Panasonic DP-6000 Manuale utente

Digital Imaging System

DP-6000/7000

Options

DA-FS700/MA700/XT700/TR700

Operating Instructions (For Copier)

Before operating this machine, please read

these instructions completely and keep these

operating instructions for future reference. English

TRADEMARKS/COPYRIGHTS

The following trademarks and registered trademarks are used throughout this manual.

Microsoft, MS-DOS, Windows, and Windows NT are either registered trademarks or trademarks

of Microsoft Corporation in the United States and/or other countries.

i386, i486, and Pentium are either registered trademarks or trademarks of Intel Corporation.

Adobe, the Adobe logo, Adobe PostScript, Acrobat, Acrobat Reader, and Acrobat logo are either

registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or

other countries.

Apple, the Apple logo, LaserWriter, Mac, Mac logo, Macintosh, Power Macintosh, and TrueType

are either registered trademarks or trademarks of Apple Computer, Inc. in the United States and/

or other countries.

Novell, Novell Client, Novell Directory Services, Novell Distributed Print Services, Netware,

intraNetware, NDPS, NDS, , IPX, IPX/SPX, NDS Admin, NDS Administrator are either registered

trademarks or trademarks of Novell, Inc., in the United States and/or other countries.

Panasonic Document Imaging Company has made every effort to supply trademark information

about company names, products and services mentioned in this documentation. All third party

and/or other trademarks identified herein are the property of their respective owners.

information now allowed by statutory or judicial law or hereinafter granted, including without

limitation, material generated from the software programs that are displayed on the screen such

as styles, templates, icons, screen displays, looks, etc.

Contents are subject to change without notice.

Printed in Japan.

Preface

Thank you for choosing Panasonic DP-6000/7000 Series. This manual aims to provide all the information

necessary for effectively operating the copier together with notes on safety precautions and maintenance tips.

To get the most out of your copier, please read the manual carefully and completely before using the machine.

Keep this manual handy as a quick reference should you encounter any difficulties when using the copier.

In this manual, safety instructions are preceded by the symbol .

Always read and follow the instructions before performing the required procedures.

Safety Notes, Compliances Certifications, and Other Notices

Safety Notes

Your DP-6000/7000 and its supplies have been designed and tested to meet strict safety requirements. These

include safety agency examination and approval, and compliance with established environmental standards.

Please read the following instructions carefully before operating the DP-6000/7000.

Failure to follow the recommendations in this section may result in personal injury or rescinding of the

Dealer's Warranty/Maintenance Agreement.

Ozone Safety

Make sure that the machine is installed in a spacious or well-ventilated room so as not to increase the amount

of ozone in the air. Since ozone is heavier than air, it is recommended that air at floor level be ventilated.

Laser Safety

Use of controls, adjustments or performance procedures other than those specified herein, may result in

hazardous laser radiation exposure.

This equipment complies with safety standards. With specific regard to laser safety, the equipment complies

with performance standards for laser products set by government agencies as a Class I laser product and

does not emit hazardous lights, the beam is totally enclosed during all modes of customer

operation and maintenance.

FCC

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required to correct the interference

at his own expense.

Responsible Party: Matsushita Electric Corporation ofAmerica

One Panasonic Way, Secaucus, NJ 07094

Technical Support: Panasonic Document Imaging Company/

Technical Support Department

Two Panasonic Way, Secaucus, NJ 07094

1-800-225-5329

Email: [email protected]

The user could lose the authority to operate this equipment if any unauthorized changes or modifications are

made to this equipment.

Shielded cables must be used with this equipment to maintain compliance with FCC regulations.

European Union

This product complies with the requirements of EC Council Directives 73/23/EEC amended by 93/68/EEC,

and 89/336/EEC amended by 92/31/EEC and 93/68/EEC.

WARNING

This product is certified, manufactured and tested in compliance with strict safety and radio

frequency interference regulations. Any unauthorized alteration, which includes the addition of

new functions or the connection of external devices, may impact this certification. Please contact

your local authorized Panasonic representative for a list of approved accessories.

WARNING

This is a Class A product. In a domestic environment this product may cause radio frequency

interference in which case the user may be required to take adequate measures.

The user could lose the authority to operate this equipment if any unauthorized changes or

modifications are made to this equipment.

iii

DP-6000/7000 Series

Useful Features

Making Sorted Sets

You can select to output the copies

as collated sets.

4-7 Collating Copy Output

(Output/Finishing)

Copying Mixed Size

Originals

Mixed size documents can be

copied simultaneously without

having to specify the size of

each original.

