Oticon MiniRITE Alta2 Manuale utente

Alta2 Nera2 Ria2

INSTRUCTIONS FOR USE RITE

Alta2, Alta, Nera2, Nera, Ria2, Ria

Introduction to this booklet

This booklet guides you in how to use and maintain your new

hearing instrument. Please read the booklet carefully including

the Warning section. This will help you to achieve the full benet

of your new hearing instrument.

Your Hearing Care Professional has adjusted the hearing

instrument to meet your needs. If you have additional questions,

please contact your Hearing Care Professional.

About Start up Handling Options Warnings Additionals

For your convenience this booklet contains a navigation bar to help

you navigate easily through the dierent sections.

Indication for use

The hearing instrument is intended to amplify and transmit sound to

the ear and thereby compensate for mild to moderate-to-severe-to-

profound hearing impairment.

IMPORTANT NOTICE

The hearing instrument amplication is uniquely adjusted and optimised

to your personal hearing capabilities during the instrument tting

performed by your Hearing Care Professional.

Table of content

Options

Warnings

Additionals

About

Start up

Handling

Identify your hearing instrument speaker and ear piece 6

RITE 8

Identify left and right instrument 10

Battery 11

Turn the hearing instrument ON and OFF 12

When to replace a battery 13

Replace the battery 14

Caring for your hearing instrument 16

Put on the instrument 18

Speaker with dome or GripTip 20

Replace dome or GripTip 21

Speaker with micro mould, LiteTip or power mould 22

Maintain the micro mould, LiteTip or power mould 23

Optional features and accessories 24

Mute the hearing instrument (optional) 25

Change programs (optional) 26

Change volume (optional) 28

Tamper-resistant battery drawer (optional) 30

Wireless accessories (optional) 32

Other options (optional) 34

Warnings 36

Troubleshooting guide 42

Water resistant 44

Warranty certicate 46

International warranty 47

Mobile phone 48

Technical information 50

6 7

About Start up Handling Options Warnings Additionals

Identify your hearing instrument speaker

and ear piece

This will make it easier for you to

navigate through this booklet.

A RITE comes with dierent

speakers and ear pieces.

RITE speaker

A RITE will have one of the

following speakers.

RITE ear pieces

A RITE will have one of the

following ear pieces.

RITE with Power mould

speaker

Speaker

(60 shown)

Ear grip

(optional)

Micro mould or LiteTip

Dome (open dome shown)

GripTip

60 85 100

8 9

About Start up Handling Options Warnings Additionals

RITE

What it is

Push button Change programs,

volume and mute

the instrument

Microphone

openings

Sound in

What it does

Battery drawer Contains the battery.

Battery drawer is also

the on/o switch

Speaker

(60 shown) Sound out

10 11

About Start up Handling Options Warnings Additionals

Identify left and right instrument

It is important to distinguish between the left and the right

instrument as they might be programmed dierently. You can nd

left/right colour indicators inside the battery drawer or on 60 and 85

speakers or on the micro moulds/LiteTip.

Battery

Your hearing instrument is a miniature electronic device that runs on

special batteries. To activate the hearing instrument, you must insert

a new battery in the battery drawer. See how in the “Replace the

battery” section.

A RED indicator marks the

RIGHT instrument.

A BLUE indicator marks the

LEFT instrument. Pull out to open

Battery drawer

Your instrument

battery size is 312

12 13

About Start up Handling Options Warnings Additionals

Turn the hearing instrument ON and OFF

The battery drawer is also used to switch the hearing instrument

on and o. To preserve the battery, make sure your instrument is

switched o when you are not wearing it.

When to replace a battery

When it is time to replace the battery you will hear two beeps

repeated in moderate intervals until the battery runs out.

Two beeps

= The battery is running low

Four beeps

= The battery has run out

Battery maintenance tip

To make sure the hearing instrument is always working, bring spare

batteries with you, or replace the battery before you leave home.

Turn ON

Close the

battery

drawer with

the battery

in place.

Turn OFF

Open the

battery drawer.

14 15

About Start up Handling Options Warnings Additionals

Replace the battery

2. Uncover 3. Insert

Fully open the

battery drawer.

Remove the battery.

Remove the sticky

label from the + side

of the new battery.

Insert the new battery

into the battery

drawer. Make sure the

+ side faces up.

1. Remove

MultiTool

Close the battery drawer. The

instrument will play a jingle

through the ear piece.

Hold the earpiece close to your

ear to hear the jingle.

The MultiTool can be used for

battery change. Use the magnetic

end to remove and insert batteries.

The MultiTool is provided by

your Hearing Care Professional.

4. Close Tip

16 17

Caring for your hearing instrument

When handling your hearing instrument, hold it over a soft surface

to avoid damage if you drop it.

Clean the microphone openings

Carefully brush away debris from

the openings. Gently brush the

surface. Make sure the brush is clean

and that it is not pressed into

the openings.

About Start up Handling Options Warnings Additionals

IMPORTANT NOTICE

Use a soft, dry cloth to clean the hearing instrument. It must never be

washed or immersed in water or other liquids.

Microphone

openings

The MultiTool

The MultiTool contains a brush and a wire loop for cleaning ear wax

from the mould. The brush can be replaced and purchased from your

Hearing Care Professional.

Brush

MagnetWire loop

18 19

About Start up Handling Options Warnings Additionals

Put on the instrument

The speaker brings the sound into

your ear. The speaker should

always be used with an ear

piece attached. Use only parts

designed for your

hearing instrument.

If the speaker has an ear grip,

place it in the ear so it follows

the contour of the ear

(see Step 3).

Ear grip

(optional)

Speaker

(60 shown)

Place the hearing

instrument behind

your ear.

Hold the bend of

the speaker wire

between your thumb

and index nger.

The ear piece should

point towards the ear

canal opening.

Gently push the

ear piece into your ear

canal until the speaker

wire sits close against

the side of your head.

Step 1 Step 2 Step 3
