Panasonic EB-G600 Manuale utente
Operating Instructions EB-G600
Digital Cellular Telephone Main Kit
Before operating this equipment please read these instructions completely.
Contents
Before You Start ························1
Symbols Used, Safety Information,
Fitting/Removing the SIM, Fitting/Removing the Battery
Your Telephone ·························4
Location of Controls, Display
Basic Operation ·························6
Power on/off, Making a Call, Ending a Call,
Answering a Call, Adjusting Volume, Vibration Alert,
Automatic Redial
Advanced Operation ····················10
Concept of Operation, Voice Memo, DTMF Tones,
Call Hold/Call Waiting
Stored Numbers ························14
Note Pad, Recent Numbers, Phonebook, Fixed Dial,
Service Numbers, Hot Key Telephone Numbers
Alpha Entry ···························20
Editing Alpha Entry
Additional Features·····················21
Key Guard, Phonebook, Messages, Call Service,
Call Divert, Security, Network, Personalise
Battery Information·····················27
Low Battery, Charging the Battery
Care and Maintenance ··················28
Other Information ······················29
Glossary of Terms, Trouble Shooting,
Important Error Messages
Specifications··························34
Notes·································35
Before You Start
Thank you for purchasing this Panasonic G600 digital cellular telephone. This telephone is designed to operate on
the Global System for Mobile Communications (GSM).
These operating instructions detail use of the equipment contained in the Main Kit.
Some services are network dependent or may only be available on a subscription basis. Some functions are SIM
dependent. For more information contact your Service Provider.
Symbols Used
FShows that you should press the following key(s).
,Text-Shows that the display text will be flashing.
Safety Information
This equipment is intended for use when supplied with power from the built-in charger or Dual charger
(EB-CR600) through the AC Adaptor (EB-CA600). Other usage will invalidate any approval given to this
apparatus and may be dangerous.
Switch off your cellular telephone when in an aircraft. The use of cellular telephones in an aircraft may be
dangerous to the operation of the aircraft, disrupt the cellular network and may be illegal. Failure to
observe this instruction may lead to the suspension or denial of cellular telephone services to the offender,
or legal action or both.
You are advised not to use the equipment at a refuelling point. You are reminded of the need to observe
restrictions on the use of radio equipment in fuel depots, chemical plants or where blasting operations are
in progress.
Never expose the battery pack to extreme temperatures (in excess of 60°C) or charge the battery pack for
much longer than recommended.
1
You MUST exercise proper control of your vehicle at all times. Do not use a hand-held telephone or
microphone while you are driving. Find a safe place to stop first. Do not speak into a hands-free
microphone if it will take your mind off the road. Acquaint yourself thoroughly with restrictions concerning
the use of cellular telephones within the country you are driving and observe them at all times.
Care must be taken when using the telephone in close proximity to personal medical devices, such as
pacemakers and hearing aids.
Fitting/Removing the SIM
The SIM is fitted into a holder at the back of the telephone underneath the battery.
Fitting the SIM
Removing the SIM
To remove the SIM follow the above steps in reverse.
2
4
Fitting/Removing the Battery
Fit a fully charged battery pack. If the battery pack is not fully charged then it must be charged as shown in
“Charging the Battery” – see page 27.
Fitting the Battery Removing the Battery
3
1
2
1
3
2
3
Your Telephone
Location of Controls
gNavigation key – pressing up/down scrolls through
options in the main area of the display or adjusts the
volume. Pressing left/right scrolls through options in the
option area of the display (see Display below)
BSelect key – selects an option in the option area of
the display (see Display below)
A– accesses Phonebook or switches character types
D– makes a call or recalls recently dialled telephone
numbers
C– clears the last digit entered, clears all digits when
pressed and held or returns to the previous display
E– ends a call or switches the telephone on/off when
pressed and held
Digit keys 0 to 9, * and # – the # key will switch on and
off vibration alert
:– records a conversation during a call or plays it
back during standby
4
Display
Antenna
Earpiece
Microphone
External
connector
Incoming / charging
indicator
Memo
key
Display
Following some operations the display will automatically
clear after three seconds or after pressing any key.
Ylights when you are registered to a non-home network
- roaming
tlights when call divert is enabled
]lights when vibration alert is enabled
[lights when all tones or ring volume is off
Nflashes when an unread message is stored or lights
when message area is full
Olights when phone lock is enabled
Sindicates that it is possible to make emergency calls
TIndicates received signal strength - \weak
signal, Tstrong signal
Hindicates the battery level - Hfull, Llow
battery
pindicates that the Navigation key (g) can be pressed
5
Location area - indicates
menu number, location
number, or alpha mode
Option area - shows options
that can be selected by B
key
Main area
Pana
57
Basic Operation
Power on/off
FEand hold to switch power on
A greeting will be displayed.
FEand hold to switch power off
Making a Call
Make sure that the telephone is switched on and the signal strength meter is displayed.
1Farea code and telephone number
2FD
Emergency Calls
To make an emergency call the antenna symbol (S) must be present.
F112Dor press Bwhen “SOS” is displayed in the option area of the display
6
Voice Call
Hold
00:01
International Dialling
Using the Automatic International Access Code “+” you will be able to dial international number
without having to know the code for the international exchange.
1F0and hold until a “+” appears
2Fcountry code or eto scroll through the abbreviated international names
3Farea code and telephone number
4FD
NOTE: Many countries include an initial “0” in the area code. This should, in most cases, be left out when dialling
international numbers. If you have difficulties making international calls, contact your Service Provider.
Ending a Call
FE
Answering a Call
To receive a call the telephone must be switched on and the signal strength meter must be displayed.
Fany key except Eor g
FEto reject the call
If a call is not answered the number of unanswered calls will be displayed.
Fany key to clear the display
7
Incoming