5-5 Loading Mixed Size Originals

(Mixed Size Originals)

Making Copies of

Odd Sizes

You can make copies by

changing the length/width of

your document.

4-4 Reducing/Enlarging the

Length and Width (Independent

X-Y%)

Copying Multiple

Documents on one

Page

You can copy multiple pages

onto a single sheet of paper.

5-4 Copying Several Documents

onto One Copy (Multi-Up (N Up))

Inserting Blank

Sheets Between

Copied

Transparencies

You can insert blank sheets as

separators between the copied

transparencies. Copies for

distribution can also be made

simultaneously.

5-9 Interleaving Blank Sheets

between Transparencies

(Transparency Separators)

Erasing Shadows

on Copies

You can erase dark lines

usually found on copies made

with the document cover open,

or when the copies are made

from bound documents.

5-8 Erasing the Edges and

Copying All (Edge Erase/Copy All)

Making Copies of a

Bound Document

onto Separate

Sheets

You can make copies from a

bound document onto separate

sheets of paper.

5-6 Copying Facing Pages onto

Separate Sheets (Book Copying)

Creating a Binding

Margin

You can shift the copy image to

create a binding margin at the

edge.

5-7 Setting the Margins (Image

Shift)

Creating a

Negative-type


You can create a negative-type

image on a copy by reversing

the black and white areas of the

original.

5-14 Creating Negative-like

Images (Negative Image)

Repeating an Image

You can copy an image and

repeat it on a paper.

5-16 Repeating an Image

(Repeat Image)

Creating Mirror

Images

You can create a copy

containing the mirror image of a

document by reversing its

orientation.

5-15 Creating Mirror Images

(Mirror Image)

Specifying the Size

of a Document

You can specify the area of the

document you wish to copy.

5-12 Selecting the Original Size

(Original Size)

Storing Jobs in

Memory

You can store the jobs which you

frequently perform into memory.

5-21 Job Memory Operation

Stapling/Punching

Holes in Copies

(optional)

You can staple and output the

copies. Alternatively, you can

punch holes in the copies.

This feature is only available

when the optional Finisher is

installed.

4-8 Stapling (Stapling)

4-9 Punching Holes (Punching)

Enhancing the

Sharpness of a


You can enhance or reduce the

sharpness of a photo.

5-13 Enhancing Sharpness

(Sharpness)

Making Duplex

Copies of Facing

Pages

You can make two sided copies

of documents with facing

pages.

5-17 Making Duplex Copies of

Facing Pages (Book Duplex)

5-18 Inserting Covers (Covers)

Inserting Covers

You can insert a cover such as

a colored sheet as the front

copy.

vii

Using These Operating

Instructions

This manual consists of the following chapters.

Chapter 1 Getting to Know Your Copier

This chapter contains operating instructions about your copier like information on the major components, the

methods of switching the power On and Off and how to use the touch panel display.

After the copier has been properly installed, be sure to read this chapter completely before operating the machine.

Chapter 2 Loading Paper

This chapter covers the types of paper that can be used on this copier, the precautions on paper handling and the

methods on how to load paper in the respective trays. Read this chapter before loading paper in the trays.

Chapter 3 Loading Documents

This chapter covers the types of original documents that can be used on this copier, the precautions on document

handling and how to load the documents. Read this chapter before loading documents on the copier.

Chapter 4 Basic Features

This chapter describes the basic copying operations and nice-to-know applications so that users can perform

normal copying jobs required in a typical office environment. Read this chapter before performing any copying

operations.

Chapter 5 Added Features

This chapter describes how to use the special features and the many versatile ways of making copies. Read this

chapter after you have understood and know how to use the features described in

Chapter 4 Basic Features

Chapter 6 Custom Presets

This chapter provides information required to preset the parameters of the copying features to facilitate daily

operations of the copier. For instance, the default screen, the default values, the tone and the time can all be

preset.

This chapter shows the contents of those parameters that can be selected and explains how to select them with

the use of examples. Read this chapter before selecting the parameters.

viii

Chapter 7 Troubleshooting

This chapter describes the actions to be taken in the event of errors or machine faults. Read this chapter for

instructions on how to resolve these errors if they occurred.

Chapter 8 Daily Care

This chapter provides information on regular maintenance such as replacing drum/toner cartridges, checking the

meters and cleaning the machine. Read this chapter when necessary.

Chapter 9 Using the Auditron Feature

This chapter explains the Auditron feature of this copier. Auditron is the feature that captures information on the

number of copies made by each account user. Read this chapter when managing account data of the users.

Appendix

The appendix includes information on the specifications, the possible combinations of features, and the stapling

function of the machine.
