Power off the lamp ?” sign will display in screen. You can clear

the turn-off message by pressing any function key. Or you can just ignore this

message without pressing any function key; the message will disappear after 5

seconds and restore to previous status.
