Panasonic AJ-HPM110MC Manuale utente

Panasonic Broadcast

Mechanical Parts List

Model No. : AJ-HPM110P/E/MC

CONTENTS

CASING PARTS ASSEMBLY (1).................................................................................................... MPL-1

CASING PARTS ASSEMBLY (2).................................................................................................... MPL-3

CASING PARTS ASSEMBLY (3).................................................................................................... MPL-5

PACKING PARTS ASSEMBLY....................................................................................................... MPL-7

204

208

204

212

209

204

212

204

212

E19

212

204

209

204

215

222

204

212

204 205

204

208

206 204

204

E21

222

215

205

44 45

215

205

44 45

203

201

204

201

204

203

204

E18

212

201

205

201

204

201

212 212

212

CASING PARTS ASSEMBLY (1)

MPL-1

Components identified with the mark have the special characteristics for safety.

When replacing any of these components, use only the same type.

(P only)

Ref.No. Part No. Part Name & Description

Remarks Ref.No. Part No. Part Name & Description

Remarks

215 XSB3+10FJK SCREW 15

1 VEE1B44 1394 CABLE 1 222 VMX1558 NYLON WASHER 15

2 VMP8741 SD BNC ANGLE 1

3 VMZ3361 PROTECT SHEET 1

5 VJF1559 CLAMPER 2

6 VMT1809 GASKET 2 E1 VEP83683A AVIO P.C.BOARD 1

7 VJF1535 COATING CLIP 1 E2 VEP83670C CODEC P.C.BOARD 1

8 VLP0123 FERRITE CORE 1 J0KG00000001 E3 VEP81253A DCDC1 P.C.BOARD 1

9 VMP8744 POWER UNIT BACK ANGLE 1 E4 VEP81256B DCDC2 P.C.BOARD 1

10 VMZ3665 INSULATION SHEET BOTTOM 1 E5 VEP81251B AC IN P.C.BOARD 1

11 VSC5938 POWER SW SHIELD ANGLE 1 E6 VEP81252B DC IN P.C.BOARD 1

12 VMZ3666 INSULATION SHEET POWER SW

1 E7 VEP83682A SDI P.C.BOARD 1

13 VGU0A63 POWER SW KNOB 1 E8 VEP80D73A CARD IF1 P.C.BOARD 1

14 VEE1D17 DCIN HERNESS 1 E9 VEP80D73B CARD IF2 P.C.BOARD 1

15 VMP8745 POWER UNIT FAN ANGLE 1 E18 VEP80D12H 1394 CN P.C.BOARD 1

16 VMZ3668 INSULATION SHEET DC OUT 1 E19 VEP80D77A HEADPHONE P.C.BOARD 1

17 VQL1K80 CAUTION LABEL 1 FOR AJ-HPM110P/E E21 VEP81257A POWER CN P.C.BOARD 1

17 VQL1K81 CAUTION LABEL 1 FOR AJ-HPM110MC

18 VMP8746 POWER UNIT SIDE ANGLE 1

19 L6FAYYYD0006 FAN MOTOR 1

20 VJF1556 DC IN JACK COVER SHEET 1

21 VGH4997 SIDE JACK NAME PLATE 1

22 VGM2272 MAIN FRAME 1

23 VGQ9194 SIDE DOOR LACTH 1

24 VGU0A64 POWER SW BUTTON 1

25 VYF3176 DOOR U 1

26 VMB4077 SIDE DOOR LACTH SPRING 1

27 VMG1759 PHONE JACK COVER 1

28 VMP8727 HANDLE ANGLE 2

29 VMP8728 SIDE DOOR LACTH ANGLE 1

30 VMP8742 POWER SW SPRING 1

31 VMS7800 POST(SQ-25） 1

32 VQL1K83 POWER SW SHEET 1

33 L6FAYYYD0006 FAN MOTOR 1

34 VSC5967 TOP EARTH ANGLE 2

35 VSC5936 CENTER PANEL EARTH ANGLE 2

37 VMZ3667 INSULATION SHEET POWER SW

38 VGF1072 LCD HINGE L COVER SHEET 1

39 DFKH8008YA HANDLE U 1

40 VMZ3689 FRAME HOLE COVER SHEET 1

41 VYK1Z43 TOP CASE U 1

42 VYK2M75 BOTTOM CASE U 1

43 VMT1865 GASKET 1

44 VKA0394 RUBBER FOOT 2

45 VMX3574 SPACER 4

46 VYP9254 CENTER PANEL U 1

47 VWJ40G7060L0 FLEX. CABLE 2

48 VWJ20H2060L0 FLEX CABLE 1

49 VEE1D04 DCDC1-DCDC2 CABLE 1 1

50 VEE1D05 DCDC1-AVIO CABLE 1 1

51 VEE1D06 DCDC2-AVIO CABLE 1

52 VEE1D07 DCDC2-CODEC/CARD IF CABLE 1

53 VEE1D09 DCDC1-DCDC2 CABLE ２ 1

54 VEE1D10 DCDC1-AVIO CABLE 2 1

55 VEE1D16 AVIO-HEADPHONE CABLE 1

56 VMZ3671 CARD FLEX SHEET 1

57 VMZ3688 DC CABLE SHEET 1

59 VQL4837 SERVICE CAUTION LABEL 1 FOR AJ-HPM110P

61 VGQ9380 COOLING SHEET C6 1

62 VGF1065 PUNCHING SHEET 1

63 VSC5955 HARD GASKET 1

64 VSC5956 HARD GASKET 1

65 VLP0123 FERRITE CORE 1 J0KG00000001

67 VGQ1712 ANP BASE 1

201 XYN26+J6FJ SCREW 11

203 XSB2+6FJ SCREW 4

204 XYN3+J6FJ SCREW 37

205 XSB3+6FJK SCREW 8

206 XQN26+A4FJ SCREW 2

208 XYN3+J20FJK SCREW 8

209 XSB26+6FJK SCREW 2

212 XYN3+J8FJ SCREW 20

CASING PARTS ASSEMBLY (1)

MPL-2

205 213

213

205

211

204

221

213

205

205 205

214

210

E11

E10

CASING PARTS ASSEMBLY (2)

MPL-3

Components identified with the mark have the special characteristics for safety.

When replacing any of these components, use only the same type.

(P only)

Ref.No. Part No. Part Name & Description

Remarks Ref.No. Part No. Part Name & Description

Remarks

1 VYK1Z42 BACK CASE 1U 1

2 VKA0393 RUBBER FOOT 4

3 VMX3574 SPACER 8

4 VYQ3917 SNAP ANGLE U 4

5 VWJ40H2045L0 40PIN45MM FFC 1

6 VWJ30H2045L0 30PIN45MM FFC 1

7 VMX2020 P.C.BOARD POST 3 K9ZZ00000689

8 VXQ0102 SCREW 2 K1YE50000008

9 VKF4152 REAR JACK COVER 1

10 VGN0X75 RATING LABEL 1 FOR AJ-HPM110P

10 VGN0X76 RATING LABEL 1 FOR AJ-HPM110E

10 VGN0X77 RATING LABEL 1 FOR AJ-HPM110MC

12 VMT1858 GASKET 1

13 VMT1906 GASKET 1

14 VQL1P27 CAUTION LABEL 1 FOR AJ-HPM110P

204 XYN3+J6FJ 3

205 XSB3+6FJK SCREW 13

213 DRQT26+D3FKL SCREW 8

214 VHD1774 SCREW 3

211 XYN26+A6FJK SCREW 16

210 XSS3+6FJK SCREW 4

221 XTN3+10JFJK SCREW 6

E10 VEP80E21A JACK IF P.C.BOARD 1

E11 VEP80E22A REAR JACK P.C.BOARD 1

CASING PARTS ASSEMBLY (2)

MPL-4

201

224

217

217 220

220

218

216 216

216

217

201

216

201

226

227 203

203

E14

E15

E20

E13

32 41

202

201

212

205

212

201

202

205

202

201

212

201

202

20 47

E12

20 20

E16 E17

205

212

CASING PARTS ASSEMBLY (3)

MPL-5

Components identified with the mark have the special characteristics for safety.

When replacing any of these components, use only the same type.

(P only)

Ref.No. Part No. Part Name & Description

Remarks Ref.No. Part No. Part Name & Description

Remarks

1 VYK2L87 LCD CASE 1 U 1

3 VGF1066 LCD SPEAKER PUNCHING SHEET 2

4 DFHE0843ZA LCD MAGNET 1

5 DFGB0131ZA PANASONIC BADGE 1

6 VGB0677 P2HD BADGE 1

7 VEQ4541 LCD U 1

8 VMZ3674 FLOURESCENT TUBE INSULATOR 1

9 VMP8748 LCD U ANGLE R 1

10 VMZ3687 FLOURESCENT TUBE INSULATOR 1

11 N0DG2GB00001 INVERTER U 1

12 VMZ3669 LCD INVERTER INSULATOR 1

13 VMP8747 LCD UNIT ANGLE L 1

14 VYQ3884 HINGE UNIT L 1

15 VYQ3885 HINGE UNIT R 1

16 VEE1D12 LCD SIDE-INVERTER CABLE 1

17 VEE1D13 AUDIO-LCD CABLE 1

18 VEK0K64 SPEAKER R 1

19 VEK0K65 SPEAKER L 1

20 VJF1535 COATING CLIP 3

21 J0KG00000011 FERRITE CORE 1

22 VQL4837 SERVICE CAUTION LABEL 1 FOR AJ-HPM110P

23 VJF1559 CLAMPER 1

24 VYP9186 KEY BOARD PANEL 1U 1

25 VGH4372 SLIDE VR NAME PLATE 1

26 VGF1068 SLIDE VR SHEET 1

27 VMG1763 SCREW CAP 5

28 VGU0A77 RESET BUTTON 9

29 VYK1Z40 MINI LCD CASE 1U 1

30 VDB1758 MINI LCD CASE BEARING 2

31 VMZ3672 KEY MAIN SHEET A 1

32 VMZ3673 KEY MAIN SHEET B 1

33 K9B270YY0001 SEARCH DIAL U 1

34 VGU9613 SEARCH DIAL KNOB 1

35 VGU9614 SEARCH DIAL RUBBER 1

36 VGU8401 SLIDE VR KNOB 2

37 VWJ12H2120L0 12PIN120MM FFC 1

38 VWJ12G6080L0 12PIN80MM FFC 1

39 VWJ40H2135L0 40PIN135MM FFC 1

40 VWJ10H2030L0 10PIN30MM FFC 1

41 J0ZZZ0000053 FILTER 2

42 VMS7811 SPACER 2

43 VGQ9224 LCD CABLE COVER 1

44 VYQ3999 HINGE U 1

45 VJF1559 COATING CLIP 1

46 VMZ3361 SUPPORT SHEET 1

47 VMT1852 GASKET 5

201 XYN26+J6FJ SCREW 17

202 VHD1918 SCREW 6

203 XSN3+6FJK SCREW 5

205 XSB3+6FJK SCREW 7

212 XYN3+J8FJ SCREW 8

216 XTV3+8GFJ SCREW 12

217 XTV26+8GFJ SCREW 7

218 XTN4+8GFJ SCREW 3

220 XTW3+8PFJ SCREW 2

224 XWGV3D9G WASHER 2

226 XTV26+6GFJ SCREW 4

E12 VEP80D79A LCD SIDE P.C.BOARD 1

E13 VEP86358A KEY LCD P.C.BOARD 1

E14 VEP86357A KEY MAIN P.C.BOARD 1

E15 VEP80D74A KEY SUB1 P.C.BOARD 1

E16 VEP80D75A KEY SUB2 P.C.BOARD 1

E17 VEP80D76A KEY IF P.C.BOARD 1

E20 VEP80D78A POWER LED P.C.BOARD 1

CASING PARTS ASSEMBLY (3)

MPL-6

PACKING PARTS ASSEMBLY

MPL-7

Components identified with the mark have the special characteristics for safety.

When replacing any of these components, use only the same type.

(E only)

(MC only)

Ref.No. Part No. Part Name & Description

Remarks Ref.No. Part No. Part Name & Description

Remarks

1 VQT1Q19 OPERATING INSTRUCTIONS 1 FOR AJ-HPM110P/E

1 VQT1Q20 OPERATING INSTRUCTIONS 1 FOR AJ-HPM110MC

2 VJA1177 POWER CORD 1 FOR AJ-HPM110P

2 VJA1175 POWER CORD 1 FOR AJ-HPM110E

2 VJA1166 POWER CORD 1 FOR AJ-HPM110MC

3 VPF0876 POLYETHYLENT BAG 1

4 VPN6555 CUSHION TOP 1

5 VPN6556 CUSHION BOTTOM 1

6 VPN6557 ACCESSORY BOX 1

7 VPG1Q95 PACKING CASE 1 FOR AJ-HPM110P

7 VPG1Q96 PACKING CASE 1 FOR AJ-HPM110E

7 VPG1Q97 PACKING CASE 1 FOR AJ-HPM110MC

8 VJA1174 POWER CORD 1 FOR AJ-HPM110E

9 VPG1M36 PACKING CASE 1 FOR AJ-HPM110MC

10 VFC4289 ACCESSORY U 2

PACKING PARTS ASSEMBLY

MPL-8
